DaMieN Posted October 2, 2009 Share Posted October 2, 2009 Hi all.. I've got a problem about tapered holes and threads. I created a (ISO) M6 tapered hole on a surface of part 1. Then I created another part (part 2) which is a simply a bolt that has threads of ISO M6. Finally i try to make an assembly with them. But my problem had started there. After defining constraints, i did an "Interference Analyze"; and found out that there is an interference between threaded surfaces of part 1 and part 2. Is it normal or i'm making a mistake while defining constraints.. Hope you help me: ] Thanks.. Quote Link to comment Share on other sites More sharing options...
ReMark Posted October 3, 2009 Share Posted October 3, 2009 Sounds like something Inventor guru J.D.Mather might be able to assist you with. Let me give this thread a "bump". Perhaps he'll see it. Quote Link to comment Share on other sites More sharing options...
MarkFlayler Posted October 3, 2009 Share Posted October 3, 2009 When the Hole is modeled it uses the Minor Diameter of the hole for representation. When you modeled your bolt it was probably major diameter. This interference is normal to show engagement of threads. If you wish to change this method you can go to your part templates' document settings and change the setting on the model tab for Hole diameter creation. Quote Link to comment Share on other sites More sharing options...
ReMark Posted October 3, 2009 Share Posted October 3, 2009 Thanks Mark for taking a look at this question. Quote Link to comment Share on other sites More sharing options...
DaMieN Posted October 3, 2009 Author Share Posted October 3, 2009 Thank you Mark.. and damn to my limited knowledge of technical drawing : ] Quote Link to comment Share on other sites More sharing options...
