Scales in Layout sheets.

[chris l]

Hey guys having a bit of trouble here.

Im currently trying to set out some detail drawings i have done for uni. I would like to have a sectional detail and also a couple of larger details to show some close ups and some more detail.

I was wondering if it is possible to have say the section at 1:15 and the larger details at 1:5 and have them on the same layout sheet.

Currently i can only work out how to set the scale of the layout and cant work out how to set the scales of the other details. This means that every time i copy another detail in it goes to the same scale as the layout sheet.

I hope this makes sense and someone can help me.

Thanks in advance

chris

[ReMark]

Scales are assigned to individual viewports in your layout. Therefore it is entirely possible to have ten different viewports, each with a different scale, in a layout that will ultimately be plotted at a scale of 1:1.

I typically select my scales from the Viewport toolbar. Scales can also be assigned to a viewport using the Zoom > Scale > nXP option.

[ica_cici]

Do as Remark said, "Zoom > Scale > nXP option"

but you can also use solprof comand for the solid object, and insert by the scale you want.
