    Default Vb.net Select PL AND a point

    Registered forum members do not see this ad.

    I am using the code below to get a user to select a polyline. This is working beautifully. But now I also need the point where the user clicked on the Polyline, i.e. the X and Y coordinates.
    Any Ideas?

    Dim myPEO AsNew Autodesk.AutoCAD.EditorInput.PromptEntityOptions(v bLf & "Select a Polyline:")
    myDWG = Autodesk.AutoCAD.ApplicationServices.Application.D ocumentManager.MdiActiveDocument
    myDB = myDWG.Database
    myEd = myDWG.Editor
    myPEO.SetRejectMessage("You must select a PolyLine." & vbCrLf)
    myPEO.AddAllowedClass(GetType(Autodesk.AutoCAD.DatabaseServices.Polyline), False)
    myPER = myEd.GetEntity(myPEO)
    myPS = myPER.Status
    SelectCase myPS
    Case Autodesk.AutoCAD.EditorInput.PromptStatus.OK
    'MsgBox("Good job!")
    myTransMan = myDWG.TransactionManager
    myTrans = myTransMan.StartTransaction
    myEnt = myPER.ObjectId.GetObject (Autodesk.AutoCAD.DatabaseServices.OpenMode.ForRea d)
    'MsgBox("Entity is on layer " & myEnt.Layer)
    'Where did he click?!
    Case Autodesk.AutoCAD.EditorInput.PromptStatus.Cancel
    'MsgBox("You cancelled.")
    ExitSub
    Case Autodesk.AutoCAD.EditorInput.PromptStatus.Error
    MsgBox("Error warning.")
    ExitSub
    CaseElse
    ExitSub
    EndSelect
    Last edited by Jozi68; 6th Nov 2009 at 10:29 am. Reason: Resolved

  2. #2
    Forum Deity SEANT's Avatar
    Using
    AutoCAD 2014
    Join Date
    Aug 2005
    Location
    Rhode Island
    Posts
    2,187

    Default

    Look at:
    Code:
    Autodesk.AutoCAD.EditorInput.PickPointSelectedObject
    If you set the SelectedObject returned by myPER to an instance of that class then the selection point should be available from the PickPointDescriptor of the
    Code:
    PickPointSelectedObject.PickPoint
    I’m not in a position to give that a test run, unfortunately. If the issue is still in question, I may have time this weekend.

  3. #3
    Senior Member
    Using
    Civil 3D 2012
    Join Date
    Apr 2009
    Posts
    116

    Default

    Thanx Seant, could you please give more detail? I'm not sure how to implement this.

  4. #4
    Forum Deity SEANT's Avatar
    Using
    AutoCAD 2014
    Join Date
    Aug 2005
    Location
    Rhode Island
    Posts
    2,187

    Default

    It will have to wait till later as I'm about to head out the door. Sorry.

  5. #5
    Senior Member
    Using
    AutoCAD 2007
    Join Date
    Jul 2009
    Location
    Marseille France
    Posts
    178

    Default

    Hi,

    Here's a little sample (C#)

    Code:
    using System.Windows.Forms;
    using Autodesk.AutoCAD.ApplicationServices;
    using Autodesk.AutoCAD.DatabaseServices;
    using Autodesk.AutoCAD.EditorInput;
    using Autodesk.AutoCAD.Geometry;
    using Autodesk.AutoCAD.Runtime;
    using acadApp = Autodesk.AutoCAD.ApplicationServices.Application;

    namespace PickPoint
    {
        public class Class1
        {
            [CommandMethod("Test")]
            public void Test()
            {
                Document doc = acadApp.DocumentManager.MdiActiveDocument;
                Database db = doc.Database;
                Editor ed = doc.Editor;
                PromptEntityOptions peo = new PromptEntityOptions("\nSelect a polyline: ");
                peo.SetRejectMessage("You must select a polyline\n");
                peo.AddAllowedClass(typeof(Polyline), false);
                PromptEntityResult per = ed.GetEntity(peo);
                if (per.Status == PromptStatus.OK)
                {
                    using (Transaction tr = db.TransactionManager.StartTransaction())
                    {
                        ObjectId id = per.ObjectId;
                        Point3d picked = per.PickedPoint;
                        Polyline pline = tr.GetObject(id, OpenMode.ForRead) as Polyline;
                        Point3d onPlinePt = pline.GetClosestPointTo(picked, ed.GetCurrentView().ViewDirection, false);
                        MessageBox.Show("Picked point: " + picked.ToString() +  "\nClosest point on polyline: " + onPlinePt.ToString());
                        tr.Commit();
                    }
                }
            }
        }
    }
    A VB convertion (made with a .net code converter)

