costadina Posted May 9, 2009 Share Posted May 9, 2009 Hi All. I'm new to this forum. I am looking for any suggestions where I can find some code to do a layer swap in Autocad. This is the situation: We have many drawings drawn to our companies layer standards. Now we have a new job and the customer has their own layer standards we must conform to. For example, we have Layer 1 called Electrical, Line Type continuous, Color Yellow. Customer has Layer 1 called Mechanical, Line Type Hidden, Color Green. Does anyone have any suggestions where I can find some code to crunch through drawing sets and automatically change the layers? Magazine, book, website, whatever. Also, this code must be able to change Layers embedded in blocks as well. I am familiar with VBA having done VBA programming in Excel, so I would prefer VBA code, but of course, I'll take what I can find. Just trying to avoid having to develop the code myself. Thanks in advance. Quote Link to comment Share on other sites More sharing options...
lpseifert Posted May 9, 2009 Share Posted May 9, 2009 Just trying to avoid having to develop the code myself. Thanks in advance. So you want someone to do the work for you? Try the Laytrans command Quote Link to comment Share on other sites More sharing options...
Commandobill Posted May 9, 2009 Share Posted May 9, 2009 So you want someone to do the work for you? Try the Laytrans command Im pretty sure he just meant he was hoping it was already written... laytrans should do what you are looking for though Quote Link to comment Share on other sites More sharing options...
alanjt Posted May 9, 2009 Share Posted May 9, 2009 i swear i read something by bill kramer (HTH), and he had written something very similar to that. i think he even called it Layer Swap, but i could be imagining things. they're right, laytrans will do what you are wanting though. Quote Link to comment Share on other sites More sharing options...
David Bethel Posted May 9, 2009 Share Posted May 9, 2009 I've used this a lot over the years on simple model space only, no xrefs drawings. A drawback can be if the linetype for the new layer does not exist or isn't in acad.lin, then it will fail during the LAYER command. It is case senitive ( in older releases didn't matter ) [b][color=BLACK]([/color][/b]defun c:cnvlayer [b][color=FUCHSIA]([/color][/b]/ ll tdef ln ss fe fd ld[b][color=FUCHSIA])[/color][/b] [color=#8b4513];;; FORMAT OLD NEW CLR LTYPE[/color] [b][color=FUCHSIA]([/color][/b]setq ll '[b][color=NAVY]([/color][/b][b][color=MAROON]([/color][/b][color=#2f4f4f]"1D"[/color] [color=#2f4f4f]"PLAN"[/color] 2 [color=#2f4f4f]"CONTINUOUS"[/color][b][color=MAROON])[/color][/b] [b][color=MAROON]([/color][/b][color=#2f4f4f]"2D"[/color] [color=#2f4f4f]"DETAIL"[/color] 6 [color=#2f4f4f]"PHANTOM"[/color][b][color=MAROON])[/color][/b] [b][color=MAROON]([/color][/b][color=#2f4f4f]"3D"[/color] [color=#2f4f4f]"MODEL"[/color] 8 [color=#2f4f4f]"CONTINUOUS"[/color][b][color=MAROON])[/color][/b][b][color=NAVY])[/color][/b][b][color=FUCHSIA])[/color][/b] [b][color=FUCHSIA]([/color][/b]foreach l ll [b][color=NAVY]([/color][/b]command [color=#2f4f4f]"_.LAYER"[/color][b][color=NAVY])[/color][/b] [b][color=NAVY]([/color][/b]if [b][color=MAROON]([/color][/b]not [b][color=GREEN]([/color][/b]tblsearch [color=#2f4f4f]"LAYER"[/color] [b][color=BLUE]([/color][/b]nth 1 l[b][color=BLUE])[/color][/b][b][color=GREEN])[/color][/b][b][color=MAROON])[/color][/b] [b][color=MAROON]([/color][/b]command [color=#2f4f4f]"_M"[/color] [b][color=GREEN]([/color][/b]nth 1 l[b][color=GREEN])[/color][/b][b][color=MAROON])[/color][/b][b][color=NAVY])[/color][/b] [b][color=NAVY]([/color][/b]command [color=#2f4f4f]"_C"[/color] [b][color=MAROON]([/color][/b]nth 2 l[b][color=MAROON])[/color][/b] [b][color=MAROON]([/color][/b]nth 1 l[b][color=MAROON])[/color][/b] [color=#2f4f4f]"_LT"[/color] [b][color=MAROON]([/color][/b]nth 3 l[b][color=MAROON])[/color][/b] [b][color=MAROON]([/color][/b]nth 1 l[b][color=MAROON])[/color][/b] [color=#2f4f4f]""[/color][b][color=NAVY])[/color][/b][b][color=FUCHSIA])[/color][/b] [b][color=FUCHSIA]([/color][/b]while [b][color=NAVY]([/color][/b]setq tdef [b][color=MAROON]([/color][/b]tblnext [color=#2f4f4f]"LAYER"[/color] [b][color=GREEN]([/color][/b]not tdef[b][color=GREEN])[/color][/b][b][color=MAROON])[/color][/b][b][color=NAVY])[/color][/b] [b][color=NAVY]([/color][/b]setq ln [b][color=MAROON]([/color][/b]cdr [b][color=GREEN]([/color][/b]assoc 2 tdef[b][color=GREEN])[/color][/b][b][color=MAROON])[/color][/b][b][color=NAVY])[/color][/b] [b][color=NAVY]([/color][/b]and [b][color=MAROON]([/color][/b]setq ss [b][color=GREEN]([/color][/b]ssget [color=#2f4f4f]"X"[/color] [b][color=BLUE]([/color][/b]list [b][color=RED]([/color][/b]cons 8 ln[b][color=RED])[/color][/b][b][color=BLUE])[/color][/b][b][color=GREEN])[/color][/b][b][color=MAROON])[/color][/b] [b][color=MAROON]([/color][/b]assoc ln ll[b][color=MAROON])[/color][/b] [b][color=MAROON]([/color][/b]command [color=#2f4f4f]"_.CHPROP"[/color] ss [color=#2f4f4f]""[/color] [color=#2f4f4f]"_LA"[/color] [b][color=GREEN]([/color][/b]nth 1 [b][color=BLUE]([/color][/b]assoc ln ll[b][color=BLUE])[/color][/b][b][color=GREEN])[/color][/b] [color=#2f4f4f]""[/color][b][color=MAROON])[/color][/b][b][color=NAVY])[/color][/b][b][color=FUCHSIA])[/color][/b] [b][color=FUCHSIA]([/color][/b]while [b][color=NAVY]([/color][/b]setq tdef [b][color=MAROON]([/color][/b]tblnext [color=#2f4f4f]"BLOCK"[/color] [b][color=GREEN]([/color][/b]not tdef[b][color=GREEN])[/color][/b][b][color=MAROON])[/color][/b][b][color=NAVY])[/color][/b] [b][color=NAVY]([/color][/b]setq fe [b][color=MAROON]([/color][/b]cdr [b][color=GREEN]([/color][/b]assoc -2 tdef[b][color=GREEN])[/color][/b][b][color=MAROON])[/color][/b][b][color=NAVY])[/color][/b] [b][color=NAVY]([/color][/b]entmake tdef[b][color=NAVY])[/color][/b] [b][color=NAVY]([/color][/b]while fe [b][color=MAROON]([/color][/b]setq fd [b][color=GREEN]([/color][/b]entget fe[b][color=GREEN])[/color][/b] ln [b][color=GREEN]([/color][/b]cdr [b][color=BLUE]([/color][/b]assoc 8 fd[b][color=BLUE])[/color][/b][b][color=GREEN])[/color][/b][b][color=MAROON])[/color][/b] [b][color=MAROON]([/color][/b]and [b][color=GREEN]([/color][/b]setq ld [b][color=BLUE]([/color][/b]assoc ln ll[b][color=BLUE])[/color][/b][b][color=GREEN])[/color][/b] [b][color=GREEN]([/color][/b]setq fd [b][color=BLUE]([/color][/b]subst [b][color=RED]([/color][/b]cons 8 [b][color=PURPLE]([/color][/b]nth 1 ld[b][color=PURPLE])[/color][/b][b][color=RED])[/color][/b] [b][color=RED]([/color][/b]assoc 8 fd[b][color=RED])[/color][/b] fd[b][color=BLUE])[/color][/b][b][color=GREEN])[/color][/b][b][color=MAROON])[/color][/b] [b][color=MAROON]([/color][/b]entmake fd[b][color=MAROON])[/color][/b] [b][color=MAROON]([/color][/b]setq fe [b][color=GREEN]([/color][/b]entnext fe[b][color=GREEN])[/color][/b][b][color=MAROON])[/color][/b][b][color=NAVY])[/color][/b] [b][color=NAVY]([/color][/b]entmake [b][color=MAROON]([/color][/b]list [b][color=GREEN]([/color][/b]cons 0 [color=#2f4f4f]"ENDBLK"[/color][b][color=GREEN])[/color][/b][b][color=GREEN]([/color][/b]cons 8 [color=#2f4f4f]"0"[/color][b][color=GREEN])[/color][/b][b][color=MAROON])[/color][/b][b][color=NAVY])[/color][/b][b][color=FUCHSIA])[/color][/b] [b][color=FUCHSIA]([/color][/b]prin1[b][color=FUCHSIA])[/color][/b][b][color=BLACK])[/color][/b] -David Quote Link to comment Share on other sites More sharing options...
costadina Posted May 10, 2009 Author Share Posted May 10, 2009 When I get back in the office next week I will try all your suggestions. David, thanks for posting the code. Since I am unfamiliar with Lisp, could you describe your variables (ll tdef ln ss fe fd ld) so I can better understand the program. Quote Link to comment Share on other sites More sharing options...
David Bethel Posted May 10, 2009 Share Posted May 10, 2009 They're actually pretty simple ll = users_layer_list tdef = table_definition ln = layer_name ss - selection_set fe - first_block_nested_entity_ename fd - fe_dxf_definition ld - layer_definition ll is the only 1 you would need to modify to your needs. The rest are autonomous in the program. -David Quote Link to comment Share on other sites More sharing options...
costadina Posted May 10, 2009 Author Share Posted May 10, 2009 Thankyou, David Quote Link to comment Share on other sites More sharing options...
