ketongin Posted October 30, 2011 Share Posted October 30, 2011 (edited) Hi all, I'm having trouble with a conditional statement and probably you can help me out. 1. I have point A and point B pick. 2. How can I know which side my pick 3 lies on point A and point B. Thank you! Edited October 30, 2011 by ketongin Quote Link to comment Share on other sites More sharing options...
Tharwat Posted October 30, 2011 Share Posted October 30, 2011 One way could be as following .... (and (setq p1 (getpoint "\n Specify Point A :")) (setq p2 (getpoint p1 "\n Specify Point B :")) (setq p3 (getpoint "\n Specify Point C :")) ) (cond ( (and (> (cadr p3) (cadr p1)) (< (car p3) (car p2))) (princ "\n Point C is on the Left side ") ) ( (and (> (car p3) (car p1)) (< (cadr p3) (car p2))) (princ "\n Point C is on the Right side ") ) ) Quote Link to comment Share on other sites More sharing options...
pBe Posted October 30, 2011 Share Posted October 30, 2011 (defun c:test (/ p1 p2 p3 p1_ p2_) (setq p1 (getpoint "\nPick Point1") p2 (getpoint "\nPick Point2") p3 (getpoint "\nPick Point3") ) (setq p1_ (polar p1 (angle p1 p2)( / (distance p1 p2) 2)) p2_ (car (vl-sort (list p1 p2) (function (lambda (y1 y2) (> (cadr y1) (cadr y2))))))) (if (<= (c:cal "ang(p1_,p2_,p3)") 180) (princ "\nUpper Side of P1 P2") (princ "\nLower Side of P1 P2") ) (princ) ) Quote Link to comment Share on other sites More sharing options...
David Bethel Posted October 30, 2011 Share Posted October 30, 2011 You have nine possible results for this query, the four compass directions N,S,E,W four quadrants NE SE SW NW or the point is on the line. Is that what you are trying to discern? -David Quote Link to comment Share on other sites More sharing options...
Lee Mac Posted October 30, 2011 Share Posted October 30, 2011 (edited) ;; Side of Ray - Lee Mac ;; Args: pt - test point, l1,l2 - points defining ray ;; Returns: ;; 0 if pt lies on ray ;; -1 if pt is right of ray ;; 1 if pt is left of ray (defun LM:SideOfRay ( pt l1 l2 / x ) (cond ( (equal (setq x (sin (- (angle l1 pt) (angle l1 l2)))) 0.0 1e-14) 0) ( (minusp x) -1) ( 1 ) ) ) Test function: (defun c:test ( / p1 p2 p3 x ) (if (and (setq p1 (getpoint "\nPick First Point of Line: ")) (setq p2 (getpoint p1 "\nPick Second Point of Line: ")) (setq p3 (getpoint "\nPick Point to Test: ")) ) (alert (cond ( (zerop (setq x (LM:SideOfRay (trans p3 1 0) (trans p1 1 0) (trans p2 1 0)))) "Point is on Line." ) ( (minusp x) "Point is to the Right of Line." ) ( "Point is to the Left of Line." ) ) ) ) (princ) ) Edited October 30, 2011 by Lee Mac Added test function Quote Link to comment Share on other sites More sharing options...
pBe Posted October 30, 2011 Share Posted October 30, 2011 Lee, on a different note: How would you do inverse cosine? Quote Link to comment Share on other sites More sharing options...
Lee Mac Posted October 30, 2011 Share Posted October 30, 2011 Lee, How would you do inverse cosine? http://lee-mac.com/mathematicalfunctions.html#trigonometric Quote Link to comment Share on other sites More sharing options...
pBe Posted October 30, 2011 Share Posted October 30, 2011 http://lee-mac.com/mathematicalfunctions.html#trigonometric Thank you Lee Quote Link to comment Share on other sites More sharing options...
ketongin Posted October 30, 2011 Author Share Posted October 30, 2011 All possible results. You have nine possible results for this query, the four compass directions N,S,E,W four quadrants NE SE SW NW or the point is on the line. Is that what you are trying to discern? -David Quote Link to comment Share on other sites More sharing options...