    Code:
    Imports System.Windows.Forms
    Imports Autodesk.AutoCAD.ApplicationServices
    Imports Autodesk.AutoCAD.DatabaseServices
    Imports Autodesk.AutoCAD.EditorInput
    Imports Autodesk.AutoCAD.Geometry
    Imports Autodesk.AutoCAD.Runtime
    Imports acadApp = Autodesk.AutoCAD.ApplicationServices.Application

    Namespace PickPoint
        Public Class Class1
            <CommandMethod("Test")> _
            Public Sub Test()
                Dim doc As Document = acadApp.DocumentManager.MdiActiveDocument
                Dim db As Database = doc.Database
                Dim ed As Editor = doc.Editor
                Dim peo As New PromptEntityOptions(vbLf & "Select a polyline: ")
                peo.SetRejectMessage("You must select a polyline" & vbLf)
                peo.AddAllowedClass(GetType(Polyline), False)
                Dim per As PromptEntityResult = ed.GetEntity(peo)
                If per.Status = PromptStatus.OK Then
                    Using tr As Transaction = db.TransactionManager.StartTransaction()
                        Dim id As ObjectId = per.ObjectId
                        Dim picked As Point3d = per.PickedPoint
                        Dim pline As Polyline = TryCast(tr.GetObject(id, OpenMode.ForRead), Polyline)
                        Dim onPlinePt As Point3d = pline.GetClosestPointTo(picked, ed.GetCurrentView().ViewDirection, False)
                        MessageBox.Show(("Picked point: " & picked.ToString() & vbLf & "Closest point on polyline: ") + onPlinePt.ToString())
                        tr.Commit()
                    End Using
                End If
            End Sub
        End Class
    End Namespace
    Last edited by gile; 4th Nov 2009 at 03:26 pm.

  6. #6
    Forum Deity SEANT's Avatar
    Using
    AutoCAD 2014
    Join Date
    Aug 2005
    Location
    Rhode Island
    Posts
    2,187

    Default

    Gile, that is a particularly concise and direct method which appears hard to beat.

    I was hopeful that the Editor.GetSelection route would allow for additional filtering (if a person were interested in that sort of thing) but every attempt I’ve made to combine a SinglePick version of PromptEntityOptions along with SelectionFilters has crashed AutoCAD.

    That would be a fairly useful option, so I’ll keep looking.

    The example below works well enough but doesn’t bring anything new to the table.


    Code:
    Imports Autodesk.AutoCAD.Runtime
    Imports Autodesk.AutoCAD.ApplicationServices
    Imports Autodesk.AutoCAD.DatabaseServices
    Imports Autodesk.AutoCAD.EditorInput
    Imports Autodesk.AutoCAD.Geometry

    Public Class STSCCommands
        <CommandMethod("Pop")> _
     Public Sub PointOnPoly()
            Dim db As Database = HostApplicationServices.WorkingDatabase
            Dim ed As Editor = Application.DocumentManager.MdiActiveDocument.Editor
            Dim pso As PromptSelectionOptions = New PromptSelectionOptions()
            pso.MessageForAdding = "Select a Poly: "
            pso.SinglePickInSpace = True
            pso.SingleOnly = True
            Dim result As PromptSelectionResult = ed.GetSelection(pso)
            If result.Status = PromptStatus.OK And result.Value.Count > 0 Then
                Using trn As Transaction = db.TransactionManager.StartTransaction
                    Dim ppso As PickPointSelectedObject = DirectCast(result.Value(0), PickPointSelectedObject)
                    Dim poly As Polyline = TryCast(trn.GetObject(result.Value(0).ObjectId, OpenMode.ForRead), Polyline)
                    If poly IsNot Nothing Then
                        Dim p3d As Point3d = poly.GetClosestPointTo(ppso.PickPoint.PointOnLine, False)
                        ed.WriteMessage(p3d.ToString())
                    End If
                End Using
            End If
        End Sub

