Visual Styles Default Settings wanted

Regarding Ready-to-use Visual Styles. I have found that Reset to Default doesn't set everything back to default. For example in the Realistic, Edge Settings, Number of lines - I had changed it to 50 and perhaps other settings too. Comforted by the thought that one click everything would go back to Default. But so far I realise the Number of lines remains 50, I believe the default should be (4?).

Given this inccident, I think I should better check through all the Visual Styles to see if all details are now in default. Where can I get hold of all the default setting details please?

Thanks in advance.

Number of lines? Would that be ISOLINES we're talking about?

Yes. In the Layer Properties Manager, under the title Edge Settings, Edge mode in Realistic is Isolines, Number of lines is the next row.

You are correct. The default setting is 4. This can be invoked at the command line using the ISOLINES command. Per your AutoCAD Help file this value is an integer saved in the drawing itself not in the Windows Registry like some other settings. The range is from 0 to 2047.

You are correct. The default setting is 4.

That's what I meant. Why Reset to Default doesn't give you back all the original default setting? And that's why I'll need to check through all details for myself one by one hence I need all the correct default settings of the Ready-to-use Styles.

This tip, courtesy of Shaan Hurley and his blog Between the Lines, published 05 February 2008 will reset ALL system variables to their original defaults.



USE AT YOUR OWN RISK.



"Two files, defaults.svf and defaults.scr, are installed in the Express directory along with the System Variable Editor. These files contain AutoCAD's default system variable settings for a new installation of AutoCAD. To return AutoCAD to a 'pristine' system variable state you can either read the defaults.svf file into SYSVDLG or run the defaults.scr file from the AutoCAD command line using the SCRIPT command. Be aware that this will overwrite any system variable settings in the drawing you are currently editing."



I repeat: USE AT YOUR OWN RISK.



I assume no responsibility as to the outcome of using this advice. But it seems to me you might be able to cull out the info you seek specific to your visual styles default settings from the script file. You do know what you're looking for right?

Thanks ReMark but I do not want to take the risk.

Would someone if he/she knows for sure that theirs' are the real original default settings, just print and post the table of each of the Ready-to-use Visual Style from the Visual Style Manager please?

Are you a man or a mouse? Don't be such a wimp.



If you know what system variables you're interested in then open the default.scr file with Notepad and search through it until you find those variables.

Default system variables from 2009. Should be close enough for your use.



(setvar "3DDWFPREC" 2)

(setvar "3DCONVERSIONMODE" 1)

(setvar "3DSELECTIONMODE" 1)

(setvar "ACADLSPASDOC" 0)

(setvar "ACISOUTVER" 70)

(setvar "ACTPATH" "")

(setvar "ACTUI" 6)

(setvar "AFLAGS" 16)

(setvar "ANGBASE" 0.0000)

(setvar "ANGDIR" 0)

(setvar "ANNOALLVISIBLE" 1)

(setvar "ANNOAUTOSCALE" -4)

(setvar "ANNOTATIVEDWG" 0)

(setvar "APBOX" 0)

(setvar "APERTURE" 10)

(setvar "ATTDIA" 0)

(setvar "ATTIPE" 0)

(setvar "ATTMODE" 1)

(setvar "ATTMULTI" 1)

(setvar "ATTREQ" 1)

(setvar "AUDITCTL" 0)

(setvar "AUNITS" 0)

(setvar "AUPREC" 0)

(setvar "AUTODWFPUBLISH" 0)

(setvar "AUTOSNAP" 63)

(setvar "BACKGROUNDPLOT" 2)

(setvar "BACTIONCOLOR" "7")

(setvar "BDEPENDENCYHIGHLIGHT" 1)

(setvar "BGRIPOBJCOLOR" "141")

(setvar "BGRIPOBJSIZE"

(setvar "BINDTYPE" 0)

(setvar "BLIPMODE" 0)

(setvar "BLOCKEDITLOCK" 0)

(setvar "BPARAMETERCOLOR" "7")

