    Default stormwater linetype

    Registered forum members do not see this ad.

    Hello,

    i need to create this linetype for stormwater pipes( please see attachment). anyone can help please??
    is it a special linetype or a block or ... ???
    HELP!!!

    thanks.
    Attached Images

  2. #2
    Quantum Mechanic ReMark's Avatar
    Computer Details
    ReMark's Computer Details
    Operating System:
    Windows 7 Pro 64-bit
    Computer:
    Thinkmate
    Motherboard:
    Intel DX58SO2 LGA1366 X58
    CPU:
    Intel i7-960 Quad-core 3.20GHz 8MB cache
    RAM:
    12GB (3x4GB) PC3-106000 DDR3
    Graphics:
    nVidia Quadro 4000, 2GB GDDR5
    Primary Storage:
    150GB Velocipraptor 10,000 rpm
    Secondary Storage:
    none
    Monitor:
    Dell P24LLH - 24" wide screen LCD
    Discipline
    See details...
    ReMark's Discipline Details
    Occupation
    CAD Draftsman/Designer...chemical manufacturing.
    Discipline
    See details below.
    Details
    I work for a specialty chemical manufacturer. I do a little bit of everything from P&IDs to civil to architectural and structural.
    Using
    AutoCAD 2015
    Join Date
    Nov 2005
    Location
    Norwalk, CT USofA
    Posts
    40,462

    Default

    It could probably be done using Express Tools using commands to make linetype and make shape.
    "I have only come here seeking knowledge. Things they wouldn't teach me of in college." The Police

    Eat brains...gain more knowledge!

    I'm now a full member of the Society for the Promotion of Mediocrity in CAD. Standards? We don't need no stinkin' standards! Take whatever advice I offer and do the opposite.

  3. #3
    Super Member Murph_map's Avatar
    Computer Details
    Murph_map's Computer Details
    Operating System:
    XP,Visa, Win7
    Computer:
    HP something or other and the laptop is an HP too
    RAM:
    2 gigs or 6 gigs in Laptop
    Discipline
    Utilities
    Murph_map's Discipline Details
    Occupation
    Boats and campers renting and repairs
    Discipline
    Utilities
    Details
    GIS and Map making.
    Using
    Map 3D 2011
    Join Date
    Feb 2011
    Location
    TN or KY depends if I'm at work or home.
    Posts
    823

    Default

    I see 3 line types in your image, do you want the one that looks like
    ----s----s----s ?
    Murph

    Need a boat or camper for the weekend?

  4. #4
    Quantum Mechanic ReMark's Avatar
    Computer Details
    ReMark's Computer Details
    Operating System:
    Windows 7 Pro 64-bit
    Computer:
    Thinkmate
    Motherboard:
    Intel DX58SO2 LGA1366 X58
    CPU:
    Intel i7-960 Quad-core 3.20GHz 8MB cache
    RAM:
    12GB (3x4GB) PC3-106000 DDR3
    Graphics:
    nVidia Quadro 4000, 2GB GDDR5
    Primary Storage:
    150GB Velocipraptor 10,000 rpm
    Secondary Storage:
    none
    Monitor:
    Dell P24LLH - 24" wide screen LCD
    Discipline
    See details...
    ReMark's Discipline Details
    Occupation
    CAD Draftsman/Designer...chemical manufacturing.
    Discipline
    See details below.
    Details
    I work for a specialty chemical manufacturer. I do a little bit of everything from P&IDs to civil to architectural and structural.
    Using
    AutoCAD 2015
    Join Date
    Nov 2005
    Location
    Norwalk, CT USofA
    Posts
    40,462

    Default

    The OP is interested in the top most line not the two below it. I know because the OP posted a verbal description of the linetype at another CAD forum.
    "I have only come here seeking knowledge. Things they wouldn't teach me of in college." The Police

    Eat brains...gain more knowledge!

    I'm now a full member of the Society for the Promotion of Mediocrity in CAD. Standards? We don't need no stinkin' standards! Take whatever advice I offer and do the opposite.

