    Drawing IFC file exported from revit

    Registered forum members do not see this ad.

    Does any one have an IFC file exported from Revit as we're trying to see how it reads in Autocad MEP 2010?

  2. #2
    Full Member
    Using
    Revit 2009
    Join Date
    Jan 2009
    Posts
    42

    Default

    Not sure why you would need a file xported to ifc from Revit to use in a MEP file. Why not just link them?
    Why not export an IFC file form MEP and then import back into MEP?

    I think I might be missing somethig here.

  3. #3
    Junior Member
    Using
    AutoCAD 2011
    Join Date
    Feb 2009
    Location
    London, UK
    Posts
    20

    Default

    We are going to be sent 3d models from Revitt by a client and I just wondered how it would open in AutoCAD MEP?

  4. #4
    Junior Member
    Computer Details
    qbi's Computer Details
    Operating System:
    VISTA64, XP
    Using
    Revit 2010
    Join Date
    Dec 2008
    Location
    Kraków
    Posts
    23

    Default

    @ARCHdoc You cannot link REVIT file into ACAD MEP file? If yes, please show me how ?

    @_E_ About the IFC file, it is easy to export IFC from revit, and it is easy to use it in ACAd MEP. We are doing this way for design purposes, but for presentation it is better to use for example NavisWorks
    Jakub Pekala
    AIO
    Tech

    All-IN-ONE Technology

  5. #5
    Luminous Being tzframpton's Avatar
    Computer Details
    tzframpton's Computer Details
    Computer:
    Custom built rig
    Discipline
    Multi-disciplinary
    tzframpton's Discipline Details
    Occupation
    BIM Specialist
    Discipline
    Multi-disciplinary
    Details
    Facilities engineering, involving mechanical piping, mechanical HVAC, electrical and structural engineering.
    Using
    Revit 2014
    Join Date
    Mar 2006
    Location
    Dallas, TX - USA
    Posts
    7,433

    Default

    IFC will work perfectly fine. Or you can just export as DWG too. Either way it'll work.

  6. #6
    Junior Member
    Using
    AutoCAD 2010
    Join Date
    Oct 2009
    Posts
    14

    AutoCAD

    When an IFC file is created in Revit architecture and then imported into Autocad MEP is the project manager automatically set up with xrefs etc?

  7. #7
    Luminous Being tzframpton's Avatar
    Computer Details
    tzframpton's Computer Details
    Computer:
    Custom built rig
    Discipline
    Multi-disciplinary
    tzframpton's Discipline Details
    Occupation
    BIM Specialist
    Discipline
    Multi-disciplinary
    Details
    Facilities engineering, involving mechanical piping, mechanical HVAC, electrical and structural engineering.
    Using
    Revit 2014
    Join Date
    Mar 2006
    Location
    Dallas, TX - USA
    Posts
    7,433

    Default

    You can only Import, that's why I usually export the 3D Model as a AutoCAD DWG format. Just makes life easier it seems.

  8. #8
    Junior Member
    Using
    AutoCAD 2011
    Join Date
    Feb 2009
    Location
    London, UK
    Posts
    20

    Default

    Ok, thanks for the replys.

    So can you import a revit file and work with it or does it have to be an IFC file?

    Also DK's comment was also relevant to my situation, does the project manager automatically load the xrefs when you inport it into to MEP from Revit arch?

    Cheers

    _E_

  9. #9
    Luminous Being tzframpton's Avatar
    Computer Details
    tzframpton's Computer Details
    Computer:
    Custom built rig
    Discipline
    Multi-disciplinary
    tzframpton's Discipline Details
    Occupation
    BIM Specialist
    Discipline
    Multi-disciplinary
    Details
    Facilities engineering, involving mechanical piping, mechanical HVAC, electrical and structural engineering.
    Using
    Revit 2014
    Join Date
    Mar 2006
    Location
    Dallas, TX - USA
    Posts
    7,433

    Default

    AutoCAD files can be imported into Revit, however Revit cannot be imported into AutoCAD.

  10. #10
    Junior Member
    Using
    AutoCAD 2010
    Join Date
    Oct 2009
    Posts
    14

    Default

    Registered forum members do not see this ad.

    Revit MEP provides IFC import and fully certified export based on the latest IAI IFC2x2 data exchange standard. When you export a Revit MEP building information model to IFC format, the information can be used directly by other building specialists, such as structural and building services engineers.
    For example, building information models developed with Revit MEP are saved to the RVT file format. You can export the building model using the IFC format to an IFC-certified application that does not use the RVT file format. The drawing can be opened and worked on in the non-native application. Similarly, in Revit MEP you can import an IFC file, create a RVT file, and work on the building model in Revit MEP.
    IFC uses architecturally meaningful containers to describe real-world building objects. Those containers include parameters that have meaningful values. Many standard Revit MEP elements have corresponding IFC containers. These do not require any specific user action to export them. (For example, Revit walls export as IFCwalls.)

    Does this help _E_?
