    Default Can't edit plotstyles

    Registered forum members do not see this ad.

    Hello everyone,
    I've just started working in a drawing that has some strange plotstyle happenings... I was emailed the drawing, and it is in metric, and I don't have any info from the person who created it.. When I go to edit the current plotstyle or to create a new one I am not able to change anything. The list of colors does not show up, only the list of plotstyle names where the colors usually are. (nothing happens when I click on them) I opened a new document and do not have this problem. Any ideas if there's a setting somewhere that's preventing me from editing plotstyles? (the plot with plotstyles box IS checked, as is the radio button to use color dependent plotstyles.
    Thanks for your help!
    -K
    Reply With Quote Reply With Quote
  2. 2nd Mar 2011 10:19 pm #2
    SLW210
    SLW210 is offline
    Super Moderator SLW210's Avatar
    Computer Details
    SLW210's Computer Details
    Operating System:
    Windows 7 PRO
    Computer:
    IBM Lenovo
    Motherboard:
    ACPI x86
    CPU:
    Pentium(R) Dual-Core CPU E5500 @ 2.80GHz
    RAM:
    4 GB RAM
    Graphics:
    Nvidia Quadro 600 1GB
    Primary Storage:
    300 GB
    Secondary Storage:
    650GB
    Monitor:
    ThinkVision 22"
    Discipline
    Multi-disciplinary
    SLW210's Discipline Details
    Occupation
    Design Draftsman
    Discipline
    Multi-disciplinary
    Details
    Mostly do drafting related to manufacturing. From doing site layouts with proposed updates, additions and renovations to be budgeted and submitted for bid, to updating and changing existing drawings to reflect maintenance and repair/revision work done on site.
    Using
    AutoCAD 2011
    Join Date
    May 2007
    Location
    South Florida, USA
    Posts
    9,106

    Default

    May you could post the DWG file or give some screenshots.
    “A narrow mind and a fat head invariably come on the same person” Zig Zigler


    Reply With Quote Reply With Quote
  3. 2nd Mar 2011 10:31 pm #3
    rkent
    rkent is offline
    Forum Deity rkent's Avatar
    Computer Details
    rkent's Computer Details
    Operating System:
    WIN7 PRO 64bit
    Computer:
    Dell Precision T7500
    CPU:
    Xeon Dual Core E5503 2.0Ghz
    RAM:
    6GB DDR3 ECC SDRAM, 1333MHz, 6x1GB
    Graphics:
    nVidia Quadro 3800
    Primary Storage:
    300Gb, 10K rpm
    Monitor:
    Dell 24" FS (2x)
    Discipline
    Mechanical
    rkent's Discipline Details
    Occupation
    Facilities Design - Semi-conductor manufacturing
    Discipline
    Mechanical
    Details
    Designer: Process Piping, P&ID's, Machine Part Design, Planning / General Arrangement. Facilities Management. Drafting: Electrical, Controls, Architectural.
    Using
    Mechanical 2014
    Join Date
    Nov 2007
    Location
    Lat:35, Long:-106, Elev: 5164'
    Posts
    3,372

    Default

    Quote Originally Posted by kellert82 View Post
    Hello everyone,
    I've just started working in a drawing that has some strange plotstyle happenings... I was emailed the drawing, and it is in metric, and I don't have any info from the person who created it.. When I go to edit the current plotstyle or to create a new one I am not able to change anything. The list of colors does not show up, only the list of plotstyle names where the colors usually are. (nothing happens when I click on them) I opened a new document and do not have this problem. Any ideas if there's a setting somewhere that's preventing me from editing plotstyles? (the plot with plotstyles box IS checked, as is the radio button to use color dependent plotstyles.
    Thanks for your help!
    -K
    Sounds like you have an .STB file that has the r14 color mapping table in it. You can't edit them until you remove that table. See image.
    Attached Images
    "You are entitled to your own opinion but you are not entitled to your own facts." Daniel Patrick Moynihan
    Reply With Quote Reply With Quote
  4. 2nd Mar 2011 11:23 pm #4
    kellert82
    kellert82 is offline
    Forum Newbie
    Using
    AutoCAD 2010
    Join Date
    Dec 2010
    Posts
    4

