Metric scaling muddle


JamFam

Recommended Posts

Greetings everyone. My problem has to do with plotting (printing) to a metric scale accurately. I have a drawing in model space that is 4200mm wide by 1870mm high. I have set the Paper size to A4 (because I am printing a metric image onto an 8 1/2" x 11") piece of standard paper. When I scale within plot settings the plotted (printed) image does not come printed at the desired scale, in this case 1:20. What am I doing wrong and what settings must I check to fix this problem?.

The finished plot is not to any metric scale. When in Layout1 I can see the image and it is completely within the layout1 viewport, taking up the top half of the sheet of paper. It doesn't seem to change.



PLEASE HELP, I AM WORKING ON DRAWINGS THAT MUST BE TO SCALE!!



Thanks.

Link to comment
Share on other sites

You have to set your Viewport scale. I haven't used Autocad 2000 in many, many years, so I can't tell you exactly how or where to do it, but you should be able to set it from within your Properties palette.



I have moved your question to the Autocad "Beginners" section. You posted in the 3DS Max section.

Link to comment
Share on other sites

CAD64, thanks for the assistance. You were right in how to correct my problem. I have an Autocad 2000 manual, but because I didn't know what the problem was I didn't know where to look for help, but because you mentioned Viewport scale I looked up Viewport, scale and the step by step was there, thanks. Now when I put my scale ruler to my drawings I can be assured that they are in fact to scale and thanks for moving my post to "Beginners", I'm not sure how my post got here.



A multitude of gratitude



JamFam

Link to comment
Share on other sites
