    Default covert 3d face to polymesh

    hello to all
    can any one help me on how we can convert a 3d face drawing as in attached drawing or can be using autolisp routin
    Attached Files

  2. #2
    Forum Deity
    Using
    AutoCAD 2002
    Join Date
    Sep 2006
    Location
    East Sussex, U.K.
    Posts
    3,394

    Default

    Have you tried using the commands 3DSOUT and then the 3DSIN?

    If you look those up in your Help file, it will tell you how to do it.

  3. #3
    Forum Deity David Bethel's Avatar
    Discipline
    Multi-disciplinary
    David Bethel's Discipline Details
    Discipline
    Multi-disciplinary
    Details
    Commercial Food Service
    Using
    AutoCAD pre 2000
    Join Date
    Dec 2003
    Location
    Newport News, Virginia
    Posts
    2,024

    Default

    Here's a really really old routine ( still has Compuserve info )

    Code:
    ;=======================================================================
    ;    MakPface.Lsp                               Sep 19, 1998
    ;    Make A PFace Mesh From A Selection of 3DFaces
    ;================== Start Program ======================================
    (princ "\nCopyright (C) 1998, Fabricated Designs, Inc.")
    (princ "\nLoading MakPface v1.5 ")
    (setq mpf_ nil lsp_file "MakPface")

    ;================== For Automated Calling From Another Program =========
    (defun mpf_auto (ar1) (fa2pf ar1)) ;;;Supply PickSet Of Faces

    ;================== Macros =============================================
    (defun PDot ()(princ "."))

    (PDot);++++++++++++ Set Modes & Error ++++++++++++++++++++++++++++++++++
    (defun mpf_smd ()
     (SetUndo)
     (setq olderr *error*
          *error* (lambda (e)
                    (and (/= e "quit / exit abort")
                         (princ (strcat "\nError: *** " e " *** ")))
                    (command "_.UNDO" "_END" "_.U")
                    (mpf_rmd))
           mpf_var '(("CMDECHO"   . 0) ("MENUECHO"   . 0)
                     ("MENUCTL"   . 0) ("MACROTRACE" . 0)
                     ("OSMODE"    . 0) ("SORTENTS"   . 119)
                     ("BLIPMODE"  . 0) ("MODEMACRO"  . ".")
                     ("SNAPMODE"  . 1) ("PLINEWID"   . 0.0)
                     ("ORTHOMODE" . 1) ("GRIDMODE"   . 0)
                     ("ELEVATION" . 0) ("THICKNESS"  . 0)
                     ("FILLMODE"  . 0) ("SPLFRAME"   . 0)
                     ("UCSICON"   . 1) ("HIGHLIGHT"  . 1)
                     ("REGENMODE" . 1) ("COORDS"     . 2)
                     ("CECOLOR"   . "BYLAYER") ("CELTYPE" . "BYLAYER")))
     (foreach v mpf_var
          (setq m_v (cons (getvar (car v)) m_v)
                m_n (cons (car v) m_n))
          (setvar (car v) (cdr v)))
     (princ (strcat (getvar "PLATFORM") " Release " (substr (ver) 18 2)
       " -  Make PFface Mesh ....\n"))
     (princ))

    (PDot);++++++++++++ Return Modes & Error +++++++++++++++++++++++++++++++
    (defun mpf_rmd ()
      (setq *error* olderr)
      (mapcar 'setvar m_n m_v)
      (command "_.UNDO" "_END")
      (prin1))

    (PDot);++++++++++++ Set And Start An Undo Group ++++++++++++++++++++++++
    (defun SetUndo ()
     (and (zerop (getvar "UNDOCTL"))
          (command "_.UNDO" "_ALL"))
     (and (= (logand (getvar "UNDOCTL") 2) 2)
          (command "_.UNDO" "_CONTROL" "_ALL"))
     (and (= (logand (getvar "UNDOCTL") 8) 8)
          (command "_.UNDO" "_END"))
     (command "_.UNDO" "_GROUP"))

    (PDot);====== Convert A Selection Set Of 3DFaces To A PFace Mesh =======
      (defun fa2pf (ss / slen i ed en ef vlist vlen tlist ln)
      (and (/= (type ss) 'PICKSET)
           (princ "** Invalid Parameter To FA2PF ** ")
           (exit))
      (princ "\nDetermining Vertex Data\n")
      (setq slen (fix (sslength ss))
               i (1- slen))

