harilalmn Posted September 5, 2011 Share Posted September 5, 2011 What is wrong in the code? I am trying to set the Z position value to zero for all the blocks in the drawing; (defun c:B0() (setq myFilter(list (cons 0 "INSERT"))) (setq ss (ssget "_X" myFilter)) (setq l (sslength ss)) (setq i 0) (Repeat l (setq blk (ssname ss i)) (setq DXF (entget (car blk))) (setq IP (cadr (assoc 0 dxf))) (setq NewIP (subst "0" (caddr IP) IP)) (setq NewDXF (subst NewIP IP DXF)) (entmod NewDXF) ) ) Quote Link to comment Share on other sites More sharing options...
pBe Posted September 5, 2011 Share Posted September 5, 2011 (edited) [color=black](defun c:B0 ()[/color] [color=black] (setq myFilter (list (cons 0 "INSERT")))[/color] [color=black] (setq ss (ssget "_X" myFilter))[/color] [color=black] (setq l (sslength ss))[/color] [color=black] (setq i 0)[/color] [color=black] (Repeat l[/color] [color=black] (setq blk (ssname ss i))[/color] [color=black] (setq DXF (entget blk))[/color] [color=black] (setq IP ([color=sienna]cdr [/color](assoc [color=sienna]10 [/color]dxf)))[/color] [color=black] (setq NewIP (subst [color=sienna]0.00[/color] (caddr IP) IP))[/color] [color=black] (setq NewDXF (subst [color=sienna](cons 10 NewIP) (assoc 10 dxf)[/color] DXF))[/color] [color=black] (entmod NewDXF)[/color] [color=sienna](setq i (1+ i))[/color] [color=black] )[/color] [color=black] )[/color] variable i remains at 0.... "0" as string not real number... Among other things.... Edited September 5, 2011 by pBe Quote Link to comment Share on other sites More sharing options...
Tharwat Posted September 5, 2011 Share Posted September 5, 2011 Try this ... (defun c:Test (/ ss i sset lst) (vl-load-com) (if (setq ss (ssget "_x" '((0 . "INSERT") (410 . "model")))) (repeat (setq i (sslength ss)) (setq sset (ssname ss (setq i (1- i)))) (setq lst (cons (vlax-ename->vla-object sset) lst)) ) (alert " << No Blocks existed in this drawing >> ") ) (foreach ml '(1e99 -1e99) (mapcar (function (lambda (x) (vla-move x (vlax-3d-point (list 0 0 0)) (vlax-3d-point (list 0 0 ml)) ) ) ) lst ) ) (princ) ) Tharwat Quote Link to comment Share on other sites More sharing options...
harilalmn Posted September 5, 2011 Author Share Posted September 5, 2011 pBe Thanks for your comment.. I now understand I should have added a (setq i (1+ i)) in the repeat loop...!! Thanks for the code Tharwat...!! That was much professional a solution compared to my code...!! Happy Happy.... Quote Link to comment Share on other sites More sharing options...
pBe Posted September 5, 2011 Share Posted September 5, 2011 .... (1e99 -1e99)..... Interesting Quote Link to comment Share on other sites More sharing options...
Lee Mac Posted September 5, 2011 Share Posted September 5, 2011 I would approach it this way: (defun c:B0 ( / e i p s ) (if (setq s (ssget "_X" '((0 . "INSERT") (-4 . "*,*,<>") (10 0.0 0.0 0.0)))) (repeat (setq i (sslength s)) (setq e (entget (ssname s (setq i (1- i)))) p (assoc 10 e) ) (entmod (subst (list 10 (cadr p) (caddr p) 0.0) p e)) ) ) (princ) ) I don't see the need to move everything to 1e99 elevation and back just to set the elevation to zero Quote Link to comment Share on other sites More sharing options...
David Bethel Posted September 5, 2011 Share Posted September 5, 2011 Using (subst) on a point value is very dangerous (setq ip '(10 10 10 10)) (subst 0 (caddr ip) ip) Returns -> '(0 0 0 0) [b][color=BLACK]([/color][/b]defun c:iz0 [b][color=FUCHSIA]([/color][/b]/ ss en ed in[b][color=FUCHSIA])[/color][/b] [b][color=FUCHSIA]([/color][/b]and [b][color=NAVY]([/color][/b]setq ss [b][color=MAROON]([/color][/b]ssget [color=#2f4f4f]"X"[/color] '[b][color=GREEN]([/color][/b][b][color=BLUE]([/color][/b]0 . [color=#2f4f4f]"INSERT"[/color][b][color=BLUE])[/color][/b][b][color=GREEN])[/color][/b][b][color=MAROON])[/color][/b][b][color=NAVY])[/color][/b] [b][color=NAVY]([/color][/b]while [b][color=MAROON]([/color][/b]setq en [b][color=GREEN]([/color][/b]ssname ss 0[b][color=GREEN])[/color][/b][b][color=MAROON])[/color][/b] [b][color=MAROON]([/color][/b]setq ed [b][color=GREEN]([/color][/b]entget en[b][color=GREEN])[/color][/b] in [b][color=GREEN]([/color][/b]cdr [b][color=BLUE]([/color][/b]assoc 10 ed[b][color=BLUE])[/color][/b][b][color=GREEN])[/color][/b][b][color=MAROON])[/color][/b] [b][color=MAROON]([/color][/b]entmod [b][color=GREEN]([/color][/b]subst [b][color=BLUE]([/color][/b]list 10 [b][color=RED]([/color][/b]car in[b][color=RED])[/color][/b] [b][color=RED]([/color][/b]cadr in[b][color=RED])[/color][/b] 0.0[b][color=BLUE])[/color][/b] [b][color=BLUE]([/color][/b]assoc 10 ed[b][color=BLUE])[/color][/b] ed[b][color=GREEN])[/color][/b][b][color=MAROON])[/color][/b] [b][color=MAROON]([/color][/b]entupd en[b][color=MAROON])[/color][/b] [b][color=MAROON]([/color][/b]ssdel en ss[b][color=MAROON])[/color][/b][b][color=NAVY])[/color][/b][b][color=FUCHSIA])[/color][/b] [b][color=FUCHSIA]([/color][/b]prin1[b][color=FUCHSIA])[/color][/b][b][color=BLACK])[/color][/b] I would think a lot more filtering would be advisable. Maybe groups 67 210 at the very least should be added. Also this will not move the attributes the elevation 0. -David Quote Link to comment Share on other sites More sharing options...
