    Default determining plane slopes

    Registered forum members do not see this ad.

    How can I determine the slope of a plane? Then, how can I set the slope of another plane to match the first one?

  2. #2
    Super Moderator fuccaro's Avatar
    Using
    AutoCAD 2006
    Join Date
    Nov 2002
    Location
    Romania, Marosvasarhely
    Posts
    3,540

    Default

    Time for some math!
    The following program will prompt the user for 3 points and it will draw the intersection line between the plane passing through those points and a horizontal plane. Just draw a perpendicular line from any point contained in the plane to the line returned by the program.
    I wrote the program without error trap so please enter 3 different, non collinear points.
    Code:
    ;| Intersection between a user defined plane and a horisontal one
       the 20th of sept 2007    mfuccaro@hotmail.com
    |;
    (defun c:intpl( / q1 q2 q3 l z0 a b c d) ;INTersection of PLanes
     (defun d3(l)
      (- (+ (* (nth 0 l) (nth 4 l) (nth 8 l))
        (* (nth 2 l) (nth 3 l) (nth 7 l))
        (* (nth 1 l) (nth 5 l) (nth 6 l)))
         (+ (* (nth 2 l) (nth 4 l) (nth 6 l))
        (* (nth 0 l) (nth 5 l) (nth 7 l))
        (* (nth 1 l) (nth 3 l) (nth 8 l))))
      )
      (setq l (list (setq q1 (getpoint "first point"))
            (setq q2 (getpoint "2nd"))
            (setq q3 (getpoint "3rd")))
        z0 (apply 'min (mapcar 'caddr l))
        a (d3 (append '(1) (cdr q1) '(1) (cdr q2) '(1) (cdr q3)))
        b (d3 (list (car q1) '1 (last q1) (car q2) '1 (last q2) (car q3) '1 (last q3)))
        c (d3 (list (car q1) (cadr q1) '1 (car q2) (cadr q2) '1 (car q3) (cadr q3) '1))
        d (- (d3 (append q1 q2 q3))))
      (if (zerop b)
        (entmake (list '(0 . "LINE") (list 10 (car q1) (cadr q1) z0) (list 11 (car q2) (cadr q2) z0)))
        (entmake (list '(0 . "LINE")
               (list 10 (apply 'min (mapcar 'car l))
                 (- (/ (+ (* a (apply 'min (mapcar 'car l))) (* c z0) d) b)) z0)
               (list 11 (apply 'max (mapcar 'car l))
                 (- (/ (+ (* a (apply 'max (mapcar 'car l))) (* c z0) d) b))
                 z0)))
        )
      )
    As about the second question: try the ALIGN command
    It's nice to be nice, but sometimes is nicer to be evil!.
    Tip: Please do not PM or email me with CAD questions - use the forums, you'll get an answer sooner.

  3. #3
    Banned Alan Cullen's Avatar
    Using
    Map 3D 2009
    Join Date
    Jun 2006
    Location
    Cairns, Queensland, Australia
    Posts
    4,181

    Default

    Registered forum members do not see this ad.

    It would also help if you specified your autocad version.
