    Default Extrude At angle ?

    Is there a command to extrude something at like a an angle. Im not talking about taper but something that could extrude at an angle

  2. #2
    Forum Deity
    Using
    Civil 3D 2013
    Join Date
    Dec 2005
    Location
    GEELONG AUSTRALIA
    Posts
    4,965

    Default

    You can extrude an object at any any 3D angle you need to look into UCS, you just create a new ucs draw object then extrude.
    A man who never made mistakes never made anything

  3. #3
    Super Member Patrick Hughes's Avatar
    Computer Details
    Patrick Hughes's Computer Details
    Operating System:
    Win 7 x64
    Computer:
    Dell Precision T7610
    CPU:
    Intel Xeon E5-2630 v2 (six core)
    RAM:
    32 Gb
    Graphics:
    3 Gb Nvidia Quadro K4000
    Primary Storage:
    1 TB
    Monitor:
    2x 1920x1080 Dell Ultrasharp U2312HM
    Discipline
    Mechanical
    Patrick Hughes's Discipline Details
    Occupation
    Self unemployed - Machine Design
    Discipline
    Mechanical
    Details
    Machine Design
    Using
    AutoCAD 2015
    Join Date
    May 2008
    Location
    Rockford, Illinois
    Posts
    678

    Default

    Quote Originally Posted by BIGAL View Post
    You can extrude an object at any any 3D angle you need to look into UCS, you just create a new ucs draw object then extrude.
    I'm not certain I follow you BIGAL, I haven't tried adjusting the UCS to extrude. I've extruded at an angle by drawing a line into the z-axis and rotating it to the angle I want (or the line could be drawn to the angle you want) then extrude using the line as the path.
    www.cadtempo.com
    Time tracking for AutoCAD, Inventor, Revit and other CAD programs

  4. #4
    Quantum Mechanic ReMark's Avatar
    Computer Details
    ReMark's Computer Details
    Operating System:
    Windows 7 Pro 64-bit
    Computer:
    Thinkmate
    Motherboard:
    Intel DX58SO2 LGA1366 X58
    CPU:
    Intel i7-960 Quad-core 3.20GHz 8MB cache
    RAM:
    12GB (3x4GB) PC3-106000 DDR3
    Graphics:
    nVidia Quadro 4000, 2GB GDDR5
    Primary Storage:
    150GB Velocipraptor 10,000 rpm
    Secondary Storage:
    none
    Monitor:
    Dell P24LLH - 24" wide screen LCD
    Discipline
    See details...
    ReMark's Discipline Details
    Occupation
    CAD Draftsman/Designer...chemical manufacturing.
    Discipline
    See details below.
    Details
    I work for a specialty chemical manufacturer. I do a little bit of everything from P&IDs to civil to architectural and structural.
    Using
    AutoCAD 2015
    Join Date
    Nov 2005
    Location
    Norwalk, CT USofA
    Posts
    39,454

    Default

    Quote Originally Posted by fpanjsh4 View Post
    Is there a command to extrude something at like a an angle. Im not talking about taper but something that could extrude at an angle
    Do you know how to reorient your UCS? Yes/No/What is a UCS?
    "I have only come here seeking knowledge. Things they wouldn't teach me of in college." The Police

    Eat brains...gain more knowledge! I've gone over to the dark side.

  5. #5
    Forum Deity Organic's Avatar
    Discipline
    Civil
    Using
    AutoCAD 2015
    Join Date
    Feb 2009
    Posts
    2,197

    Default

    Quote Originally Posted by ReMark View Post
    Do you know how to reorient your UCS? Yes/No/What is a UCS?
    The UCS is one of the more complicated features of AutoCad remember.

