Nick_Diaz Posted February 6, 2012 Share Posted February 6, 2012 (edited) The image is posted below: http://imageshack.us/photo/my-images/718/1hw3fig.png/ THANKS RVPAS! Edited February 6, 2012 by Nick_Diaz Quote Link to comment Share on other sites More sharing options...
rvpas Posted February 6, 2012 Share Posted February 6, 2012 Hi Nick Off Dynamic input before draw your shape F12 and Dont forget your second point option Second pt 60,95 enter(1st point) A enter(select option Arc) S enter(select option Second pt) 170,140 enter 225,130 enter W enter (change Width select option Width) Specify starting width 25 enter Specify ending width 0 enter 295,70 enter enter Bye Pascal Quote Link to comment Share on other sites More sharing options...
BIGAL Posted February 7, 2012 Share Posted February 7, 2012 Two lines then fillet would be easier ? Quote Link to comment Share on other sites More sharing options...
SLW210 Posted February 7, 2012 Share Posted February 7, 2012 Post your image to CADTutor so more can see what you are after. Imageshack is block at many companies. Quote Link to comment Share on other sites More sharing options...
jgbgod Posted February 7, 2012 Share Posted February 7, 2012 RVPAS hits it square on the nose. Use the arc command and enter the coordinates provided on the drawing. For the arrow head, simply use a polyline and change the start and ending width. Quote Link to comment Share on other sites More sharing options...
eldon Posted February 7, 2012 Share Posted February 7, 2012 Use the arc command and enter the coordinates provided on the drawing. For the arrow head, simply use a polyline and change the start and ending width. I think that the requirement was to use a Polyline at all times, with the Arc option Quote Link to comment Share on other sites More sharing options...
jgbgod Posted February 8, 2012 Share Posted February 8, 2012 ...Touche' Quote Link to comment Share on other sites More sharing options...