(setvar "BPARAMETERFONT" "Simplex.shx")

(setvar "BPARAMETERSIZE" 12)

(setvar "BTMARKDISPLAY" 1)

(setvar "BVMODE" 0)

(setvar "CALCINPUT" 1)

(setvar "CAMERADISPLAY" 0)

(setvar "CAMERAHEIGHT" 0)

(setvar "CANNOSCALE" "1:1")

(setvar "CECOLOR" "ByLayer")

(setvar "CELTSCALE" 1.0000)

(setvar "CELTYPE" "ByLayer")

(setvar "CELWEIGHT" -1)

(setvar "CENTERMT" 0)

(setvar "CHAMFERA" 0.0000)

(setvar "CHAMFERB" 0.0000)

(setvar "CHAMFERC" 0.0000)

(setvar "CHAMFERD" 0.0000)

(setvar "CHAMMODE" 0)

(setvar "CIRCLERAD" 0.0000)

(setvar "CLAYER" "0")

(setvar "CMATERIAL" "ByLayer")

(setvar "CMDDIA" 1)

(setvar "CMDECHO" 1)

(setvar "CMDINPUTHISTORYMAX" 20)

(setvar "CMLEADERSTYLE" "Standard")

(setvar "CMLJUST" 0)

(setvar "CMLSCALE" 1.0000)

(setvar "CMLSTYLE" "Standard")

(setvar "COMPASS" 0)

(setvar "COORDS" 1)

(setvar "COPYMODE" 0)

(setvar "CROSSINGAREACOLOR" 3)

(setvar "CSHADOW" 0)

(setvar "CTABLESTYLE" "Standard")

(setvar "CURSORSIZE" 5)

(setvar "CVPORT" 2)

(setvar "DATALINKNOTIFY" 2)

(setvar "DBLCLKEDIT" 1)

(setvar "DEFAULTLIGHTING" 1)

(setvar "DEFAULTLIGHTINGTYPE" 1)

(setvar "DELOBJ" 1)

(setvar "DEMANDLOAD" 3)

(setvar "DGNFRAME" 0)

(setvar "DGNOSNAP" 1)

(setvar "DIMADEC" 0)

(setvar "DIMALT" 0)

(setvar "DIMALTD" 2)

(setvar "DIMALTF" 25.4000)

(setvar "DIMALTRND" 0.0000)

(setvar "DIMALTTD" 2)

(setvar "DIMALTTZ" 0)

(setvar "DIMALTU" 2)

(setvar "DIMALTZ" 0)

(setvar "DIMAPOST" "")

(setvar "DIMARCSYM" 0)

(setvar "DIMASSOC" 2)

(setvar "DIMASZ" 0.1800)

(setvar "DIMATFIT" 3)

(setvar "DIMAUNIT" 0)

(setvar "DIMAZIN" 0)

(setvar "DIMBLK" "")

(setvar "DIMBLK1" "")

(setvar "DIMBLK2" "")

(setvar "DIMCEN" 0.0900)

(setvar "DIMCLRD" 0)

(setvar "DIMCLRE" 0)

(setvar "DIMCLRT" 0)

(setvar "DIMDEC" 4)

(setvar "DIMDLE" 0.0000)

(setvar "DIMDLI" 0.3800)

(setvar "DIMDSEP" ".")

(setvar "DIMEXE" 0.1800)

(setvar "DIMEXO" 0.0625)

(setvar "DIMFIT" 3)

(setvar "DIMFRAC" 0)

(setvar "DIMFXL" 1.0000)

(setvar "DIMFXLON" 0)

(setvar "DIMGAP" 0.0900)

(setvar "DIMJOGANG" 45.0000)

(setvar "DIMJUST" 0)

(setvar "DIMLDRBLK" "")

(setvar "DIMLFAC" 1.0000)

(setvar "DIMLIM" 0)

(setvar "DIMLTEX1" "")

(setvar "DIMLTEX2" "")

(setvar "DIMLTYPE" "")

