    Default Symbol for Duct Cutting section

    Registered forum members do not see this ad.

    Hi All,

    Good day to all, please if possible to have some Lisp Route that will automate to create a Rectangular DUCT Cutting Section as shown below attached image, by picking a 2 endpoints of rectang and create a shade solid hatch, similar with pipe cut (Yinyang) but on rectangular duct the shaded is on side portions only,

    advance thanks to all,
