Need help to Rotate a part in AutoCAD 3D

[john7911]

Hi,
How can I rotate the Gizmo in AutoCAD 3D in order to rotate a part as shown in these picture:
I have tried UCS : ZA - Face - View... but i did not succeed


Thank you

[rvpas]

Hi John
Just right click on gizmo and select personalized gizmo
now select orign, x et y axis of edge
By
Pascal

[john7911]

OK dear rvpas Thank you

[danellis]

Do you have to use the gizmo? Might it be easier to use ROTATE3D with a reference or 3DALIGN?

dJE

[john7911]

Do you have to use the gizmo? Might it be easier to use ROTATE3D with a reference or 3DALIGN?

dJE

I used the sweep it was easy to use for my project

Thank you

[ReMark]

Your beams are overlapping in the corners. Shouldn't at least two of them (opposite sides) be coped?

[john7911]

Is there any tool to cut beams? i have used extrusion and boolean to cut some parts but i have to finish the work.
I know in AutoCAD Plant 3D there is a nice tool to do it but now i'm working with MEP 2011.

[ReMark]

I have no knowledge of MEP. I could do it in plain AutoCAD using an extruded polyline and the SLICE command with SURFACE option.

I'm guessing then that your two angles on top has one punching through the other as well and you have them extended in the corners right into the beams too. Is that correct?

[john7911]

I'm guessing then that your two angles on top has one punching through the other as well and you have them extended in the corners right into the beams too. Is that correct?

Yes correct

[john7911]

I have cleaned up my work a litle bit