(setvar "DIMLUNIT" 2)

(setvar "DIMLWD" -2)

(setvar "DIMLWE" -2)

(setvar "DIMPOST" "")

(setvar "DIMRND" 0.0000)

(setvar "DIMSAH" 0)

(setvar "DIMSCALE" 1.0000)

(setvar "DIMSD1" 0)

(setvar "DIMSD2" 0)

(setvar "DIMSE1" 0)

(setvar "DIMSE2" 0)

(setvar "DIMSOXD" 0)

(setvar "DIMTAD" 0)

(setvar "DIMTDEC" 4)

(setvar "DIMTFAC" 1.0000)

(setvar "DIMTFILL" 0)

(setvar "DIMTFILLCLR" 0)

(setvar "DIMTIH" 1)

(setvar "DIMTIX" 0)

(setvar "DIMTM" 0.0000)

(setvar "DIMTMOVE" 0)

(setvar "DIMTOFL" 0)

(setvar "DIMTOH" 1)

(setvar "DIMTOL" 0)

(setvar "DIMTOLJ" 1)

(setvar "DIMTP" 0.0000)

(setvar "DIMTSZ" 0.0000)

(setvar "DIMTVP" 0.0000)

(setvar "DIMTXSTY" "Standard")

(setvar "DIMTXT" 0.1800)

(setvar "DIMTZIN" 0)

(setvar "DIMUPT" 0)

(setvar "DIMZIN" 0)

(setvar "DISPSILH" 0)

(setvar "DONUTID" 0.5000)

(setvar "DONUTOD" 1.0000)

(setvar "DRAGMODE" 2)

(setvar "DRAGP1" 10)

(setvar "DRAGP2" 25)

(setvar "DRAGVS" "")

(setvar "DRAWORDERCTL" 3)

(setvar "DTEXTED" 2)

(setvar "DWFFRAME" 2)

(setvar "DWFOSNAP" 1)

(setvar "DWGCHECK" 1)

(setvar "DXEVAL" 12)

(setvar "DYNDIGRIP" 31)

(setvar "DYNDIVIS" 1)

(setvar "DYNMODE" 3)

(setvar "DYNPICOORDS" 0)

(setvar "DYNPIFORMAT" 0)

(setvar "DYNPIVIS" 1)

(setvar "DYNPROMPT" 1)

(setvar "DYNTOOLTIPS" 1)

(setvar "EDGEMODE" 0)

(setvar "ELEVATION" 0.0000)

(setvar "EXPERT" 0)

(setvar "EXPLMODE" 1)

(setvar "EXTNAMES" 1)

(setvar "FACETRATIO" 0)

(setvar "FACETRES" 0.5000)

(setvar "FIELDDISPLAY" 1)

(setvar "FIELDEVAL" 31)

(setvar "FILEDIA" 1)

(setvar "FILLETRAD" 0.0000)

(setvar "FILLMODE" 1)

(setvar "FONTALT" "simplex.shx")

(setvar "FONTMAP" "acad.fmp")

(setvar "FULLPLOTPATH" 1)

(setvar "GRIDDISPLAY" 2)

(setvar "GRIDMAJOR" 5)

(setvar "GRIDMODE" 0)

(setvar "GRIDUNIT" '(0.5000 0.5000))

(setvar "GRIPBLOCK" 0)

(setvar "GRIPCOLOR" 160)

(setvar "GRIPDYNCOLOR" 140)

(setvar "GRIPHOT" 1)

(setvar "GRIPHOVER" 3)

(setvar "GRIPOBJLIMIT" 100)

(setvar "GRIPS" 1)

(setvar "GRIPSIZE" 5)

(setvar "GRIPTIPS" 1)

(setvar "GTAUTO" 1)

(setvar "GTDEFAULT" 0)

(setvar "GTLOCATION" 0)

(setvar "HALOGAP" 0)

(setvar "HIDEPRECISION" 0)

(setvar "HIDETEXT" 1)

(setvar "HIGHLIGHT" 1)

