    Default Plotting Specific Paper Sizes VBA

    Registered forum members do not see this ad.

    All,

    I'm looking for a little help with plotting specific paper sizes in VBA. I'm writing a program that gives the drafters in our group a little flexibility. The program allows them to pick available plotters from a list and then allows them to set up what paper sizes they want printed where. For instance, A size: InkJet 1 (8.5x11), B size: InkJet 1 (11x17), C size: Oce Plotter (... etc etc). All the drawings selected, if they are a certain size should then be plotted to the predetermined plotter.

    I can get it to print to the proper printer but I don't know how to set the proper paper size. I've demonstrated an ability to do it using sendcommand, but I know that's poor programming. Is there a way of plottingtodevice using a specific available paper size?

  2. #2
    Junior Member
    Using
    AutoCAD 2007
    Join Date
    May 2010
    Posts
    10

    Default

    Well I figured out how to do that part. Now I just need to figure out how to get the program to wait long enough for the previous job to print before going onto the next one.

  3. #3
    Junior Member
    Using
    AutoCAD 2007
    Join Date
    May 2010
    Posts
    10

    Default

    Disregard this entirely... figured it out.

  4. #4
    Senior Member Kerry Brown's Avatar
    Using
    not applicable
    Join Date
    Jan 2006
    Location
    Brisbane, Australia UTC+10
    Posts
    195

    Default

    Quote Originally Posted by EGoldberg View Post
    Disregard this entirely... figured it out.
    That's great.

    For those following, what was the solution you arrived at ??
    Perfection is not optional.
    another Swamper

  5. #5
    Junior Member
    Using
    AutoCAD 2007
    Join Date
    May 2010
    Posts
    10

    Default

    Registered forum members do not see this ad.

    I just typed a whole nice description up with details and everything but because there was links to my source info and I have 8 posts instead of the 9 necessary to post links; I lost everything. I don't really have the time to go into detail again but if you have any questions, please let me know. Basically I use two user forms. One contains a list of all the drawings and sizes, the other contains labels that store the plotter info and the paper sizes available to each plotter and what was selected for size A, B, C, D, and E. Using that info, the plotter info is compared to the size of the drawing and plotted to the correct plotter.

    Userform1 - code snippet
    Code:
    For I = ListBox1.ListCount - 1 To 0 Step -1
        If ListBox1.Selected(I) = True Then
            tdd = Split(ListBox1.list(I), " - ")
            If tdd(2) <> "Size: Unknown!" Then
                Application.Documents(tdd(0)).Activate
                Thisdrawing.ActiveLayout = Thisdrawing.Layouts(tdd(1))
                sze = Right(tdd(2), 1)

    var_BGPlot = Thisdrawing.GetVariable("BACKGROUNDPLOT")
    Thisdrawing.SetVariable "BACKGROUNDPLOT", 0
    bResult = True
    getBackPlot = bResult

                Select Case sze
                Case "A"
                    pltps = Split(PSS.Label9.Caption, " - ")
                Case "B"
                    pltps = Split(PSS.Label10.Caption, " - ")
                Case "C"
                    pltps = Split(PSS.Label11.Caption, " - ")

                Case "D"
                    pltps = Split(PSS.Label12.Caption, " - ")

                Case "E"
                    pltps = Split(PSS.Label13.Caption, " - ")


                End Select


    Thisdrawing.PlotConfigurations.Add "TESTPC2", True
    Thisdrawing.ActiveLayout.ConfigName = pltps(0)
    Thisdrawing.PlotConfigurations.Item("TESTPC2").ConfigName = pltps(0)
    Thisdrawing.ActiveLayout.StyleSheet = "NU-STD.stb"
    Thisdrawing.PlotConfigurations.Item("TESTPC2").StyleSheet = "NU-STD.stb"
    cmn = Thisdrawing.ActiveLayout.GetCanonicalMediaNames
    For qq = 0 To UBound(cmn)
    lcn = Thisdrawing.ActiveLayout.GetLocaleMediaName(cmn(qq))
         If lcn = pltps(1) Then

            Thisdrawing.ActiveLayout.CanonicalMediaName = cmn(qq)
            Thisdrawing.PlotConfigurations.Item("TESTPC2").CanonicalMediaName = cmn(qq)


            Thisdrawing.ActiveLayout.StandardScale = acScaleToFit
            Thisdrawing.PlotConfigurations.Item("TESTPC2").StandardScale = acScaleToFit
            Thisdrawing.ActiveLayout.CenterPlot = True
            Thisdrawing.PlotConfigurations.Item("TESTPC2").CenterPlot = True


            Thisdrawing.ActiveLayout.RefreshPlotDeviceInfo

            Thisdrawing.ActiveLayout.RefreshPlotDeviceInfo
            Thisdrawing.PlotConfigurations.Item("TESTPC2").RefreshPlotDeviceInfo

            Thisdrawing.ActiveLayout.RefreshPlotDeviceInfo

            Thisdrawing.Plot.PlotToDevice pltps(0) '"TESTPC2"
            Thisdrawing.ActiveLayout.RefreshPlotDeviceInfo

                 Thisdrawing.PlotConfigurations.Item("TESTPC2").Delete




    Thisdrawing.SetVariable "BACKGROUNDPLOT", var_BGPlot

         End If
    Next


            End If
        End If
    Next I
    Userform(2) PSS

    Code:
    Private Declare Function GetProfileString Lib "kernel32" _
            Alias "GetProfileStringA" _
            (ByVal lpAppName As String, _
             ByVal lpKeyName As String, _
             ByVal lpDefault As String, _
             ByVal lpReturnedString As String, _
             ByVal nSize As Long) As Long

