DODGE Posted February 14, 2010 Share Posted February 14, 2010 Hi guys The dimension leader I use is the right angle arrow and Architectural ticks for dimensions. Is there a way of making just the right angle arrow part of the leader a thicker line, also the same with the Arch tick. Cheers Dodge Quote Link to comment Share on other sites More sharing options...
BearDyugin Posted February 14, 2010 Share Posted February 14, 2010 Either my English or your description will not allow to understand you completely. I will assume, use of type of an arrow "User" can will help you Quote Link to comment Share on other sites More sharing options...
DODGE Posted February 14, 2010 Author Share Posted February 14, 2010 Either my English or your description will not allow to understand you completely.I will assume, use of type of an arrow "User" can will help you I want to make the arrow head / Point thicker lines than the arrow shaft so to speak. Cheers Dodge Quote Link to comment Share on other sites More sharing options...
eldon Posted February 14, 2010 Share Posted February 14, 2010 The open 90 arrow head is a block, so if you want a thicker arrow head, you will have to re-define the block. Just remember to move the arrow head, so that when you give it a width, the outside corner is at the correct point. The Architectural tick is already a wide line, but if you want it wider, you can just re-define it. Quote Link to comment Share on other sites More sharing options...
nukecad Posted February 14, 2010 Share Posted February 14, 2010 If you are using a colour dependent plot style (.ctb) than you could set the arrow/tick to a colour that will plot thicker whilst leaving the dimension line at its current colour. Quote Link to comment Share on other sites More sharing options...
DODGE Posted February 14, 2010 Author Share Posted February 14, 2010 The open 90 arrow head is a block, so if you want a thicker arrow head, you will have to re-define the block. Just remember to move the arrow head, so that when you give it a width, the outside corner is at the correct point. The Architectural tick is already a wide line, but if you want it wider, you can just re-define it. Thanks for your help. I did do a bit of reading last night from my Cad bible and I found out it is a block. Thanks for your explanation and diag. Has the weather improved in the UK yet? I am really looking forward to the winter here, I am over this heat. Dodge. Quote Link to comment Share on other sites More sharing options...