(setvar "HPANG" 0.0000)

(setvar "HPASSOC" 1)

(setvar "HPBOUND" 1)

(setvar "HPDOUBLE" 0)

(setvar "HPDRAWORDER" 3)

(setvar "HPGAPTOL" 0.0000)

(setvar "HPINHERIT" 0)

(setvar "HPMAXLINES" 1000000)

(setvar "HPNAME" "ANSI31")

(setvar "HPOBJWARNING" 10000)

(setvar "HPORIGIN" (0 0))

(setvar "HPORIGINMODE" 0)

(setvar "HPSCALE" 1.0000)

(setvar "HPSEPARATE" 0)

(setvar "HPSPACE" 1.0000)

(setvar "HYPERLINKBASE" "")

(setvar "IMAGEHLT" 0)

(setvar "IMPLIEDFACE" 1)

(setvar "INDEXCTL" 0)

(setvar "INETLOCATION" "http://www.autodesk.com")

(setvar "INPUTHISTORYMODE" 15)

(setvar "INSBASE" (0.0000 0.0000 0.0000))

(setvar "INSNAME" "")

(setvar "INSUNITS" 1)

(setvar "INSUNITSDEFSOURCE" 1)

(setvar "INSUNITSDEFTARGET" 1)

(setvar "INTELLIGENTUPDATE" 20)

(setvar "INTERFERECOLOR" "1")

(setvar "INTERFEREOBJVS" "Realistic")

(setvar "INTERFEREVPVS" "3D Wireframe")

(setvar "INTERSECTIONCOLOR" 257)

(setvar "INTERSECTIONDISPLAY" 0)

(setvar "ISAVEBAK" 1)

(setvar "ISAVEPERCENT" 50)

(setvar "ISOLINES" 4)

(setvar "LASTPOINT" (0.0000 0.0000 0.0000))

(setvar "LAYEREVAL" 1)

(setvar "LAYERFILTERALERT" 2)

(setvar "LAYERNOTIFY" 15)

(setvar "LAYLOCKFADECTL" 50)

(setvar "LAYOUTREGENCTL" 2)

(setvar "LEGACYCTRLPICK" 0)

(setvar "LENSLENGTH" 50.0000)

(setvar "LIGHTGLYPHDISPLAY" 1)

(setvar "LIGHTINGUNITS" 0)

(setvar "LIGHTSINBLOCKS" 0)

(setvar "LIMCHECK" 0)

(setvar "LIMMAX" '(12.0000 9.0000))

(setvar "LIMMIN" '(0.0000 0.0000))

(setvar "LINEARBRIGHTNESS" 0)

(setvar "LINEARCONTRAST" 0)

(setvar "LOCKUI" 0)

(setvar "LOFTANG1" 90.0000)

(setvar "LOFTANG2" 90.0000)

(setvar "LOFTMAG1" 0.0000)

(setvar "LOFTMAG2" 0.0000)

(setvar "LOFTNORMALS" 1)

(setvar "LOFTPARAM" 7)

(setvar "LOGEXPBRIGHTNESS" 65.0000)

(setvar "LOGEXPCONTRAST" 50.0000)

(setvar "LOGEXPDAYLIGHT" 2)

(setvar "LOGEXPMIDTONES" 1.0000)

(setvar "LOGEXPPHYSICALSCALE" 1500.0000)

(setvar "LOGFILEMODE" 0)

(setvar "LONGITUDE")

(setvar "LTSCALE" 1.0000)

(setvar "LUNITS" 2)

(setvar "LUPREC" 4)

(setvar "LWDEFAULT" 25)

(setvar "LWDISPLAY" 0)

(setvar "LWUNITS" 1)

(setvar "MAXACTVP" 64)

(setvar "MAXSORT" 1000)

(setvar "MBUTTONPAN" 1)

(setvar "MEASUREINIT" 0)

(setvar "MEASUREMENT" 0)

(setvar "MENUCTL" 1)

(setvar "MENUECHO" 0)

