    Default 2D Screw Threads - Any easy way?

    Just wondering.

    If you are just doing a 2D representation of a screw thread, is there are easy way to create it?

    You have a Major Diameter, and a Minor Diameter, plus the form of the thread (poss just plain 30' angles?)

    If you draw just 1 tooth (as it were) can you easily create the whole thread?

  2. #2
    Super Moderator SLW210's Avatar
    Computer Details
    SLW210's Computer Details
    Operating System:
    Windows 7 PRO
    Computer:
    IBM Lenovo
    Motherboard:
    ACPI x86
    CPU:
    Pentium(R) Dual-Core CPU E5500 @ 2.80GHz
    RAM:
    4 GB RAM
    Graphics:
    Nvidia Quadro 600 1GB
    Primary Storage:
    300 GB
    Secondary Storage:
    650GB
    Monitor:
    ThinkVision 24"
    Discipline
    Multi-disciplinary
    SLW210's Discipline Details
    Occupation
    Design Draftsman
    Discipline
    Multi-disciplinary
    Details
    Mostly do drafting related to manufacturing. From doing site layouts with proposed updates, additions and renovations to be budgeted and submitted for bid, to updating and changing existing drawings to reflect maintenance and repair/revision work done on site.
    Using
    AutoCAD 2011
    Join Date
    May 2007
    Location
    South Florida, USA
    Posts
    9,881

    Default

    How about just downloading a drawing from McMaster-Carr.
    “A narrow mind and a fat head invariably come on the same person” Zig Zigler



  3. #3
    Full Member Tempest's Avatar
    Using
    AutoCAD 2007
    Join Date
    Oct 2007
    Location
    Horley (Gatwick) UK
    Posts
    99

    Default

    Quote Originally Posted by SLW210 View Post
    How about just downloading a drawing from McMaster-Carr.
    Thanks for that, but perhaps I'm a bit dim, errrrr, I want a thread form in AutoCAD (a 2D view - not a 3D model) Not sure how a drawing will help, I mean, I can trace around it.

    Unless I'm misunderstanding your meaning here?

  4. #4
    Super Member riga's Avatar
    Using
    AutoCAD 2007
    Join Date
    May 2007
    Location
    Switzerland
    Posts
    723

    Default

    Quote Originally Posted by Tempest View Post
    Thanks for that, but perhaps I'm a bit dim, errrrr, I want a thread form in AutoCAD (a 2D view - not a 3D model) Not sure how a drawing will help, I mean, I can trace around it.

    Unless I'm misunderstanding your meaning here?
    Probably you missed the button for download on the site linked by SLW.
    Select the thread screw you want (type, form, diameter and lenght) then select thecnical drawing (left column) and on the top left corner of the page you will see the download tab (you can choose between 2D dxf or dwg, PDF, Solidworks and also 3D models in various formats)
    HAVE A NICE DAY

  5. #5
    Full Member Tempest's Avatar
    Using
    AutoCAD 2007
    Join Date
    Oct 2007
    Location
    Horley (Gatwick) UK
    Posts
    99

    Default

    Quote Originally Posted by riga View Post
    Probably you missed the button for download on the site linked by SLW.
    Select the thread screw you want (type, form, diameter and lenght) then select thecnical drawing (left column) and on the top left corner of the page you will see the download tab (you can choose between 2D dxf or dwg, PDF, Solidworks and also 3D models in various formats)
    Nope, my glasses must be faulty as I still can't see anything in the left column after going thru to a particular thread.

    All I have in the left column is:

    ----------------------------------------------------------




    97048A725 Metric Steel Acme Threaded Rod M26, 2 Meter Length, 5 mm Pitch In stock at $116.19 Each

    Each

    Bookmark this Product
    WriteAHref("PartNbrLinks", "Catalog Page", "McMMain", "View catalog page for this product.", "/nav/enter.asp?pagetype=itmlookupctlg&reqtyp=catalog&Ct lgPgNbr=3099&sesnextrep=696900466574956&CtlgEditio n=113&k1=97048A725&t1=PN", "/nav/framework.asp?reqtyp=catalog&CtlgPgNbr=3099&sesnex trep=696900466574956&CtlgEdition=113&k1=97048A725& t1=PN") Catalog Page Current Order - 0 lines

    ---------------------------------------------------------

    Obviously I'm just going mad!



    ===EDIT===

    Just noticed that past I did above came out a bit messy
    Will do a screen grab after lunch.

  6. #6
    Super Member riga's Avatar
    Using
    AutoCAD 2007
    Join Date
    May 2007
    Location
    Switzerland
    Posts
    723

    Default

    I guess not all products have a technical draw to download.
    Sorry mate
    HAVE A NICE DAY

  7. #7
    Full Member Tempest's Avatar
    Using
    AutoCAD 2007
    Join Date
    Oct 2007
    Location
    Horley (Gatwick) UK
    Posts
    99

    Default

    Quote Originally Posted by riga View Post
    I guess not all products have a technical draw to download.
    Sorry mate
    I just wondered if it was me missing something.
    I've clicked through a few items and not found any drawings yet. So still unsure if it's me being dim, or (as you say) there are only drawings for certain select items.

