    Cool Trouble viewing weld symbols

    Registered forum members do not see this ad.

    Hi All


    I have a customers drawing that I have added dim's and weld symbols to (I use Auto Cad Mech 2016), after I save the drawing and get out, my co-worker who uses Autocad Lt 2014 opens the drawing and can see the dim's that I added but not the weld symbols. I have looked at his setting, trying to compare them to a second system that is also running Autocad Lt 2014 who can open the same drawing and see both the dim's and weld symbols. Any suggestions will be greatly appricated.