(setvar "MIRRTEXT" 1)

(setvar "MLEADERSCALE" 1)

(setvar "MODEMACRO" "")

(setvar "MSOLESCALE" 1.0000)

(setvar "MSLTSCALE" 1)

(setvar "MTEXTED" "Internal")

(setvar "MTEXTFIXED" 2)

(setvar "MTEXTTOOLBAR" 2)

(setvar "MTJIGSTRING" "abc")

(setvar "NAVVCUBEDISPLAY" 1)

(setvar "NAVVCUBELOCATION" 0)

(setvar "NAVVCUBEOPACITY" 50)

(setvar "NAVVCUBESIZE" 1)

(setvar "NAVSWHEELMODE" 0)

(setvar "NAVSWHEELOPACITYBIG" 50)

(setvar "NAVSWHEELOPACITYMINI" 50)

(setvar "NAVSWHEELSIZEBIG" 1)

(setvar "NAVSWHEELSIZEMINI" 1)

(setvar "NOMUTT" 0)

(setvar "OBSCUREDCOLOR" 257)

(setvar "OBSCUREDLTYPE" 0)

(setvar "OFFSETDIST" -1.0000)

(setvar "OFFSETGAPTYPE" 0)

(setvar "OLEFRAME" 2)

(setvar "OLEHIDE" 0)

(setvar "OLEQUALITY" 3)

(setvar "OLESTARTUP" 0)

(setvar "ORTHOMODE" 0)

(setvar "OSMODE" 37)

(setvar "OSNAPCOORD" 2)

(setvar "OSNAPNODELEGACY" 0)

(setvar "OSNAPZ" 0)

(setvar "OSOPTIONS" 3)

(setvar "PALETTEOPAQUE" 0)

(setvar "PAPERUPDATE" 0)

(setvar "PDMODE" 0)

(setvar "PDSIZE" 0.0000)

(setvar "PEDITACCEPT" 0)

(setvar "PELLIPSE" 0)

(setvar "PERSPECTIVE")

(setvar "PERSPECTIVECLIP" 5.0000)

(setvar "PICKADD" 1)

(setvar "PICKAUTO" 1)

(setvar "PICKBOX" 3)

(setvar "PICKDRAG" 0)

(setvar "PICKFIRST" 1)

(setvar "PICKSTYLE" 1)

(setvar "PLINEGEN" 0)

(setvar "PLINETYPE" 2)

(setvar "PLINEWID" 0.0000)

(setvar "PLOTOFFSET" 0)

(setvar "PLOTROTMODE" 2)

(setvar "PLOTTER" 0)

(setvar "PLQUIET" 0)

(setvar "POLARADDANG" "")

(setvar "POLARANG" 90.0000)

(setvar "POLARDIST" 0.0000)

(setvar "POLARMODE" 0)

(setvar "POLYSIDES" 4)

(setvar "PREVIEWEFFECT" 2)

(setvar "PREVIEWFILTER" 7)

(setvar "PROJECTNAME" "")

(setvar "PROJMODE" 1)

(setvar "PROXYGRAPHICS" 1)

(setvar "PROXYNOTICE" 1)

(setvar "PROXYSHOW" 1)

(setvar "PROXYWEBSEARCH" 0)

(setvar "PSLTSCALE" 1)

(setvar "PSOLHEIGHT" 4.0000)

(setvar "PSOLWIDTH" 0.2500)

(setvar "PSTYLEPOLICY" 1)

(setvar "PSVPSCALE" 0.0000)

(setvar "PUBLISHALLSHEETS" 1)

(setvar "PUBLISHCOLLATE" 1)

(setvar "PUBLISHHATCH" 1)

(setvar "PUCSBASE" "")

(setvar "QTEXTMODE" 0)

(setvar "RASTERDPI" 300)

(setvar "RASTERPERCENT" 20)

(setvar "RASTERPREVIEW" 1)

(setvar "RASTERTHRESHOLD" 20)

(setvar "RECOVERYMODE" 2)