  7. #7
    Senior Member
    Using
    AutoCAD 2007
    Join Date
    Jul 2009
    Location
    Marseille France
    Posts
    178

    Default

    Seant,

    To mimic the Editor.GetEntiy with Editor.GetSelection it seems to me it needs:
    PromptSelectionOptions.SelectEverythingInAperture (rather than SinglePickInSpace)
    and
    PromptSelectionOptions.SingleOnly
    as the LISP expression: (ssget "_:S:E")

    Here's a C# example (works on A2007 and A2010)

    Code:
            [CommandMethod("TEST")]
            public void test()
            {
                Document doc = acadApp.DocumentManager.MdiActiveDocument;
                Database db = doc.Database;
                Editor ed = doc.Editor;
                TypedValue[] filter = { new TypedValue(0, "LWPOLYLINE") };
                SelectionFilter selFilter = new SelectionFilter(filter);
                PromptSelectionOptions pso = new PromptSelectionOptions();
                pso.MessageForAdding = "Select a polyline: ";
                pso.SelectEverythingInAperture = true;
                pso.SingleOnly = true;
                PromptSelectionResult psr = ed.GetSelection(pso, selFilter);
                if (psr.Status == PromptStatus.OK)
                {
                    using (Transaction tr = db.TransactionManager.StartTransaction())
                    {
                        ObjectId[] ids = psr.Value.GetObjectIds();
                        ObjectId id = ids[0];
                        Polyline pline = tr.GetObject(id, OpenMode.ForRead) as Polyline;
                        PickPointSelectedObject ppso = psr.Value[0] as PickPointSelectedObject;
                        Point3d picked = ppso.PickPoint.PointOnLine;
                        Point3d onPlinePt = pline.GetClosestPointTo(picked, ed.GetCurrentView().ViewDirection, false);
                        MessageBox.Show("Picked point: " +
                            picked.ToString() +
                            "\nClosest point on polyline: " +
                            onPlinePt.ToString());
                        tr.Commit();
                    }
                }
            }

  8. #8
    Forum Deity SEANT's Avatar
    Using
    AutoCAD 2014
    Join Date
    Aug 2005
    Location
    Rhode Island
    Posts
    2,187

    Default

    Gile, nicely done. The advanced filtering available from Editor.GetSelection makes that a compelling option in certain situations.

  9. #9
    Senior Member
    Using
    AutoCAD 2007
    Join Date
    Jul 2009
    Location
    Marseille France
    Posts
    178

    Default

    Just a little thing for these routines to work whatever the current UCS and current view.

    Using Editor.GetEntity,
    the PickedPoint is UCS coordinates, so have to replace :
    Code:
    Point3d picked = per.PickedPoint;
    by
    Code:
    Point3d picked = per.PickedPoint.TransformBy(ed.CurrentUserCoordinateSystem);
    and the use :
    Code:
    Point3d onPlinePt = pline.GetClosestPointTo(picked, ed.GetCurrentView().ViewDirection, false);
    Using Editor.GetSelection, it can be done this way:
    Code:
    PickPointSelectedObject ppso = psr.Value[0] as PickPointSelectedObject;
    PickPointDescriptor ppd = ppso.PickPoint;
    Point3d onPlinePt = pline.GetClosestPointTo(ppd.PointOnLine, ppd.Direction, false);

  10. #10
    Forum Deity SEANT's Avatar
    Using
    AutoCAD 2014
    Join Date
    Aug 2005
    Location
    Rhode Island
    Posts
    2,187

    Default

    Registered forum members do not see this ad.

    Yes, I did notice that feature in Post #9, a critical feature in 3D work. It would have been processed at some point along the way. Yesterday, the amount of attention I could devote towards any aspect of the problem was focused primarily on filtering. Thanks again for the heads up.
