mikeymike Posted November 17, 2010 Share Posted November 17, 2010 Hello, I am trying to subtract 2 objects from eachother. The first is a solid (cylinder) and the second is a revolve surface (I revolved from a curve). I found out I cannot subtract a surface from a solid. I also cannot convert the revolved surface to a solid. How can I fix it? How can I make the object solid to subract from the cylinder? Thanks Mike Quote Link to comment Share on other sites More sharing options...
JD Mather Posted November 17, 2010 Share Posted November 17, 2010 Perhaps Slice with the Surface option. Attach your file here. Have you done the tutorials in my signature? Quote Link to comment Share on other sites More sharing options...
mikeymike Posted November 17, 2010 Author Share Posted November 17, 2010 Hello, no I didn't the tutorials yet. I will look after it. I attached 2 dwg files (acad 2011) with the curve imported from Maya and the final drawing. I want to subtract the object from the cylinder. booleanl-def.dwg curve-drawing.dwg Quote Link to comment Share on other sites More sharing options...
ajamit007 Posted November 17, 2010 Share Posted November 17, 2010 In "curve-drawing.dwg" the top & bottom end of the spline is not perpendicular, so it will only revolve to surface, try to make it perpendicular so it will be solid.. Quote Link to comment Share on other sites More sharing options...
mikeymike Posted November 17, 2010 Author Share Posted November 17, 2010 what do you mean with perpendicular? The top and the bottom have to be a straight perpendicular line at the end? Quote Link to comment Share on other sites More sharing options...
JD Mather Posted November 17, 2010 Share Posted November 17, 2010 (edited) Not sure what ajamit meant, but you should create a line connecting the open endpoints of the curve. PE to join and then revolve to get a revolved solid. Edited November 18, 2010 by JD Mather Quote Link to comment Share on other sites More sharing options...
mikeymike Posted November 17, 2010 Author Share Posted November 17, 2010 how can I best do that? What do you mean by PE to join? I am a real newbe in autocad, sorry..... Quote Link to comment Share on other sites More sharing options...
ajamit007 Posted November 18, 2010 Share Posted November 18, 2010 I guess this is what you are trying to achieve.. booleanl-def.zip Quote Link to comment Share on other sites More sharing options...
ReMark Posted November 18, 2010 Share Posted November 18, 2010 PE is short for Polyline Edit. This command has an option for joining both separate by contiguous lines and polylines into a single continuous entity. When working with lines the user is prompted to change them to polylines for the command to work properly. Quote Link to comment Share on other sites More sharing options...
mikeymike Posted November 18, 2010 Author Share Posted November 18, 2010 thanks all for the answers! @ajamit007: YES! thats what I am looking for. How did you made it? Quote Link to comment Share on other sites More sharing options...
ajamit007 Posted November 18, 2010 Share Posted November 18, 2010 (edited) The mistake you made was that you didn't made the top and bottom end point perpendicular. (In attachment you will see that there is vertical line from top to bottom for reference, there was a small gap left on bottom which i have highlighted in red mark). I didn't opted you to go for "Pe" command cause it will lead to unusual number of arc/lines if you converted spline to pline (your curve was spline), cause in Revolve command u just need to make sure that start point of polyline and end point are perpendicular to make it Solid, if its not then revolve command will convert polyline/spline into surface.. Note :- My English is not that good curve-drawing-Model.pdf Edited November 18, 2010 by ajamit007 Added Disclaimer warning about Bad English...... Quote Link to comment Share on other sites More sharing options...
mikeymike Posted November 18, 2010 Author Share Posted November 18, 2010 thanks ajamit007, i saw that you are right, they are not at the same level of eachother. But now I fixed it and revolved again, but still an error in the boolean subtract that my object is a surface. What else I do wrong? Quote Link to comment Share on other sites More sharing options...
ajamit007 Posted November 18, 2010 Share Posted November 18, 2010 Option 2, Draw a vertical from top to bottom and apply a region command, and then apply revolve command, make sure that the revolved curve is "3D Solid" in the properties..then try to subtract it from the Cylinder.. Quote Link to comment Share on other sites More sharing options...
JD Mather Posted November 18, 2010 Share Posted November 18, 2010 thanks ajamit007, i saw that you are right, they are not at the same level of eachother. But now I fixed it and revolved again, but still an error in the boolean subtract that my object is a surface. What else I do wrong? Well, now that you have it closed the Slice with Surface option should work. Quote Link to comment Share on other sites More sharing options...
mikeymike Posted November 20, 2010 Author Share Posted November 20, 2010 just one try left: i made a solid from the curve and place it on top of a cylinder. But it will not work at my side, because the boolean subtract didn't do anything. Can you give it a try and tell me please what went wrong? boolean-solids.dwg Quote Link to comment Share on other sites More sharing options...
