    Default Drawing curves on a road.

    Registered forum members do not see this ad.

    I read a few threads on splines, plines and arcs, but still can't get the results I'm looking for. I'm trying to draw a road with known dimensions. How do I draw the curves? Do I use spline, pline or arc?

  2. #2
    Forum Deity
    Using
    Civil 3D 2008
    Join Date
    Sep 2006
    Location
    Pittsburgh, PA, USA
    Posts
    3,581

    Default

    Unless you need a spiral, draw 2 tangents (lines or plines) and use the fillet command for the correct radius.

  3. #3
    Quantum Mechanic ReMark's Avatar
    Computer Details
    ReMark's Computer Details
    Operating System:
    Windows 7 Pro 64-bit
    Computer:
    Thinkmate
    Motherboard:
    Intel DX58SO2 LGA1366 X58
    CPU:
    Intel i7-960 Quad-core 3.20GHz 8MB cache
    RAM:
    12GB (3x4GB) PC3-106000 DDR3
    Graphics:
    nVidia Quadro 4000, 2GB GDDR5
    Primary Storage:
    150GB Velocipraptor 10,000 rpm
    Secondary Storage:
    none
    Monitor:
    Dell P24LLH - 24" wide screen LCD
    Discipline
    See details...
    ReMark's Discipline Details
    Occupation
    CAD Draftsman/Designer...chemical manufacturing.
    Discipline
    See details below.
    Details
    I work for a specialty chemical manufacturer. I do a little bit of everything from P&IDs to civil to architectural and structural.
    Using
    AutoCAD 2015
    Join Date
    Nov 2005
    Location
    Norwalk, CT USofA
    Posts
    40,192

    Default

    How would you draw the curves if you were doing it on a drafting board instead of using CAD? Since you should have all the curve data it should be a no brainer.
    "I have only come here seeking knowledge. Things they wouldn't teach me of in college." The Police

    Eat brains...gain more knowledge!

    I'm now a full member of the Society for the Promotion of Mediocrity in CAD. Standards? We don't need no stinkin' standards! Take whatever advice I offer and do the opposite.

  4. #4
    Full Member
    Using
    AutoCAD LT 2002
    Join Date
    Jun 2006
    Location
    Tampa, Florida
    Posts
    60

    Default

    I'm trying to recreate a roadway drawing that was given to me. All I had to do was put boring symbols over the drawing. I've never used a drafting board and I'm teaching myself CAD. I'm just using this drawing with dimensions on it as an exercise to get more familiar with the tools and commands. I tried using the fillet command, and it gives me close to what I want, but it starts the tangent about 200' too soon. I'll have to move every curve that I make over to the right.



    I basically have a stretch of road that is 900' long and goes into a curve approx. 600' long with a radius of 858.75'.

  5. #5
    Forum Deity
    Using
    not specified
    Join Date
    Jul 2004
    Location
    Anchorage, Alaska
    Posts
    2,074

    Default

    Learning curve geometry would help you draw this. To get curve to start at the end of the line, offset the centerline by the radius (858.75'), use the end of the offset line to draw a circle. Trim circle to create centerline curve. Adjust length with "lengthen" command.

  6. #6
    Quantum Mechanic ReMark's Avatar
    Computer Details
    ReMark's Computer Details
    Operating System:
    Windows 7 Pro 64-bit
    Computer:
    Thinkmate
    Motherboard:
    Intel DX58SO2 LGA1366 X58
    CPU:
    Intel i7-960 Quad-core 3.20GHz 8MB cache
    RAM:
    12GB (3x4GB) PC3-106000 DDR3
    Graphics:
    nVidia Quadro 4000, 2GB GDDR5
    Primary Storage:
    150GB Velocipraptor 10,000 rpm
    Secondary Storage:
    none
    Monitor:
    Dell P24LLH - 24" wide screen LCD
    Discipline
    See details...
    ReMark's Discipline Details
    Occupation
    CAD Draftsman/Designer...chemical manufacturing.
    Discipline
    See details below.
    Details
    I work for a specialty chemical manufacturer. I do a little bit of everything from P&IDs to civil to architectural and structural.
    Using
    AutoCAD 2015
    Join Date
    Nov 2005
    Location
    Norwalk, CT USofA
    Posts
    40,192

    Default

    Registered forum members do not see this ad.

    I agree with CarlB about learning horizontal curve geometry.

    The curve "starts" at what is called the PC or point of curvature and ends at the PT or point of tangency. You'll need to know the delta or angle of the curve and the radius. You can compute the tangent distance, curve length and chord distance if it hasn't been supplied.

    To learn more about horizontal curves just pick up a book about surveying or "Google" the term.
