bavdeyka Posted March 5, 2015 Share Posted March 5, 2015 (edited) Please have a look at my model. I can't perform boolean substraction on it. Could you please prompt on what the problem is? http://www.4shared.com/photo/Ep01Sbdkba/mul_1_.html Edited March 6, 2015 by bavdeyka Quote Link to comment Share on other sites More sharing options...
nestly Posted March 6, 2015 Share Posted March 6, 2015 I can't figure out how to download from that site. Quote Link to comment Share on other sites More sharing options...
bavdeyka Posted March 6, 2015 Author Share Posted March 6, 2015 Sorry nestly, here's a download link: http://www.4shared.com/download/Ep01Sbdkba/mul_1_.dwg?lgfp=3000 I've been using this site for quite a time, but can't figure out myself what's wrong with the first link Quote Link to comment Share on other sites More sharing options...
nestly Posted March 6, 2015 Share Posted March 6, 2015 When opening the drawing, I get a message that it's not an AutoCAD created dwg file. AutoCAD also says the object is not a valid ShapeManager solid. (SOLIDEDIT > BODY > CHECK) which I take to mean that it doesn't conform to AutoCAD's rules for 3D Solids. Unfortunately, I don't know convert it into a "valid" Shapemanager solid. Quote Link to comment Share on other sites More sharing options...
bavdeyka Posted March 6, 2015 Author Share Posted March 6, 2015 nestly, this model was created in Solidworks by another person. It won't substract even from primitive blocks, such as box. So I'm sure that the problem is in this model. But I just can't find it Quote Link to comment Share on other sites More sharing options...
ReMark Posted March 6, 2015 Share Posted March 6, 2015 (edited) Explode the solid and look at the resultant surfaces. They are a mess. Edited March 6, 2015 by ReMark Quote Link to comment Share on other sites More sharing options...
bavdeyka Posted March 6, 2015 Author Share Posted March 6, 2015 Hi ReMark, glad to see you here! I tried exploding, but I can't restore the model back from the pieces after it. what may it mean? Quote Link to comment Share on other sites More sharing options...
ReMark Posted March 6, 2015 Share Posted March 6, 2015 The "pieces" are surfaces and as you can see they are a mess. Have you tried the Extract Edges command? Maybe something could be done to reconstruct the various profiles needed to create the 3D model. I'm just guessing here though. I have never worked with something that was originally created in Solidworks. I think the worst part of the model is everything that comes after the cylindrical portion. Quote Link to comment Share on other sites More sharing options...
