    AutoCAD multiple scales in one dwg

    Registered forum members do not see this ad.

    Some time I have to check multiple scales in one dwg.
    i.e. one dwg / one model dwg and 4 to 6 layout with different scales and dimension.

    1. How is the best way to check the standard scale dimension?
    in multiple layout ?
    2. If model scale changes it will affect the layout different scale?

    Regards
    Muhammad
    AutoCAD 2008


  2. #2
    Quantum Mechanic ReMark's Avatar
    Computer Details
    ReMark's Computer Details
    Operating System:
    Windows 7 Pro 64-bit
    Computer:
    Thinkmate
    Motherboard:
    Intel DX58SO2 LGA1366 X58
    CPU:
    Intel i7-960 Quad-core 3.20GHz 8MB cache
    RAM:
    12GB (3x4GB) PC3-106000 DDR3
    Graphics:
    nVidia Quadro 4000, 2GB GDDR5
    Primary Storage:
    150GB Velocipraptor 10,000 rpm
    Secondary Storage:
    none
    Monitor:
    Dell P24LLH - 24" wide screen LCD
    Discipline
    See details...
    ReMark's Discipline Details
    Occupation
    CAD Draftsman/Designer...chemical manufacturing.
    Discipline
    See details below.
    Details
    I work for a specialty chemical manufacturer. I do a little bit of everything from P&IDs to civil to architectural and structural.
    Using
    AutoCAD 2015
    Join Date
    Nov 2005
    Location
    Norwalk, CT USofA
    Posts
    40,109

    Default

    Objects in model space should ALWAYS be drawn FULL size. NEVER change the scale of objects in model space if you have a layout or layouts with different scales. You're only asking for trouble.
    "I have only come here seeking knowledge. Things they wouldn't teach me of in college." The Police

    Eat brains...gain more knowledge!

    I'm now a full member of the Society for the Promotion of Mediocrity in CAD. Standards? We don't need no stinkin' standards! Take whatever advice I offer and do the opposite.

  3. #3
    Forum Deity rkent's Avatar
    Computer Details
    rkent's Computer Details
    Operating System:
    WIN7 PRO 64bit
    Computer:
    Dell Precision T7500
    CPU:
    Xeon Dual Core E5503 2.0Ghz
    RAM:
    6GB DDR3 ECC SDRAM, 1333MHz, 6x1GB
    Graphics:
    nVidia Quadro 3800
    Primary Storage:
    Samsung 480Gb SSD
    Monitor:
    Dell 24" FS (2x)
    Discipline
    Mechanical
    rkent's Discipline Details
    Occupation
    Facilities Design - Semi-conductor manufacturing
    Discipline
    Mechanical
    Details
    Designer: Process Piping, P&ID's, Machine Part Design, Planning / General Arrangement. Facilities Management. Drafting: Electrical, Controls, Architectural.
    Using
    Mechanical 2014
    Join Date
    Nov 2007
    Location
    Lat:35, Long:-106, Elev: 5164'
    Posts
    3,977

    Default

    Registered forum members do not see this ad.

    You could use Field,Object, select viewport, standard scale, place near viewport. Do this on a non-plotting layer. As the viewport scale changes the field will update, usually after a regen.

    Otherwise simply dbl click inside a viewport, look down at the anno scale. Use properties, etc.
