MichaelJ07 Posted April 4, 2010 Share Posted April 4, 2010 Does your company use specific colors for specific layers? If not, what are your preferences for layer colors in your particular disciplines? In my drawings, I prefer red for those points that I want to bring special attention to. I might throw in some blues and greens and oranges just to make it interesting. Anyhoo, what do some of you folks use? Quote Link to comment Share on other sites More sharing options...
dbroada Posted April 4, 2010 Share Posted April 4, 2010 we use cyan as a thicker line so the Outline layer is CYAN. The company standard says text should be yellow but if that is printed in colour it is impossible to read so most of us use green. We have a layer called FERRULES which which we use for wire markers (export to a label printer) and we set this to MAGENTA as it is quite obvious to see that the correct layer hass been used. All this may change soon as I am evaluating AutoCAD Electrical. Quote Link to comment Share on other sites More sharing options...
nukecad Posted April 4, 2010 Share Posted April 4, 2010 Yes we use different colours and linetypes for specific layers and use .ctb's to set the plotted line thickness by colour. Its a long list but the basics- outlines, yellow, 0.35mm, continuous hidden, white,0.25, hidden centrelines, red, 0.18, center dimensions, white, 0.25, continuous text, white, 0.25, continuous existing; grey, 0.8, phantom 2D piping Isometric, cyan,0.5, continuous etc. Quote Link to comment Share on other sites More sharing options...