pBe Posted September 5, 2011 Share Posted September 5, 2011 or Ctrl+1 Quick Select Position Z Quote Link to comment Share on other sites More sharing options...
Tharwat Posted September 5, 2011 Share Posted September 5, 2011 .... (1e99 -1e99)..... Interesting Thanks pBe . I don't see the need to move everything to 1e99 elevation and back just to set the elevation to zero Why not ? Would that harm or incorrect in away or another ? Tharwat Quote Link to comment Share on other sites More sharing options...
Tharwat Posted September 5, 2011 Share Posted September 5, 2011 Thanks for the code Tharwat...!! That was much professional a solution compared to my code...!! Happy Happy.... You're welcome harilalmn . Enjoy it buddy Tharwat Quote Link to comment Share on other sites More sharing options...
Lee Mac Posted September 5, 2011 Share Posted September 5, 2011 Why not ? Because there is no need to do so - you can just move the objects directly to zero elevation. Moving objects to 1e99 elevation and back is merely expoiting the inherent limit of the AutoCAD coordinate system, and expecting the difference greater than 1e99 to be discarded. This method is usually used in 'Flatten' routines where there may be no alternative. Quote Link to comment Share on other sites More sharing options...
Tharwat Posted September 5, 2011 Share Posted September 5, 2011 This method is usually used in 'Flatten' routines where there may be no alternative. Very clever lee . I was inspired from a routine like that 'Flatten' Quote Link to comment Share on other sites More sharing options...
harilalmn Posted September 5, 2011 Author Share Posted September 5, 2011 Lee, I dont know what is happening.... Could you please look at the attached drawing? It is a part of the original file 'WBlock'-ed. I want to make everything coplanar in this. I have a script file as below; move all 0,0,0 0,0,1e99 move p 0,0,0 0,0,-1e99 For some reason, the script is killing the file...!! It moves the lines and blocks on xy plane too...!! It was to fix this file that I tried the lisp above... Could you please tell me what is wrong? Test_Drawing.dwg Quote Link to comment Share on other sites More sharing options...
Tharwat Posted September 5, 2011 Share Posted September 5, 2011 That's normal because the other entities are on a different Z value . Try the code for blocks that are on a different Z value . Quote Link to comment Share on other sites More sharing options...
harilalmn Posted September 5, 2011 Author Share Posted September 5, 2011 But I thought the above script file would bring everything to zero level...!!?? Is it not? Quote Link to comment Share on other sites More sharing options...
Tharwat Posted September 5, 2011 Share Posted September 5, 2011 But I thought the above script file would bring everything to zero level...!!?? Is it not? If you want it for all entities just remove the (0 . "insert") from my code and try again . Quote Link to comment Share on other sites More sharing options...
harilalmn Posted September 5, 2011 Author Share Posted September 5, 2011 Tharwat... Still that doesn't seem to be working... It takes some of the arcs, off their correct locations... However, blocks are not getting disoriented...! Quote Link to comment Share on other sites More sharing options...
Tharwat Posted September 5, 2011 Share Posted September 5, 2011 Try the other users' codes . Quote Link to comment Share on other sites More sharing options...
eldon Posted September 5, 2011 Share Posted September 5, 2011 One does wonder that when a drawing is posted, whether it is actually used to test the code posted I had a look at the drawing, and the geometry is something that I have never seen before. It is slightly wonky, and the arcs are not quite parallel to the main axes. It seems to be an excellent test for any flattening lisp, which at the moment does not seem to be able to cope with it. How should the geometry be altered so that the flatten lisp will work? Quote Link to comment Share on other sites More sharing options...
Lee Mac Posted September 5, 2011 Share Posted September 5, 2011 And there was me thinking the OP just wanted to set the elevation of all blocks to zero... Quote Link to comment Share on other sites More sharing options...
