Sang Posted June 11, 2010 Share Posted June 11, 2010 [To access the Soldraw command you can: type soldraw at a Command: prompt OR select Setup, and Draw, under the Solids Menu. --Prompt: Select viewports to draw... Select objects: Click on the edge of the viewport(s) you wish to convert to 2D images and press Enter. The 2D images are projected off of the views. Note : The model is not removed during this command. The 2D images are added to it as separate drawings. If you double click on the TILE button, located on the Status Line, you will see the model with the 2D projections touching it.] Question : Where is Tile button:(? Status line = status bar? Quote Link to comment Share on other sites More sharing options...
ReMark Posted June 12, 2010 Share Posted June 12, 2010 The Application Status Bar is located at the very bottom of your screen. It is populated with a number of buttons. Tile button? Quite possible it means the area where you'll find the Model and Layout tabs. You're using SolDraw in a Layout so it is being suggested that you click on the Model tab to see the actual 2D projections. Quote Link to comment Share on other sites More sharing options...
Sang Posted June 12, 2010 Author Share Posted June 12, 2010 any suggestion to delete/avoid 2D projection on MS? i really dunno when i double click the layout tab -.-!!! Quote Link to comment Share on other sites More sharing options...
ReMark Posted June 12, 2010 Share Posted June 12, 2010 Use some other command. Perhaps Flatshot or SolProf. Quote Link to comment Share on other sites More sharing options...
