    Default How can I Join lines

    Registered forum members do not see this ad.

    Hi there

    I created many lines, and joined them together nicely

    Now I have a closed complete 2D shape

    I want to extrude the shape, but...

    I think I need to join all the lines to become a single line first

    I can't find this command

    Any one knows how can I unite all the lines together

  2. #2
    Junior Member jakemstone's Avatar
    Using
    AutoCAD 2006
    Join Date
    Aug 2006
    Location
    St. Albans. UK
    Posts
    13

    Default Polyline Edit

    type PE for polyline edit then M to SELECT multiple lines, once you have selected all the lines press ENTER then you will get a set of options in the commandline, press J for the JOIN command.

  3. #3
    Senior Member Seann's Avatar
    Using
    AutoCAD 2012
    Join Date
    Dec 2006
    Location
    Granite Bay, CA USA
    Posts
    212

    Default

    You can also use region, which makes the closed area a flat face so if you shade it the area will become solid. You can also use boundary and pick the middle of your (hopefully) closed line area. Pedit works too but I prefer region because I know when shaded what closed lines are solids and which are linework.

  4. #4
    Forum Newbie
    Using
    AutoCAD 2004
    Join Date
    Jan 2007
    Posts
    2

    Default

    Thanks guys

    Got it now

    It is just that I am strugling to remember those main tools

    3 years pass since i used Autocad last time.

  5. #5
    Forum Newbie
    Using
    AutoCAD 2011
    Join Date
    May 2012
    Posts
    1

    Default

    Pure garbage, i have autocad 2011 and with this tool impossible to join lines, total waste of time...

  6. #6
    Quantum Mechanic ReMark's Avatar
    Computer Details
    ReMark's Computer Details
    Operating System:
    Windows 7 Pro 64-bit
    Computer:
    Thinkmate
    Motherboard:
    Intel DX58SO2 LGA1366 X58
    CPU:
    Intel i7-960 Quad-core 3.20GHz 8MB cache
    RAM:
    12GB (3x4GB) PC3-106000 DDR3
    Graphics:
    nVidia Quadro 4000, 2GB GDDR5
    Primary Storage:
    150GB Velocipraptor 10,000 rpm
    Secondary Storage:
    none
    Monitor:
    Dell P24LLH - 24" wide screen LCD
    Discipline
    See details...
    ReMark's Discipline Details
    Occupation
    CAD Draftsman/Designer...chemical manufacturing.
    Discipline
    See details below.
    Details
    I work for a specialty chemical manufacturer. I do a little bit of everything from P&IDs to civil to architectural and structural.
    Using
    AutoCAD 2015
    Join Date
    Nov 2005
    Location
    Norwalk, CT USofA
    Posts
    40,191

    Default

    jorge: Sounds like you don't know how to use the command or your geometry is messed up preventing it from working. Post the drawing. Someone here will take a look at it.
    "I have only come here seeking knowledge. Things they wouldn't teach me of in college." The Police

    Eat brains...gain more knowledge!

    I'm now a full member of the Society for the Promotion of Mediocrity in CAD. Standards? We don't need no stinkin' standards! Take whatever advice I offer and do the opposite.

  7. #7
    Forum Deity Dadgad's Avatar
    Using
    AutoCAD 2013
    Join Date
    Nov 2011
    Location
    At the confluence of worthlessness & invaluability
    Posts
    4,226

    Default

    Welcome to the forum.
    Autocad 2011 is pretty good software, it hardly seems fair to blame the software for what will almost certainly turn out to be UIE (user induced error).
    ReMark is right, no shortage of folks willing to help here on the forum.
    Try using the FLATTEN command before trying to join them, perhaps that will help.
    If you were having difficulty with JOIN in the PEDIT command, make sure that when you see the FUZZ DISTANCE prompt you hit ENTER, so that the command will complete.
    If you ignore that and ESCAPE, they will not be joined.
    Last edited by Dadgad; 6th May 2012 at 08:09 am.
    Volume and repetition do not validate opinions forged in the absence of thought.

  8. #8
    Luminous Being JD Mather's Avatar
    Using
    Inventor 2015
    Join Date
    Sep 2007
    Location
    Williamsport, PA
    Posts
    8,527

    Default

    Pure garbage, i have autocad 2011 and with this tool impossible to join lines, total waste of time...
    Of course all of this joining of lines to extrude is unnecessary since r2007.
    You are right - it is a waste of time since it isn't needed.
    Certified SolidWorks Professional
    Autodesk Inventor 2014 Certified Professional
    Autodesk AutoCAD 2013 Certified Professional
    http://home.pct.edu/~jmather/content..._Tutorials.htm

  9. #9
    Forum Deity Dadgad's Avatar
    Using
    AutoCAD 2013
    Join Date
    Nov 2011
    Location
    At the confluence of worthlessness & invaluability
    Posts
    4,226

    Default

    Registered forum members do not see this ad.

    jorge seems to have been necromantically moved for sure, though he doesn't specifically state that he yearns to go 'full-figure'.
