The Nickster Posted September 23, 2011 Share Posted September 23, 2011 Hey guys is there a way to create text to align with the face of an isometric line? Quote Link to comment Share on other sites More sharing options...
rkent Posted September 23, 2011 Share Posted September 23, 2011 In the text style change the oblique angle to 30 or -30 depending on which plane you are working on. So you will want to create two new text styles for handle this. Quote Link to comment Share on other sites More sharing options...
The Nickster Posted September 23, 2011 Author Share Posted September 23, 2011 all that did was angle the text Quote Link to comment Share on other sites More sharing options...
The Nickster Posted September 23, 2011 Author Share Posted September 23, 2011 i need the text to align to the face of the iso lines the oblique angle just changed it to look italicized... Quote Link to comment Share on other sites More sharing options...
rkent Posted September 23, 2011 Share Posted September 23, 2011 i need the text to align to the face of the iso lines the oblique angle just changed it to look italicized... Now rotate it 30 degrees. ISO-DIMensions.dwg Quote Link to comment Share on other sites More sharing options...
The Nickster Posted September 23, 2011 Author Share Posted September 23, 2011 Genius! Thank you very much! it's just been too long since i've done anything in isometric. Quote Link to comment Share on other sites More sharing options...
Tankman Posted September 24, 2011 Share Posted September 24, 2011 See if this helps, http://www.andrew.cmu.edu/course/48-568/2DVideosWEB_files/frame.htm, Chapter 40. Don't know 'bout Revit, never used the program. Quote Link to comment Share on other sites More sharing options...
19cruthik68 Posted January 2, 2012 Share Posted January 2, 2012 Rkent, how did you set the annotation for that? this is the image of what i am talking. in yellow circle. thanks, Quote Link to comment Share on other sites More sharing options...
rkent Posted January 2, 2012 Share Posted January 2, 2012 Sorry, I am not sure what you are asking. Are you asking if the style is annotative? or something else? Quote Link to comment Share on other sites More sharing options...
19cruthik68 Posted January 5, 2012 Share Posted January 5, 2012 i mean, in that drop down menu there is an option ACANSGDT, iso30, iso330, ssaqnotes, Standard. Just want to know how to set those options?? because mine is always Annotative(nothing more) if i will going to click the drop down menu. Quote Link to comment Share on other sites More sharing options...
SLW210 Posted January 5, 2012 Share Posted January 5, 2012 .[ATTACH=CONFIG]32075[/ATTACH] _STYLE select New name it whatever you please Quote Link to comment Share on other sites More sharing options...
