    Default Drawing a Car Wheel in AutoCAD (HELP)

    Does anybody know how I would get the Extruded Red circles (holes) in the 1st image below to look like the holes in the 2nd image below?

    I’m drawing the wheel in AutoCAD from a tutorial which has been drawn in SolidWorks.

    The small Extruded hole in the middle will go right through the wheel but the larger Extruded hole only needs to be Extruded until it hits the wheel surface (as per 2nd image).

    Help would be great.

    Thanks

    Bobzy20
    Last edited by Bobzy20; 30th Jun 2010 at 08:15 pm.
    Apparently Revit is the FUTURE but all I know is AutoCAD.

  2. #2
    Forum Deity MSasu's Avatar
    Discipline
    Construction
    MSasu's Discipline Details
    Occupation
    engineer
    Discipline
    Construction
    Details
    AutoLISP programmer
    Using
    AutoCAD 2013
    Join Date
    Mar 2009
    Location
    Brasov, Romania
    Posts
    3,735

    Default

    Draw half of the hole longitudinal section and revolve it around axis, place it in appropriate pozition on wheel and after subtract it from wheel. Done.

    Regards,
    Last edited by MSasu; 23rd Jun 2010 at 02:26 pm. Reason: Image added
