    Default Confusion with UCS and Planes (Inventor 10) *pic*

    Registered forum members do not see this ad.

    Hello All:

    I am confused when it comes to the User Coordinate System.

    For some reason, when i make a new drawing, i get this issue with the UCS arrows.

    http://premium1.uploadit.org/telegon80//ucs.bmp
    edit: cant hotlink the pic for some reason.

    As you can see, the drawing has two UCS icons. One of them (on the bottom left) has the Blue Arrow (Z axis i assume) pointing up at me. But the other one has it facing the side!!!!! why!!!!!

    so when i draw objects i dont know which UCS im using.

    Is there a way to change this? so that i only have one UCS icon? does anyone know WHY i have two???

    im making a details library so if i keep drawing all the parts in the wrong plane, then we're going to have to rotate every part every time we insert it into a new drawing.

    Thanks in advance for a fast response.

  2. #2
    Super Moderator Lazer's Avatar
    Computer Details
    Lazer's Computer Details
    Operating System:
    Windows 7
    Computer:
    HP xw 4600 Workstation
    CPU:
    Intel Core2 Duo, 3 Gig
    RAM:
    8GB
    Graphics:
    NVIDEA Quadro FX 1700
    Primary Storage:
    2TB
    Secondary Storage:
    Portable TB drive
    Monitor:
    Samsung SyncMaster 226
    Discipline
    Mechanical
    Lazer's Discipline Details
    Occupation
    2d and 3d Cad Engineer
    Discipline
    Mechanical
    Details
    Mechanical Designer using Autocad and Inventor
    Using
    Inventor 2015
    Join Date
    Aug 2005
    Location
    Northants, England
    Posts
    1,687

    Default

    I use Inventor 10 at college and i dont have 2 UCS arrows,just 1.

    Can i quess what u mean is EACH MODEL has a different UCS, i.e you have problem like when u want to view the top it goes to the bottom when u want to view the left it goes to the right, or when u insert or open a new model the UCS is different every time? if this is the case then i can help as its a simple matter of making sure your in the right view before you begin to sketch and save.

    not sure if i have helped???
    USING AUTOCAD 2015 AND INVENTOR 2015, ALIAS 2015 SHOWCASE 2015.

    If in doubt scale and don't ask!



  3. #3
    Junior Member Crompton's Avatar
    Using
    AutoCAD 2002
    Join Date
    May 2008
    Posts
    20

    Default

    how do you change the UCS because i think this is my problem answer as well?

    I am a bit of a newbie with inventor so be gentle. Plus using old version 7.

    Thanks
    David

  4. #4
    Luminous Being JD Mather's Avatar
    Using
    Inventor 2015
    Join Date
    Sep 2007
    Location
    Williamsport, PA
    Posts
    8,541

    Default

    Registered forum members do not see this ad.

    Quote Originally Posted by Bloodwig80 View Post
    I am confused.....
    This is the AutoCAD forum.

    Quote Originally Posted by Bloodwig80 View Post
    http://premium1.uploadit.org/telegon80//ucs.bmp
    edit: cant hotlink the pic for some reason. .....
    JPG files are much smaller than bmp files. You can do a screen capture by hitting the Print Screen key in upper right corner of keyboard and then past in an image editing software like MSPaint (which is installed on virtually every Windows OS). You can then attach the jpg directly to your post.

    Quote Originally Posted by Bloodwig80 View Post
    ...parts in the wrong plane, then we're going to have to rotate every part every time we insert it into a new drawing.
    You can select any of the base workplanes to start your model (you don't have to accept the default). You can change the behavior in Tools>Application Options>

    I have never had to fool with the coordinate system since starting with Inventor v7 or Solidworks v2001.

    rgb=xyz
    r=red
    g=green
    b=blue
    Certified SolidWorks Professional
    Autodesk Inventor 2014 Certified Professional
    Autodesk AutoCAD 2013 Certified Professional
    http://home.pct.edu/~jmather/content..._Tutorials.htm