  6. #6
    Quantum Mechanic ReMark's Avatar
    Computer Details
    ReMark's Computer Details
    Operating System:
    Windows 7 Pro 64-bit
    Computer:
    Thinkmate
    Motherboard:
    Intel DX58SO2 LGA1366 X58
    CPU:
    Intel i7-960 Quad-core 3.20GHz 8MB cache
    RAM:
    12GB (3x4GB) PC3-106000 DDR3
    Graphics:
    nVidia Quadro 4000, 2GB GDDR5
    Primary Storage:
    150GB Velocipraptor 10,000 rpm
    Secondary Storage:
    none
    Monitor:
    Dell P24LLH - 24" wide screen LCD
    Discipline
    See details...
    ReMark's Discipline Details
    Occupation
    CAD Draftsman/Designer...chemical manufacturing.
    Discipline
    See details below.
    Details
    I work for a specialty chemical manufacturer. I do a little bit of everything from P&IDs to civil to architectural and structural.
    Using
    AutoCAD 2015
    Join Date
    Nov 2005
    Location
    Norwalk, CT USofA
    Posts
    39,454

    Default

    Yes, I remember. What is it that you are expecting me to do?

    I'll take a wild guess here and assume you want me to tell the OP how to manipulate the UCS.

    1) Manually...from the command line. Ex. - UCS > X > 90. Make sure your UCS icon is showing. UCSICON > On.
    2) Via the Ribbon. In a 3D Modeling workspace look on either the Home or View tabs for the Coordinate panel. Multiple choices for orienting the UCS icon are available.
    3) Allow/Disallow Dynamic UCS (F6 key to toggle). There is a button for this in the lower left-hand corner of your screen sandwiched between the ones for Object Snap Tracking and Dynamic Input.
    Last edited by ReMark; 28th Nov 2011 at 01:40 pm.
    "I have only come here seeking knowledge. Things they wouldn't teach me of in college." The Police

    Eat brains...gain more knowledge! I've gone over to the dark side.

  7. #7
    Luminous Being JD Mather's Avatar
    Using
    Inventor 2015
    Join Date
    Sep 2007
    Location
    Williamsport, PA
    Posts
    8,266

    Default

    Quote Originally Posted by fpanjsh4 View Post
    Is there a command to extrude something at like a an angle. Im not talking about taper but something that could extrude at an angle
    Attach 2d drawing representative of what you are trying to do.
    Perhaps Sweep is the easiest answer to your problem.
    Certified SolidWorks Professional
    Autodesk Inventor 2014 Certified Professional
    Autodesk AutoCAD 2013 Certified Professional
    http://home.pct.edu/~jmather/content..._Tutorials.htm

  8. #8
    Full Member Alex Moiceanu's Avatar
    Computer Details
    Alex Moiceanu's Computer Details
    Operating System:
    Windows 7
    Discipline
    Mechanical
    Alex Moiceanu's Discipline Details
    Occupation
    Engineer
    Discipline
    Mechanical
    Details
    Automotive & Aerospace
    Using
    AutoCAD 2012
    Join Date
    Feb 2011
    Location
    Romania
    Posts
    46

    Default

    Try to create a line at the angle you want to extrude and sweep the area with line set as path.
    CAD-Systems.Think smart.Work less.

    http://www.cad-systems.org

    Find useful Tips & Tricks, free Tutorials and more...

  9. #9
    Super Member Bill Tillman's Avatar
    Using
    AutoCAD 2014
    Join Date
    Oct 2008
    Location
    Miami, FL
    Posts
    1,043

    Default

    Quote Originally Posted by ReMark View Post
    I'll take a wild guess here and assume you want me to tell the OP how to manipulate the UCS.
    Manipulating my UCS...not since I was a teenager.....er, oh, sorry,

    Yes, the UCS is our friend and if you're trying to do things in 3D it is highly recommended that you master this feature of AutoCAD. I was confused when I started with it too, and even today sometime I find that it takes me a couple of tries to get the rotation about the correct axis as I need it. But once I got this understood, the 3D world really opened up for me.
    It's deja vu, all over again.

  10. #10
    Forum Deity Dadgad's Avatar
    Using
    AutoCAD 2013
    Join Date
    Nov 2011
    Location
    At the confluence of worthlessness & invaluability
    Posts
    4,104

    Default quick is good

    Registered forum members do not see this ad.

    you might want to explore the UCS FACE icon on the UCS toolbar.
