    Default Hidden Line dash sizes...

    Registered forum members do not see this ad.

    How do I decrease the dash size of my hidden line layer? When I goto to finish everything up in layout 1 my hidden lines are so big that on certain parts of the model it appears as just a solid green line.

    I am using autocad 2008, and I created my viewports using the solview command, then used the soldraw command to create a 2d drawing of the model. Thanks.

  2. #2
    Junior Member
    Using
    AutoCAD 2008
    Join Date
    Apr 2008
    Posts
    16

    Default

    Nevermind, just found the command, like right after I posted this, haha. LTSCALE, while in the layer that you want to change, in case anyone else wanted to know.

  3. #3
    Banned Alan Cullen's Avatar
    Using
    Map 3D 2009
    Join Date
    Jun 2006
    Location
    Cairns, Queensland, Australia
    Posts
    4,181

    Default

    Another variable you may like to investigate related to this is PSLTSCALE.

  4. #4
    Junior Member
    Using
    AutoCAD 2008
    Join Date
    Apr 2008
    Posts
    16

    Default

    thanks for the tip!

  5. #5
    Super Member rustysilo's Avatar
    Computer Details
    rustysilo's Computer Details
    Operating System:
    WinXP
    Discipline
    Civil
    rustysilo's Discipline Details
    Occupation
    Senior CAD Draftsman
    Discipline
    Civil
    Using
    Civil 3D 2008
    Join Date
    Jul 2007
    Location
    Jacksonville, FL - USA
    Posts
    1,458

    Default

    Registered forum members do not see this ad.

    And you can also add more hidden/dashed styles in your linetype file (acad.lin). I have a hidden, hidden2, hidden3, hidden4, and hidden5 added to mine with varying lengths and spaces between. If you're good you can even make them to come out at a scale for applications such as centerline striping.
