muck Posted April 7, 2010 Share Posted April 7, 2010 Is there a good website that allows a user to pick channel or beam or any other common steel structures with dims for cad drawings? Unistrut does a good job for unistrut blocks but is there any webpages that is good for steel structures? Thank you, Quote Link to comment Share on other sites More sharing options...
ReMark Posted April 7, 2010 Share Posted April 7, 2010 With sizes? Not sure about that part. Have you checked the similar threads below? Imperial or Metric? Quote Link to comment Share on other sites More sharing options...
ReMark Posted April 7, 2010 Share Posted April 7, 2010 A ton of blocks here but be forewarned as it takes a while for the site to load. You must also pay close attention to the block names so you'll download exactly what you want. And "no" they are not dimensioned. "You can't always get what you want." ftp://adeskftp.autodesk.com/pointa/GeneralSymbolsCatalog/ Quote Link to comment Share on other sites More sharing options...
ReMark Posted April 7, 2010 Share Posted April 7, 2010 If you're from the land 'down under' then this is the website you want to visit. You'll have to scroll down a bit to find structural shapes. http://www.draftsperson.net/index.php?title=Draftsperson.net:Free_AutoCAD_Blocks Quote Link to comment Share on other sites More sharing options...
Tankman Posted April 7, 2010 Share Posted April 7, 2010 Mucky predicament? As ReMark asked, "Imperial or metric?" Unistrut™ have used, continue to use, for many years. I use the FRP Unistrut™ for pipe supports, made my own group drawing with many options I use most often. Where are you posting from? Version of AutoCAD? Both? Here's two different drawings, save 'em for future use! :wink: STEEL_SECTIONS.dwg US_Steel_Profiles.DWG UNISTRUT_Generic.dwg Quote Link to comment Share on other sites More sharing options...
Tankman Posted April 7, 2010 Share Posted April 7, 2010 Got me in the muck, cleaning files out or up. Found this old Unistrut™ used for pipe support with the poly base plate. Have fun, great weather on the East Coast today! UNISTRUT-POLY-POST BASE_Generic.dwg Quote Link to comment Share on other sites More sharing options...
muck Posted April 7, 2010 Author Share Posted April 7, 2010 For Electrical Panels Hoffman does very good but for steel channels & columns I don't know of a simular site you can pick building columes and channels etc. If you go to unisturt they have good webpages for their products but I think you have to down load their product liberarys. Still looking for good sites for steel with dimensions. Thank you, Quote Link to comment Share on other sites More sharing options...
nukecad Posted April 7, 2010 Share Posted April 7, 2010 I previously posted some zips of various blocks here http://www.cadtutor.net/forum/showthread.php?t=38775&page=3 The Materials.zip has structural steel sections in there, but again not dimensioned. Quote Link to comment Share on other sites More sharing options...
rkent Posted April 7, 2010 Share Posted April 7, 2010 Tip 1779, Cadalyst.com, provides a lisp file(s) for drawing steel shapes. Quote Link to comment Share on other sites More sharing options...
NaeKid Posted April 7, 2010 Share Posted April 7, 2010 I have a great .lsp that I was told about here. Just type stl on the command-prompt to load it up, pick the steel shape you want and place the profile into your drawing. I did a quick GoogleSearch for it and found a copy that you can download from http://structuralsteeldetailer.us/autocad.html Quote Link to comment Share on other sites More sharing options...