    Private Const DC_PAPERNAMES = &H10
    Private Declare Function DeviceCapabilities _
      Lib "winspool.drv" _
        Alias "DeviceCapabilitiesA" _
          (ByVal lpDeviceName As String, _
           ByVal lpPort As String, _
           ByVal iIndex As Long, _
           ByRef lpOutput As Any, _
           ByRef lpDevMode As Any) _
        As Long
    Private Declare Function StrLen _
      Lib "kernel32.dll" _
        Alias "lstrlenA" _
          (ByVal lpString As String) _
        As Long

    Private Sub CommandButton1_Click()
    If ListBox1.ListIndex > -1 And ListBox2.ListIndex > -1 Then
        If CheckBox1.value = True Then
            Label9.Caption = ListBox1.value & " - " & ListBox2.value
        ElseIf CheckBox2.value = True Then
            Label10.Caption = ListBox1.value & " - " & ListBox2.value
        ElseIf CheckBox3.value = True Then
            Label11.Caption = ListBox1.value & " - " & ListBox2.value
        ElseIf CheckBox4.value = True Then
            Label12.Caption = ListBox1.value & " - " & ListBox2.value
        ElseIf CheckBox5.value = True Then
            Label13.Caption = ListBox1.value & " - " & ListBox2.value
        End If

    End If
    End Sub
    Private Sub CommandButton2_Click()
    PSS.Hide
    End Sub
    Private Sub Label5_Click()
    End Sub

    Private Sub ListBox1_Click()
        ListBox2.Clear
        Call WinNTSetDefaultPrinterAvailPS
    End Sub
    Private Sub UserForm_Initialize()
        Dim r As Long
        Dim Buffer As String
        ' Get the list of available printers from WIN.INI
        Buffer = Space(8192)
        r = GetProfileString("PrinterPorts", vbNullString, "", _
           Buffer, Len(Buffer))
        ' Display the list of printer in the ListBox List1

        ParseList ListBox1, Buffer

    End Sub
    Private Sub ParseList(lstCtl As Control, ByVal Buffer As String)
        Dim I As Integer
        Dim s As String
        Do
            I = InStr(Buffer, Chr(0))
            If I > 0 Then
                s = Left(Buffer, I - 1)
                If Len(Trim(s)) Then lstCtl.AddItem s
                Buffer = Mid(Buffer, I + 1)
            Else
                If Len(Trim(Buffer)) Then lstCtl.AddItem Buffer
                Buffer = ""
            End If
        Loop While I > 0
    End Sub
    Private Sub GetDriverAndPort(ByVal Buffer As String, DriverName As _
        String, PrinterPort As String)
        Dim iDriver As Integer
        Dim iPort As Integer
        DriverName = ""
        PrinterPort = ""
        ' The driver name is first in the string terminated by a comma
        iDriver = InStr(Buffer, ",")
        If iDriver > 0 Then
             ' Strip out the driver name
            DriverName = Left(Buffer, iDriver - 1)
            ' The port name is the second entry after the driver name
            ' separated by commas.
            iPort = InStr(iDriver + 1, Buffer, ",")
            If iPort > 0 Then
                ' Strip out the port name
                PrinterPort = Mid(Buffer, iDriver + 1, _
                iPort - iDriver - 1)
            End If
        End If
    End Sub
    Private Sub WinNTSetDefaultPrinterAvailPS()
        Dim Buffer As String
        Dim DeviceName As String
        Dim DriverName As String
        Dim PrinterPort As String
        Dim PrinterName As String
        Dim r As Long
        If ListBox1.ListIndex > -1 Then
            ' Get the printer information for the currently selected
            ' printer in the list. The information is taken from the
            ' WIN.INI file.
            Buffer = Space(1024)
            PrinterName = ListBox1.Text
            r = GetProfileString("PrinterPorts", PrinterName, "", _
                Buffer, Len(Buffer))
            ' Parse the driver name and port name out of the buffer
            GetDriverAndPort Buffer, DriverName, PrinterPort
            x = Buffer & " " & DriverName & " " & PrinterPort
          '  ListBox2.AddItem x

            PD = PrinterName
            PD1 = DriverName
        Ret = DeviceCapabilities(PD, PD1, DC_PAPERNAMES, ByVal 0&, ByVal 0&)
       'resize the array
        ReDim PaperSizes(0 To Ret * 64) As Byte
       'retrieve all the available paper names
        Call DeviceCapabilities(PD, PD1, DC_PAPERNAMES, PaperSizes(0), ByVal 0&)
       'convert the retrieved byte array to an ANSI string
        AllNames = StrConv(PaperSizes, vbUnicode)
         'loop through the string and search for the names of the papers
          For I = 1 To Len(AllNames) Step 64
            PaperSize = Mid(AllNames, I, 64)
            PaperSize = Left(PaperSize, StrLen(PaperSize))
           ' Msg = Msg & PaperSize & vbCrLf
           If InStr(LCase(PaperSize), "custom") = 0 Then
           ListBox2.AddItem PaperSize
           End If
          Next I
        'MsgBox "Supported Paper Sizes:" & vbCrLf & vbCrLf & Msg, vbOKOnly, PD0


        End If
    End Sub
    Do note that my code eliminates "custom" sized paper. Let me know if you have any questions. And again, sorry for the lack of details but I just don't have the time to explain again right now :-/
