    Default How to bend on an arc?

    Registered forum members do not see this ad.

    I am drawing a locking washer much like this...


    The lock washer that I am creating is much more detailed than this. I have tried revolving then cutting out the slots, but it does not give the true shape. I really need to "BEND" the fingers from a flat version of the washer.

    I can make a bend on a line by using the "Bend Part" tool and selecting a base line. But how can I make a "Bend Part" using a circle or arc as my base line?

  2. #2
    Luminous Being JD Mather's Avatar
    Using
    Inventor 2015
    Join Date
    Sep 2007
    Location
    Williamsport, PA
    Posts
    8,514

    Default

    Attach your ipt file here.
    Most likely you will want to Cut Across Bend.
    Certified SolidWorks Professional
    Autodesk Inventor 2014 Certified Professional
    Autodesk AutoCAD 2013 Certified Professional
    http://home.pct.edu/~jmather/content..._Tutorials.htm

  3. #3
    Junior Member
    Using
    Inventor 2011
    Join Date
    Feb 2012
    Posts
    11

    Default

    Due to my company policy, I am not allowed to upload anything to forums. I did try to create a Cut Across Bend but it would not allow me to do so. I created a revolved part that was uncut. I tried to project a flat pattern but it would not allow me to select the sides that I needed. Is there another way?

  4. #4
    Luminous Being JD Mather's Avatar
    Using
    Inventor 2015
    Join Date
    Sep 2007
    Location
    Williamsport, PA
    Posts
    8,514

    Default

    Quote Originally Posted by Ardalee View Post
    Is there another way?
    Yes.
    Have your company take the more expensive approach of hiring me to come on-site and show you a technique that will work.
    Where are you located.