(setvar "REGENMODE" 1)

(setvar "RE-INIT" 0)

(setvar "REMEMBERFOLDERS" 1)

(setvar "RENDERUSERLIGHTS" 1)

(setvar "REPORTERROR" 1)

(setvar "RTDISPLAY" 1)

(setvar "SAVEFIDELITY" 1)

(setvar "SAVETIME" 10)

(setvar "SELECTIONANNODISPLAY" 1)

(setvar "SELECTIONAREA" 1)

(setvar "SELECTIONAREAOPACITY" 25)

(setvar "SELECTIONPREVIEW" 3)

(setvar "SETBYLAYERMODE" 127)

(setvar "SHADEDGE" 3)

(setvar "SHADEDIF" 70)

(setvar "SHADOWPLANELOCATION" 0.0000)

(setvar "SHORTCUTMENU" 11)

(setvar "SHOWHIST" 1)

(setvar "SHOWLAYERUSAGE" 0)

(setvar "SHPNAME" "")

(setvar "SIGWARN" 1)

(setvar "SKETCHINC" 0.1000)

(setvar "SKPOLY" 0)

(setvar "SNAPANG" 0.0000)

(setvar "SNAPBASE" (0.0000 0.0000))

(setvar "SNAPISOPAIR" 0)

(setvar "SNAPMODE" 0)

(setvar "SNAPSTYL" 0)

(setvar "SNAPTYPE" 0)

(setvar "SNAPUNIT" (0.5000 0.5000))

(setvar "SOLIDCHECK" 1)

(setvar "SOLIDHIST" 1)

(setvar "SORTENTS" 127)

(setvar "SPLFRAME" 0)

(setvar "SPLINESEGS"

(setvar "SPLINETYPE" 6)

(setvar "SSLOCATE" 1)

(setvar "SSMAUTOOPEN" 1)

(setvar "SSMPOLLTIME" 60)

(setvar "SSMSHEETSTATUS" 2)

(setvar "STANDARDSVIOLATION" 2)

(setvar "STARTUP" 0)

(setvar "STATUSBAR" 0)

(setvar "STEPSIZE" 6.0000)

(setvar "STEPSPERSEC" 2.0000)

(setvar "SUNSTATUS" 1.0000)

(setvar "SURFTAB1" 6)

(setvar "SURFTAB2" 6)

(setvar "SURFTYPE" 6)

(setvar "SURFU" 6)

(setvar "SURFV" 6)

(setvar "TABLEINDICATOR" 1)

(setvar "TABLETOOLBAR" 2)

(setvar "TABMODE" 0)

(setvar "TBCUSTOMIZE" 1)

(setvar "TEMPOVERRIDES" 1)

(setvar "TEXTEVAL" 0)

(setvar "TEXTFILL" 1)

(setvar "TEXTOUTPUTFILEFORMAT" 0)

(setvar "TEXTQLTY" 50)

(setvar "TEXTSIZE" 0.2000)

(setvar "TEXTSTYLE" "Standard")

(setvar "THICKNESS" 0.0000)

(setvar "TILEMODE" 1)

(setvar "TIMEZONE" -8000)

(setvar "TOOLTIPMERGE" 0)

(setvar "TOOLTIPS" 1)

(setvar "TRACEWID" 0.0500)

(setvar "TRACKPATH" 0)

(setvar "TRAYICONS" 1)

(setvar "TRAYNOTIFY" 1)

(setvar "TRAYTIMEOUT" 0)

(setvar "TREEDEPTH" 3020)

(setvar "TREEMAX" 10000000)

(setvar "TRIMMODE" 1)

(setvar "TSPACEFAC" 1.0000)

(setvar "TSPACETYPE" 1)

(setvar "TSTACKALIGN" 1)

(setvar "TSTACKSIZE" 70)

(setvar "UCSAXISANG" 90)

(setvar "UCSBASE" "World")

(setvar "UCSDETECT" 1)

(setvar "UCSFOLLOW" 0)