    ;;;LAYER NAME
      (setq ln (cdr (assoc 8 (entget (ssname ss 0)))))

      (while (>= i 0)
          (setq en (ssname ss i)
                ed (entget en)
                 i (1- i))
           (and (/= (cdr (assoc 0 ed)) "3DFACE")
                (princ "\n** 3DFACES Only ** ")
                (exit))
           (foreach g '(10 11 12 13)
                  (if (not (member (cdr (assoc g ed)) vlist))
                      (setq vlist (cons (cdr (assoc g ed)) vlist))))
           (princ (strcat "\r" (rtos (/ (* 100 i) slen) 2 0) "% ")))
      (princ "\nDetermining Face Data\n")
      (setq vlen (length vlist))
      (entmake (list (cons 0 "POLYLINE")
                     (cons 8 ln)
                     (cons 10 (list 0 0 0))
                     (cons 66 1)
                     (cons 70 64)
                     (cons 71 vlen)
                     (cons 72 slen)))
      (foreach v vlist
         (entmake (list (cons 0 "VERTEX")
                        (cons 10 v)
                        (cons 70 192))))
      (setq i (1- slen))
      (while (>= i 0)
        (setq en (ssname ss i)
              ed (entget en)
              ef (cdr (assoc 70 ed))
               i (1- i)
           tlist nil)
        (foreach c '(1 2 3 4)
          (setq tlist (cons
            (cons (+ 70 c)
                  (* (if (= (logand ef (expt 2 (1- c))) (expt 2 (1- c))) -1 1)
                     (1+ (- vlen (length (member (cdr (assoc (+ 9 c) ed)) vlist))))))
                tlist)))
        (entmake (list (cons 0 "VERTEX")
                       (cons 8 ln)
                       (cons 10 (last vlist))
                       (if (assoc 62 ed)
                           (assoc 62 ed)
                           (cons 62 256))
                       (cons 70 128)
                       (nth 0 tlist)
                       (nth 1 tlist)
                       (nth 2 tlist)
                       (nth 3 tlist)))
         (princ (strcat "\r" (rtos (/ (* 100 i) slen) 2 0) "% ")))
      (entmake (list (cons 0 "SEQEND")(cons 8 ln)))
      (command "_.ERASE" ss "")
      (redraw (entlast)))

    (PDot);************ Main Program ***************************************
    (defun mpf_ (/ m_v m_n olderr mpf_var ssface)
      (mpf_smd)
    ;  (setq *error* nil)
      (setq ssface (ssget '((0 . "3DFACE"))))
      (fa2pf ssface)
      (mpf_rmd))

    (PDot);************ Load Program ***************************************
    (defun C:MakPface () (mpf_))
    (if mpf_ (princ "\nMakPface Loaded\n"))
    (prin1)
    ;================== End Program ========================================
    ;Tested With R12_c3 DOS & R13_c4a Only
    ;Copyright (C) 1998, Fabricated Designs, Inc.
    ;"AS IS" Public Domain Software Donated By
    ;
    ;
    ;        Fabricated Designs, Inc.
    ;        32 Maury Avenue
    ;        Newport News, Virginia  23601-2132
    ;         Ph: (757) 595-5949
    ;        FAX: (757) 595-5787
    ;        CIS: 73544,2655
    ;   Internet: http://ourworld.compuserve.com/homepages/DavidBethel/
    ;
    The problem being is that you can't do much with a polyface mesh. Have Fun! -David
    R12 (Dos) - A2K

  4. #4
    Senior Member
    Using
    not specified
    Join Date
    Feb 2006
    Posts
    267

    Default

    thank you david bethel realy you help me thank you very much it work perfect up to acad 2010 but not work on cad2012

  5. #5
    Forum Deity David Bethel's Avatar
    Discipline
    Multi-disciplinary
    David Bethel's Discipline Details
    Discipline
    Multi-disciplinary
    Details
    Commercial Food Service
    Using
    AutoCAD pre 2000
    Join Date
    Dec 2003
    Location
    Newport News, Virginia
    Posts
    2,024

    Default

    Mote-z,

    I don't see what could make the difference on this one. What does 2012 do that 2010 didn't? -David
    R12 (Dos) - A2K

  6. #6
    Senior Member
    Using
    not specified
    Join Date
    Feb 2006
    Posts
    267

    Default

    Registered forum members do not see this ad.

    sorry david i was mistak it works in both version
