qball Posted February 10, 2011 Share Posted February 10, 2011 I have this Brace Plate for a Steel Braced Frame. I have constrained it as you can see. But I have two outstanding problems. If I insert the block at Point A, I need to attach Point B to the intersection of the Frame. Then I need to make Line 1 parallel to the braced frame angle via Point C. In one method I tried, I put Point B at a Coincident to the intersection required. But then I couldn't get Point C to attach to the Nearest of the Brace Angle. The second problem is if I insert the block at the top of the brace and mirror it all the constraints are lost. Do I need 4 different blocks for the 4 corners of a brace? bracedframe.dwg Quote Link to comment Share on other sites More sharing options...
SLW210 Posted February 10, 2011 Share Posted February 10, 2011 I gave it a quick glance, but looks like you need some rotate parameters and maybe a flip. Draw something showing me all of the positions you need it in. Quote Link to comment Share on other sites More sharing options...
qball Posted February 10, 2011 Author Share Posted February 10, 2011 I think the 4 different orientations are the least of my worries. When I added a rotation parameter it seemed to have worked on the first manipulation, but when I went to grab the rotation node again, the brace piece would only stretch horizontal or vertical. the yellow frame on the right of the attached is a good example. But as you can see, I've locked point A to where it should be, but Point B won't attach the proper spot. And grabbing Point C won't allow to attach to the Yellow Centreline bracedframe2.dwg Quote Link to comment Share on other sites More sharing options...
