    Question Perpendicular lines

    Registered forum members do not see this ad.

    Hi to all!

    I'm new to AutoCad and I get better every time I use it. And yes there will always be questions and I came upon this site by chance and I'm glad I did.

    Simple question: how do you draw a perpendicular line to a line on any angle other than in ORTHO? I've looked in this site and in my AutoCad for Dummies book with no results, any advise would greatly be appreciated.

    Thanks Frank

  2. #2
    Super Moderator Strix's Avatar
    Using
    not applicable
    Join Date
    Nov 2005
    Location
    Sheffield UK
    Posts
    3,074

    Default

    hi, and welcome to the CADTutor forum

    there are an assortment of ways, depending on what you're aiming to achieve

    you can draw a line perpendicular to another by selecting the start point away from the line, selecting the 'perpendicular' point snap and selecting the line you wish to be perpendicular to

    you can use a similar method by setting your OSNAPS to include 'perpendicular', begin your line, select the line you wish to be perpendicular to, then tab through the available osnaps until the perpendicular symbol appears

    if you wish to draw perpendicular from... somebody else will have to tell you how to do it
    Find your new best friend at Rain Rescue

    If you are a good drafter, tech will help. If you are a bad drafter, nothing will help. - Jack_O'neill at CADTutor

  3. #3
    Senior Member rgarjr's Avatar
    Computer Details
    rgarjr's Computer Details
    Operating System:
    Windows 7 64 bit
    Computer:
    Apple iMac
    CPU:
    3.06GHz C2D
    RAM:
    4GB
    Graphics:
    Radeon 4850
    Primary Storage:
    Hitachi 640GB
    Monitor:
    iMac 24"
    Using
    AutoCAD 2010
    Join Date
    Jan 2008
    Location
    Los Angeles Area, CA
    Posts
    166

    Default

    There's always polar tracking.

  4. #4
    Super Member
    Computer Details
    Dipali's Computer Details
    Operating System:
    windows vista
    Computer:
    IBM Thinkpad lenovo
    CPU:
    Intel Centrino vPro
    Monitor:
    viewsonicVA1916w
    Discipline
    Architectural
    Dipali's Discipline Details
    Occupation
    ARCHITECTURE
    Discipline
    Architectural
    Details
    interiors
    Using
    AutoCAD 2009
    Join Date
    Dec 2007
    Location
    INDIA
    Posts
    1,077

    Default

    keep 'polar' & 'otrack' both on in your tile boar at the bottom of the drawing screen.
    "An architect's most useful tools are an eraser at the drawing board & a wrecking bar at the site."
    Frank Lloyd Wright

  5. #5
    Quantum Mechanic ReMark's Avatar
    Computer Details
    ReMark's Computer Details
    Operating System:
    Windows 7 Pro 64-bit
    Computer:
    Thinkmate
    Motherboard:
    Intel DX58SO2 LGA1366 X58
    CPU:
    Intel i7-960 Quad-core 3.20GHz 8MB cache
    RAM:
    12GB (3x4GB) PC3-106000 DDR3
    Graphics:
    nVidia Quadro 4000, 2GB GDDR5
    Primary Storage:
    150GB Velocipraptor 10,000 rpm
    Secondary Storage:
    none
    Monitor:
    Dell P24LLH - 24" wide screen LCD
    Discipline
    See details...
    ReMark's Discipline Details
    Occupation
    CAD Draftsman/Designer...chemical manufacturing.
    Discipline
    See details below.
    Details
    I work for a specialty chemical manufacturer. I do a little bit of everything from P&IDs to civil to architectural and structural.
    Using
    AutoCAD 2015
    Join Date
    Nov 2005
    Location
    Norwalk, CT USofA
    Posts
    39,996

    Default

    You can use the SNAPANG function to set your crosshairs to match a line that is at an angle other exactly horizontal or vertical. Then you can draw a line perpendicular to or from that line. Reset your crosshairs back to "0" using SNAPANG again.
    "I have only come here seeking knowledge. Things they wouldn't teach me of in college." The Police

    Eat brains...gain more knowledge!

    I'm now a full member of the Society for the Promotion of Mediocrity in CAD. Standards? We don't need no stinkin' standards! Take whatever advice I offer and do the opposite.

  6. #6
    Forum Newbie FCspecial's Avatar
    Using
    AutoCAD 2004
    Join Date
    Jun 2008
    Location
    Queens NY
    Posts
    2

    Smile

    Thank you for the heads up

    Your advise did help

  7. #7
    Junior Member Stangman's Avatar
    Using
    AutoCAD 2007
    Join Date
    Feb 2008
    Location
    Iowa, US
    Posts
    19

    Default

    Registered forum members do not see this ad.

    If you want to go perpendicular from a line or object you need to hold Shift+Right click or CTRL+Right click and choose Perpendicular snap. Then choose a starting point.

    If you want to end up perpendicular to an object you'll need to do those same steps; however, instead pick a starting point first, and then choose the Perp. Snap before picking an end point.

    In drafting, I don't like to rely simply on my polar tracking to go perpendicular to something that isn't either horizontal, vertical, or 45 degrees, because you just never know if its exact. You could be off by only a fraction of a degree, but that build up of error could end up being several feet off for very large distances.
