hemal Posted November 4, 2012 Share Posted November 4, 2012 I am totally new in autocad 3d. I want to arrange views shown in fig for making isometric view. I want to know how to use rotate gizmo. please, help me. convert 2d into 3d.dwg Quote Link to comment Share on other sites More sharing options...
JD Mather Posted November 4, 2012 Share Posted November 4, 2012 3drotate enter select what you want to rotate enter look at your ucs red = x green = y blue = z click on the approriate circle and then you can rotate around the axis by 90° you can then move the views together with snaps align or 3dalign would be othe options. Quote Link to comment Share on other sites More sharing options...
rkent Posted November 4, 2012 Share Posted November 4, 2012 I would set a SE view, pick a visual style like hidden. Select one of the three views, pick on the appropriate x,y or z axis path, with polar or ortho on move your cursor so that it rotates 90 degrees. Repeat for another view. Please see help in autocad as it covers this pretty well. Quote Link to comment Share on other sites More sharing options...
