    Default how to draw horizontal railing

    [IMG]file:///C:/DOCUME%7E1/HUMAIR%7E1.KHA/LOCALS%7E1/Temp/moz-screenshot.jpg[/IMG]I drawn a spiral stairs, in which i can't draw a horizontal railing.

    pls help me to draw it....
    Attached Images

  2. #2
    Super Moderator fuccaro's Avatar
    Using
    AutoCAD 2006
    Join Date
    Nov 2002
    Location
    Romania, Marosvasarhely
    Posts
    3,543

    Default

    Draw a helix throu the ends of the vertical bars and extrude a circle along it.
    Your profile says that you use AutoCAD 2006 (nice image for 2006!)
    In AutoCAD 2006 there is no Helix command but there a re a lot of Lisp routines helping you to draw one -you may searc the internet or even this forum, in the AutoLisp section.
    Post again if you ned more help.
    It's nice to be nice, but sometimes is nicer to be evil!.
    Tip: Please do not PM or email me with CAD questions - use the forums, you'll get an answer sooner.

  3. #3
    Forum Deity shift1313's Avatar
    Using
    not applicable
    Join Date
    Sep 2008
    Location
    VA
    Posts
    2,859

    Default

    thats exactly the way i would do it as well. since you have a center snap point on each hand rail just use the SPLINE command and snap to each center point. Then draw your rail profile at the start of your handrail. EXTRUDE>Path.
    Matt - Certified Solidworks Expert -Advanced Surfacing, Mold Tool and Sheet Metal Specialist
    Current Software: SolidWorks11,SolidCam11
    http://www.solidworkslessons.info/
    www.mysolidbox.com

  4. #4
    Super Moderator fuccaro's Avatar
    Using
    AutoCAD 2006
    Join Date
    Nov 2002
    Location
    Romania, Marosvasarhely
    Posts
    3,543

    Default

    Can you extrude along a spline? -Unfortunately I can not test it right now.
    It's nice to be nice, but sometimes is nicer to be evil!.
    Tip: Please do not PM or email me with CAD questions - use the forums, you'll get an answer sooner.

  5. #5
    Forum Deity shift1313's Avatar
    Using
    not applicable
    Join Date
    Sep 2008
    Location
    VA
    Posts
    2,859

    Default

    you can but there are restrictions with the ucs. I dont recall exactly what they are pre07. 07+ doesnt have an issue with it but i know ive done this in 05.
    Matt - Certified Solidworks Expert -Advanced Surfacing, Mold Tool and Sheet Metal Specialist
    Current Software: SolidWorks11,SolidCam11
    http://www.solidworkslessons.info/
    www.mysolidbox.com

  6. #6
    Full Member
    Using
    AutoCAD 2010
    Join Date
    Jan 2009
    Posts
    50

    Default

    Ya....i did it...by spline...

    thanks...shift1313


    its cool to use spline command.
    Attached Images

  7. #7
    Super Moderator fuccaro's Avatar
    Using
    AutoCAD 2006
    Join Date
    Nov 2002
    Location
    Romania, Marosvasarhely
    Posts
    3,543

    Default

    Nice! I can not wait to see the whole building!
    It's nice to be nice, but sometimes is nicer to be evil!.
    Tip: Please do not PM or email me with CAD questions - use the forums, you'll get an answer sooner.

  8. #8
    Forum Deity shift1313's Avatar
    Using
    not applicable
    Join Date
    Sep 2008
    Location
    VA
    Posts
    2,859

    Default

    Quote Originally Posted by humaironline View Post
    Ya....i did it...by spline...

    thanks...shift1313


    its cool to use spline command.

    glad it worked out for you! How are you going to end the hand rails? some sort of decorative end? if you need to you can use the Solidedit>face>extrude and add a little extra to the ends. it will be a straight extrusion but it will allow you to trim off the ends vertical with your supports.
    Matt - Certified Solidworks Expert -Advanced Surfacing, Mold Tool and Sheet Metal Specialist
    Current Software: SolidWorks11,SolidCam11
    http://www.solidworkslessons.info/
    www.mysolidbox.com

  9. #9
    Super Moderator fuccaro's Avatar
    Using
    AutoCAD 2006
    Join Date
    Nov 2002
    Location
    Romania, Marosvasarhely
    Posts
    3,543

    Default

    Registered forum members do not see this ad.

    That "extruded end" can be also curved. If you draw an arc tangent to the helix you can extrude the ending cap along it. Here is what I mean:
    It's nice to be nice, but sometimes is nicer to be evil!.
    Tip: Please do not PM or email me with CAD questions - use the forums, you'll get an answer sooner.
