    Default stacked fractions in dimensions driving me up a wall

    Registered forum members do not see this ad.

    ok, all my dimensions are coming out with the fractional portion being stacked. That has become a problem for clarity reasons and I need them to come out diagnally. Is there a way I can set them to do this automatically and not have to go back and change them via the editor?
