valrecx Posted October 26, 2009 Share Posted October 26, 2009 hi guys i'm using cad for almost a year now, but still i'm not an expert. I have a problem ragarding visual styles. I can't hide the lines that is under a surface object. I made a box with a height of 100 mm and then I made a surface that is 100 mm elevated from 0,0,0 origins. But i can't hide the top of the box when i use conceptual or realistic style, And when i tried to render it i can see the color of the box from the top of the surface. Please help sorry for my english Quote Link to comment Share on other sites More sharing options...
rkent Posted October 26, 2009 Share Posted October 26, 2009 hi guys i'm using cad for almost a year now, but still i'm not an expert. I have a problem ragarding visual styles. I can't hide the lines that is under a surface object. I made a box with a height of 100 mm and then I made a surface that is 100 mm elevated from 0,0,0 origins. But i can't hide the top of the box when i use conceptual or realistic style, And when i tried to render it i can see the color of the box from the top of the surface. Please help sorry for my english I get the same thing so it is either an AutoCAD glitch or a poor video card / driver. If I move the rectangle object up or give it a thickness then the problem goes away. Quote Link to comment Share on other sites More sharing options...
rocneasta Posted October 29, 2009 Share Posted October 29, 2009 the two surfaces are overlapping each other - it's a problem that doesn't go away unless you move one object above or below, depending which object you choose. You don't have to move it by much, just a bit. plus i think you made a box, and over it you have most probably a region, that's why it's shown colored. try making a plane out of that region, see if that helps, other than that i got nothing better to say; i've been using acad for over 9 years and teaching it for 5, but i never combined solids with something else, other than a plane on which they stood. Quote Link to comment Share on other sites More sharing options...
valrecx Posted October 29, 2009 Author Share Posted October 29, 2009 Thanks for the help, i found out that the problem is my graphic card. I move the surface .5 mm up but the problem is still there. I change my 3d configuration setting on Direct 3D and the problem goes away. But my card can't support the Direct 3D too much. After a few minutes editing my drawings and then changing the visual style into conceptual, my drawing dissapeared. Hehe Maybe i need to replace my video card lol. thanks Quote Link to comment Share on other sites More sharing options...
valrecx Posted October 29, 2009 Author Share Posted October 29, 2009 i've been using acad for over 9 years and teaching it for 5, but i never combined solids with something else, other than a plane on which they stood. Sir it is only an example to show what my problem is Quote Link to comment Share on other sites More sharing options...