    Default

    Unfortunately I just checked and the r14 button isn't there. No buttons are. This is what I'm seeing:
    Attached Images
    Reply With Quote Reply With Quote
  5. 2nd Mar 2011 11:24 pm #5
    rkent
    rkent is offline
    Forum Deity rkent's Avatar
    Computer Details
    rkent's Computer Details
    Operating System:
    WIN7 PRO 64bit
    Computer:
    Dell Precision T7500
    CPU:
    Xeon Dual Core E5503 2.0Ghz
    RAM:
    6GB DDR3 ECC SDRAM, 1333MHz, 6x1GB
    Graphics:
    nVidia Quadro 3800
    Primary Storage:
    300Gb, 10K rpm
    Monitor:
    Dell 24" FS (2x)
    Discipline
    Mechanical
    rkent's Discipline Details
    Occupation
    Facilities Design - Semi-conductor manufacturing
    Discipline
    Mechanical
    Details
    Designer: Process Piping, P&ID's, Machine Part Design, Planning / General Arrangement. Facilities Management. Drafting: Electrical, Controls, Architectural.
    Using
    Mechanical 2014
    Join Date
    Nov 2007
    Location
    Lat:35, Long:-106, Elev: 5164'
    Posts
    3,372

    Default

    Almost there, move over to the General tab at the top left.

    If you don't normally use STB files you may want to just convert that one file using CONVERTPSTYLES command.
    "You are entitled to your own opinion but you are not entitled to your own facts." Daniel Patrick Moynihan
    Reply With Quote Reply With Quote
  6. 2nd Mar 2011 11:53 pm #6
    kellert82
    kellert82 is offline
    Forum Newbie
    Using
    AutoCAD 2010
    Join Date
    Dec 2010
    Posts
    4

    Default

    Sorry, that button isn't there, here is the other screen shot. I use plot styles all the time and I have a bunch of them... they're just not here..
    Attached Images
    Reply With Quote Reply With Quote
  7. 2nd Mar 2011 11:59 pm #7
    rkent
    rkent is offline
    Forum Deity rkent's Avatar
    Computer Details
    rkent's Computer Details
    Operating System:
    WIN7 PRO 64bit
    Computer:
    Dell Precision T7500
    CPU:
    Xeon Dual Core E5503 2.0Ghz
    RAM:
    6GB DDR3 ECC SDRAM, 1333MHz, 6x1GB
    Graphics:
    nVidia Quadro 3800
    Primary Storage:
    300Gb, 10K rpm
    Monitor:
    Dell 24" FS (2x)
    Discipline
    Mechanical
    rkent's Discipline Details
    Occupation
    Facilities Design - Semi-conductor manufacturing
    Discipline
    Mechanical
    Details
    Designer: Process Piping, P&ID's, Machine Part Design, Planning / General Arrangement. Facilities Management. Drafting: Electrical, Controls, Architectural.
    Using
    Mechanical 2014
    Join Date
    Nov 2007
    Location
    Lat:35, Long:-106, Elev: 5164'
    Posts
    3,372

    Default

    Attach the monochrome.stb file that you can't edit.

    Or convert to CTB since it sounds like you use color dependant plot styles.
    "You are entitled to your own opinion but you are not entitled to your own facts." Daniel Patrick Moynihan
    Reply With Quote Reply With Quote
  8. 3rd Mar 2011 08:29 pm #8
    kellert82
    kellert82 is offline
    Forum Newbie
    Using
    AutoCAD 2010
    Join Date
    Dec 2010
    Posts
    4

    Default

    Registered forum members do not see this ad.

    CONVERTPSTYLES worked! Thank you so much!
