JoeA Posted March 5, 2010 Share Posted March 5, 2010 Hello, Using AutoCAD2009, I have created a logo out of splines, and filled in the gaps with solid colour using the hatch command. I have then deleted the construction splines around the hatch so that the printout does not show black lines around the edge. In paperspace the logo looks fine: But when I print to PDF the outside bit has a really jagged edge (but not the inside section for some reason? - The only difference is I used a colour gradient on the outer sections): What could be the problem? Cheers, Joe Quote Link to comment Share on other sites More sharing options...
JoeA Posted May 19, 2010 Author Share Posted May 19, 2010 Just bumping in case any one new has any ideas... Quote Link to comment Share on other sites More sharing options...
deres Posted May 19, 2010 Share Posted May 19, 2010 You are having problems with the gradient fill because Autocad exports it as a bitmap (while it exports solid hatches as vector objects). That's why you are getting these jagged edges...and as far as I know there is no way to increase the bitmap resolution while exporting to PDF. Have you tried to use larger paper size? (I mean to increase your logo...) Quote Link to comment Share on other sites More sharing options...
JoeA Posted May 19, 2010 Author Share Posted May 19, 2010 So if I didnt use the gradient, and just used a solid colour it would work OK? That might have to be the solution. Many thanks! Quote Link to comment Share on other sites More sharing options...
Dana W Posted May 19, 2010 Share Posted May 19, 2010 It may also be the issues AutoCAD 2009 has with overloading pdf files with kilobytes it doesn't need. I have 2009 and the pdf reolution and image integrity is awful. Then I plot the very same drawing using Autodesk TrueView 2010 and the resulting pdf is crystal clear and nearly 70% smaller in overall file size. Quote Link to comment Share on other sites More sharing options...