  5. #5
    Senior Member
    Computer Details
    bill_borec's Computer Details
    Operating System:
    Windows 7 - 64 Bit
    Computer:
    Dell XPS
    CPU:
    Intel i7-2600
    RAM:
    8 GB
    Graphics:
    AMD Radeon HD 6700
    Monitor:
    Dual 24"s
    Discipline
    Civil
    bill_borec's Discipline Details
    Occupation
    Civil PE
    Discipline
    Civil
    Details
    Water Resources (Water/Sewer/Storm) Water/Wastewater Treatment Design
    Using
    Civil 3D 2013
    Join Date
    Jan 2012
    Location
    43.3630N 124.1947W
    Posts
    166

    Default

    Have you tried using a multi-line? This looks like it is comprised of 3 lines (2-continuous either side of a width adjusted polyline). You could mimic this with the three lines, simply offsetting the centerline and changing the ltype to continuous and the width to 0.

  6. #6
    Luminous Being
    Using
    Civil 3D 2013
    Join Date
    Dec 2005
    Location
    GEELONG AUSTRALIA
    Posts
    5,448

    Default

    I do this using a line type that is equal spacing the gap is the same as the drawn length, then just PE and enter width as pipe dia then just linetype scale and make dashed 2.4m and you can count up how many pipes needed yes you add two continuous lines to outside a lisp makes easier.

    here the linetype
    *EQUAL100,_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
    A,3.00,-3.00
    A man who never made mistakes never made anything

  7. #7
    Forum Newbie
    Using
    AutoCAD 2010
    Join Date
    Feb 2012
    Posts
    3

    Default Bill Borec

    thanks for your help,
    can i make a multiline with polylines ? i thought only with lines

  8. #8
    Quantum Mechanic ReMark's Avatar
    Computer Details
    ReMark's Computer Details
    Operating System:
    Windows 7 Pro 64-bit
    Computer:
    Thinkmate
    Motherboard:
    Intel DX58SO2 LGA1366 X58
    CPU:
    Intel i7-960 Quad-core 3.20GHz 8MB cache
    RAM:
    12GB (3x4GB) PC3-106000 DDR3
    Graphics:
    nVidia Quadro 4000, 2GB GDDR5
    Primary Storage:
    150GB Velocipraptor 10,000 rpm
    Secondary Storage:
    none
    Monitor:
    Dell P24LLH - 24" wide screen LCD
    Discipline
    See details...
    ReMark's Discipline Details
    Occupation
    CAD Draftsman/Designer...chemical manufacturing.
    Discipline
    See details below.
    Details
    I work for a specialty chemical manufacturer. I do a little bit of everything from P&IDs to civil to architectural and structural.
    Using
    AutoCAD 2015
    Join Date
    Nov 2005
    Location
    Norwalk, CT USofA
    Posts
    40,462

    Default

    I still think it is possible to make the desired linetype using the MKSHAPE and MKLTYPE commands found in Express Tools. May take a little experimentation but consider it a course in expanding your knowledge.
    "I have only come here seeking knowledge. Things they wouldn't teach me of in college." The Police

    Eat brains...gain more knowledge!

    I'm now a full member of the Society for the Promotion of Mediocrity in CAD. Standards? We don't need no stinkin' standards! Take whatever advice I offer and do the opposite.

  9. #9
    Forum Newbie
    Using
    AutoCAD 2010
    Join Date
    Feb 2012
    Posts
    3

    Default

    thanks guys! i finally did it with MKSHAPE & MKLTYPE! and Remark you r right, it took a little experiment , it was a good course

  10. #10
    Quantum Mechanic ReMark's Avatar
    Computer Details
    ReMark's Computer Details
    Operating System:
    Windows 7 Pro 64-bit
    Computer:
    Thinkmate
    Motherboard:
    Intel DX58SO2 LGA1366 X58
    CPU:
    Intel i7-960 Quad-core 3.20GHz 8MB cache
    RAM:
    12GB (3x4GB) PC3-106000 DDR3
    Graphics:
    nVidia Quadro 4000, 2GB GDDR5
    Primary Storage:
    150GB Velocipraptor 10,000 rpm
    Secondary Storage:
    none
    Monitor:
    Dell P24LLH - 24" wide screen LCD
    Discipline
    See details...
    ReMark's Discipline Details
    Occupation
    CAD Draftsman/Designer...chemical manufacturing.
    Discipline
    See details below.
    Details
    I work for a specialty chemical manufacturer. I do a little bit of everything from P&IDs to civil to architectural and structural.
    Using
    AutoCAD 2015
    Join Date
    Nov 2005
    Location
    Norwalk, CT USofA
    Posts
    40,462

    Default

    Registered forum members do not see this ad.

    Now you'll be the "go to" person when it comes to explaining how it is done and we can all go fishing! It's a win-win.
