    Default Text Rotates back to original UCS when printing from Paperspace

    Registered forum members do not see this ad.

    Hello all,

    I have an AutoCAD 2000 basemap drawing which has several referenced drawings. In the basemap a new UCS was created which changed the base point and the rotation. I then referenced these other drawings which had the same coordinate system as the new UCS. Everthing was fine until I printed my layouts. The text in some of the referenced drawings, not all, reverts back to the rotation of the previous UCS when I go to print it. The first sign of this problem is in print preview, everthing looks fine in paperspace. Is there anyway to resolve this problem without starting from scratch with dview or other commands?

    Thanks for any help you can provide.

  2. #2
    Super Moderator Cad64's Avatar
    Computer Details
    Cad64's Computer Details
    Operating System:
    Windows 7 Profesional x64
    Computer:
    XI Computers
    Motherboard:
    Asus P8Z77-V Pro
    CPU:
    Intel Core I7 3770K 4.1 Ghz Quad Core 3rd Gen
    RAM:
    24GB DDR3 @ 1333MHz
    Graphics:
    Nvidia GeForce GTX 570 1280MB GDDR5
    Primary Storage:
    SATAII 500GB 7200 RPM
    Secondary Storage:
    Western Digital My Book Studio Edition II - 2TB capacity
    Monitor:
    HPf2105 21" LCD Widescreen & Cintiq 21ux
    Discipline
    Multi-disciplinary
    Cad64's Discipline Details
    Occupation
    Freelance Digital Artist
    Discipline
    Multi-disciplinary
    Details
    3D model building, texturing and rendering. Photoshop Color Graphics.
    Using
    AutoCAD 2014
    Join Date
    Feb 2006
    Location
    Southern California
    Posts
    10,139

    Default

    Can you post some screenshots of paper space and your print preview so we can see what's happening? I'm not really sure I follow you?
    CGSociety Portfolio: http://rdeweese.cgsociety.org/
    Facebook:
    https://www.facebook.com/rdeweese67/


    "Work Smart, Not Hard"

  3. #3
    Full Member
    Using
    Map 3D 2013
    Join Date
    Nov 2008
    Posts
    49

    Default Screenshots

    Quote Originally Posted by Cad64 View Post
    Can you post some screenshots of paper space and your print preview so we can see what's happening? I'm not really sure I follow you?
    [IMG]file:///C:/Documents%20and%20Settings/HGI/Desktop/Printscreen%20-%20plot%20preview.jpg[/IMG][IMG]file:///C:/Documents%20and%20Settings/HGI/Desktop/Printscreen%20-%20paperspace.jpg[/IMG]
    [IMG]file:///C:/Documents%20and%20Settings/HGI/Desktop/Printscreen%20-%20plot%20preview.jpg[/IMG][IMG]file:///C:/DOCUME%7E1/HGI/LOCALS%7E1/Temp/moz-screenshot.jpg[/IMG]Printscreen - paperspace.jpg
    Printscreen - plot preview.jpg

    Here are screen shots of the paperspace and then the plot preview. Notice that the 500 and 550 text are not changed, but the 2 and 4 text are rotated. For some reason they are rotated back to the original UCS. Both of the groups of text were externally referenced in the same fashion, both were dropped into the new UCS I created.

    I have no idea what is going on.
    Attached Images

  4. #4
    Full Member
    Using
    Map 3D 2013
    Join Date
    Nov 2008
    Posts
    49

    Default Answer

    Registered forum members do not see this ad.

    To any people with this similar problem in the future, the answer is simple, make sure you are up to date with your service packs and patches. I installed Service Pack 1 and Service Pack 2 along with a Plotting Patch and a 3D fix. I am not sure which Service Pack or Plotting Patch fixed the problem, but it is now gone. Here is the address with all of the downloads:

    http://usa.autodesk.com/adsk/servlet...40618#section9

    Good Luck
