    Default Pieces of walls & windows print in color?

    Registered forum members do not see this ad.

    when I plot with an "AIA LWT by Object" plot style everything plot black when I put it on the "standard" layer, except the inside hatch of the wall prints yellow & the glazing of the window prints blue and the glass prints yellow. I know its an embedded layer in the the components that make up the wall or window already created by Autodesk but is there a way to override those embedded layers so everything will print correctly on the standard layer?

    Thanks in advance for any suggestions!
