    Hi everyone. I just recently started working for a fairly new company doing drafting work. However, being that this is a new company, they have almost no CAD standards in place. This is cool cause I pretty much get to set them, but I'm having trouble coming up with a decent title block. I'm unfortunately limited to 11x17 at the moment, and work in a hybrid Architectural / Mechanical industry. Outside of the standard title blocks that come with AutoCAD... and Google... are there any good places to look for title block templates? Thanks!