    But, that to one side, on the making a 2D thread.
    If I draw 1 pitch of a thread, is there an easy way to create extra pitch's next to each other?

    Basically, I'm taking about drawing say 1 box, then using AutoCAD to create another 20 boxes in one long line, all touching each other.

  8. #8
    Super Moderator Cad64's Avatar
    Computer Details
    Cad64's Computer Details
    Operating System:
    Windows 7 Profesional x64
    Computer:
    XI Computers
    Motherboard:
    Asus P8Z77-V Pro
    CPU:
    Intel Core I7 3770K 4.1 Ghz Quad Core 3rd Gen
    RAM:
    8GB DDR3 @ 1333MHz
    Graphics:
    Nvidia GeForce GTX 570 1280MB GDDR5
    Primary Storage:
    SATAII 500GB 7200 RPM
    Secondary Storage:
    Western Digital My Book Studio Edition II - 2TB capacity
    Monitor:
    HPf2105 21" LCD Widescreen & Cintiq 21ux
    Discipline
    Multi-disciplinary
    Cad64's Discipline Details
    Occupation
    Freelance Digital Artist
    Discipline
    Multi-disciplinary
    Details
    In a nutshell, I create 3D models from the client's CAD files or design sketches which I then use to produce high quality rendered images. Click on the link in my signature to view my portfolio. I'm always looking for work, so let me know if you need any custom models or renders. :)
    Using
    3ds Max 2011
    Join Date
    Feb 2006
    Location
    Southern California
    Posts
    8,910

    Default

    If you need to just create a simple 2D representation of screw threads, try the ARRAY command. Draw the profile of your thread and create the first thread, upper and lower, with the lower thread offset half the distance from the upper.

    Now start the ARRAY command and pick "Rectangular Array".
    Rows = 1
    Columns = Depends on how long your screw will be
    Select Objects Button = Select all the green lines to include in the Array
    Row Offset = 1
    Column Offset = To set the Column Offset, click the "Pick Column Offset" button and then select the two points shown in the image below.
    Angle of Array = 0
    Attached Images
    Freelance Digital Artist
    Personal Website: ( Updated 03/21/2014 ) --->
    http://www.rdeweese.com/

    "Work Smart, Not Hard"

  9. #9
    Super Moderator Cad64's Avatar
    Computer Details
    Cad64's Computer Details
    Operating System:
    Windows 7 Profesional x64
    Computer:
    XI Computers
    Motherboard:
    Asus P8Z77-V Pro
    CPU:
    Intel Core I7 3770K 4.1 Ghz Quad Core 3rd Gen
    RAM:
    8GB DDR3 @ 1333MHz
    Graphics:
    Nvidia GeForce GTX 570 1280MB GDDR5
    Primary Storage:
    SATAII 500GB 7200 RPM
    Secondary Storage:
    Western Digital My Book Studio Edition II - 2TB capacity
    Monitor:
    HPf2105 21" LCD Widescreen & Cintiq 21ux
    Discipline
    Multi-disciplinary
    Cad64's Discipline Details
    Occupation
    Freelance Digital Artist
    Discipline
    Multi-disciplinary
    Details
    In a nutshell, I create 3D models from the client's CAD files or design sketches which I then use to produce high quality rendered images. Click on the link in my signature to view my portfolio. I'm always looking for work, so let me know if you need any custom models or renders. :)
    Using
    3ds Max 2011
    Join Date
    Feb 2006
    Location
    Southern California
    Posts
    8,910

    Default

    You will end up with something like what's pictured below. You will of course have to manually draw in the half threads at the beginning and the end of the screw.

    Hope that helps.
    Attached Images
    Freelance Digital Artist
    Personal Website: ( Updated 03/21/2014 ) --->
    http://www.rdeweese.com/

    "Work Smart, Not Hard"

  10. #10
    Full Member Tempest's Avatar
    Using
    AutoCAD 2007
    Join Date
    Oct 2007
    Location
    Horley (Gatwick) UK
    Posts
    99

    Default

    Registered forum members do not see this ad.

    Quote Originally Posted by Cad64 View Post
    If you need to just create a simple 2D representation of screw threads, try the ARRAY command. Draw the profile of your thread and create the first thread, upper and lower, with the lower thread offset half the distance from the upper.

    Now start the ARRAY command and pick "Rectangular Array".
    Rows = 1
    Columns = Depends on how long your screw will be
    Select Objects Button = Select all the green lines to include in the Array
    Row Offset = 1
    Column Offset = To set the Column Offset, click the "Pick Column Offset" button and then select the two points shown in the image below.
    Angle of Array = 0
    Fantastic.
    Many thanks for the excellent explanation. I've yet to use the ARRAY command, and this will be the ideal time to.

    Thanks for spending the time to post such an excellent description.