(setvar "UCSICON" 3)

(setvar "UCSORTHO" 1)

(setvar "UCSVIEW" 1)

(setvar "UCSVP" 1)

(setvar "UNITMODE" 0)

(setvar "UPDATETHUMBNAIL" 15)

(setvar "USERI1" 0)

(setvar "USERI2" 0)

(setvar "USERI3" 0)

(setvar "USERI4" 0)

(setvar "USERI5" 0)

(setvar "USERR1" 0.0000)

(setvar "USERR2" 0.0000)

(setvar "USERR3" 0.0000)

(setvar "USERR4" 0.0000)

(setvar "USERR5" 0.0000)

(setvar "USERS1" "")

(setvar "USERS2" "")

(setvar "USERS3" "")

(setvar "USERS4" "")

(setvar "USERS5" "")

(setvar "VISRETAIN" 1)

(setvar "VPLAYEROVERRIDESMODE" 1)

(setvar "VSBACKGROUNDS" 1)

(setvar "VSEDGECOLOR" "ByEntity")

(setvar "VSEDGEJITTER" -2)

(setvar "VSEDGEOVERHANG" -6)

(setvar "VSEDGES" 1)

(setvar "VSEDGESMOOTH" 1)

(setvar "VSFACECOLORMODE" 0)

(setvar "VSFACEHIGHLIGHT" -30)

(setvar "VSFACEOPACITY" -60)

(setvar "VSFACESTYLE" 1)

(setvar "VSHALOGAP" 0)

(setvar "VSHIDEPRECISION" 0)

(setvar "VSINTERSECTIONCOLOR" 7)

(setvar "VSINTERSECTIONEDGES" "0")

(setvar "VSINTERSECTIONLTYPE" 1)

(setvar "VSISOONTOP" 0)

(setvar "VSLIGHTINGQUALITY" 1)

(setvar "VSMATERIALMODE" 0)

(setvar "VSMONOCOLOR" "255,255,255")

(setvar "VSOBSCUREDCOLOR" "ByEntity")

(setvar "VSOBSCUREDEDGES" 0)

(setvar "VSOBSCUREDLTYPE" 1)

(setvar "VSSHADOWS" 0)

(setvar "VSSILHEDGES" 0)

(setvar "VSSILHWIDTH" 5)

(setvar "VTDURATION" 750)

(setvar "VTENABLE" 3)

(setvar "VTFPS" 7)

(setvar "WHIPARC" 0)

(setvar "WHIPTHREAD" 1)

(setvar "WINDOWAREACOLOR" 5)

(setvar "WMFBKGND" 0)

(setvar "WMFFOREGND" 0)

(setvar "WORLDVIEW" 1)

(setvar "XCLIPFRAME" 0)

(setvar "XEDIT" 1)

(setvar "XFADECTL" 50)

(setvar "XLOADCTL" 2)

(setvar "XREFCTL" 0)

(setvar "XREFNOTIFY" 2)

(setvar "XREFTYPE" 0)

(setvar "ZOOMFACTOR" 60)

(setvar "ZOOMWHEEL" 0)

I hate it when this happens. Should be 8 followed by a ) .

My friend, I am only the AutoCAD End User, sorry to disappoint you that I've no idea of how to use your information.

I've never got enough hours each day to do/catch up with everything that I wish I could.

Really? We went through all of this and you're clueless? I need another hobby.



I would have expected you to know the system variables that you were interested in changing. Examples include, but are not limited to...



ISOLINES



DISPSILH



SPLINESEGS



FACETRES



VSEDGES (and all its variations)



...just to name a handful.



Oh well, I guess you have two choices. 1) Reset ALL variables using the method I previously described or 2) live with what you currently have.



Good luck with whatever option you choose.

What happens if you WBLOCK your drawing entities out to a new file?

What happens if you

WBLOCK

your drawing entities out to a new file?

No, it means exactly what I told you earlier and that is the value is an integer that is saved with the drawing. Each drawing can have a different setting.