ketongin Posted October 30, 2011 Author Share Posted October 30, 2011 Thank you ALL and to you Lee. Works as I envision it but it only on the WCS. Well it doesn't matter since I'm a having trouble with my points anyway. After I'm done with my routine, I'm planning to make it work on all viewports, so I need a little help with polar points with trans function. Autodesk reference guide just confuse me on trans. If I have point1 (setq pt1 (trans pt1 0 1)) (setq ang angx) (setq pt1x (polar (polar pt1 (- ang (-pi 90)) 6) ang 10))[color="red"] <<<-- how to use trans here[/color] I'm having trouble with trans when I get my points via polar. Thanks again. ;; Side of Ray - Lee Mac ;; Args: pt - test point, l1,l2 - points defining ray ;; Returns: ;; 0 if pt lies on ray ;; -1 if pt is right of ray ;; 1 if pt is left of ray (defun LM:SideOfRay ( pt l1 l2 / x ) (cond ( (equal (setq x (sin (- (angle l1 pt) (angle l1 l2)))) 0.0 1e-14) 0) ( (minusp x) -1) ( 1 ) ) ) Test function: (defun c:test ( / p1 p2 p3 x ) (if (and (setq p1 (getpoint "\nPick First Point of Line: ")) (setq p2 (getpoint p1 "\nPick Second Point of Line: ")) (setq p3 (getpoint "\nPick Point to Test: ")) ) (alert (cond ( (zerop (setq x (LM:SideOfRay (trans p3 1 0) (trans p1 1 0) (trans p2 1 0)))) "Point is on Line." ) ( (minusp x) "Point is to the Right of Line." ) ( "Point is to the Left of Line." ) ) ) ) (princ) ) Quote Link to comment Share on other sites More sharing options...
Lee Mac Posted October 30, 2011 Share Posted October 30, 2011 You're welcome ketongin You would need to provide a little more information about what you are trying to achieve - I can't determine much from the few lines of code you have posted (e.g. how is pt1 obtained, etc) Quote Link to comment Share on other sites More sharing options...
ketongin Posted October 30, 2011 Author Share Posted October 30, 2011 (edited) Sorry about that. I'm really confuse and can't really understand trans function with polar points even after reading about it. Perhaps this simple example will make me understand it more. Thanks Lee. (setq pt1 (trans (getpoint) 0 1)) (setq pt2 ((getpoint) 0 1)) (setq ang (angle pt1 pt2)) (setq pt1a (polar (polar pt1 (- ang (-pi 90)) 6) ang 10)) [color="red"]<<-- trans this point[/color] (setq pt1b (polar (polar pt1 (+ ang (-pi 90)) 6) ang 10)) [color="red"]<<-- trans this point[/color] Edited October 30, 2011 by ketongin *polar points Quote Link to comment Share on other sites More sharing options...
Lee Mac Posted October 30, 2011 Share Posted October 30, 2011 How do you want the result to be displayed? For example, if you are creating Lines, the resultant points need to be defined in WCS, whereas if you are creating LWPolylines they need to be in OCS, or if you are using grvecs / grdraw to display something, in UCS. The following is an example using Lines. This will work in all UCS for which the UCS plane is parallel to the WCS plane; to account for ALL UCS planes, more transformations are required, but we'll start off easy: (defun c:test ( / _line pt1 pt2 pt1a pt1b ang ) (defun _line ( a b ) (entmakex (list (cons 0 "LINE") (cons 10 a) (cons 11 b)))) (if (and (setq pt1 (getpoint "\nPt1: ")) (setq pt2 (getpoint "\nPt2: " pt1)) ) (progn ;; 'getpoint' returns points in UCS ;; pt1 = UCS ;; pt2 = UCS ;; 'angle' returns the angle measured from ;; the X-Axis of the current construction plane. (setq ang (angle pt1 pt2)) ;; Now to calculate the points using the polar function: (setq pt1a (polar (polar pt1 (- ang (/ pi 2.)) 6.0) ang 10.0 ) ) (setq pt1b (polar (polar pt1 (+ ang (/ pi 2.)) 6.0) ang 10.0 ) ) ;; Lines are defined in WCS, so now we transform all points ;; from UCS to WCS: (setq pt1 (trans pt1 1 0) pt1a (trans pt1a 1 0) pt1b (trans pt1b 1 0) ) ;; Display the result: (_line pt1 pt1a) (_line pt1 pt1b) ) ) (princ) ) Quote Link to comment Share on other sites More sharing options...
ketongin Posted October 30, 2011 Author Share Posted October 30, 2011 Thank you Lee, I've learned a lot on this tutorial, If Autodesk made their explanation like your's that would be much simpler for us newbies. And by the way can I steal your niffty code. I always been using (entmakex) each time I'm creating a line. (defun _line ( a b ) (entmakex (list (cons 0 "LINE") (cons 10 a) (cons 11 b)))) So I don't need (setq pt1 (trans (getpoint) 0 1))? How do you want the result to be displayed? For example, if you are creating Lines, the resultant points need to be defined in WCS, whereas if you are creating LWPolylines they need to be in OCS, or if you are using grvecs / grdraw to display something, in UCS. The following is an example using Lines. This will work in all UCS for which the UCS plane is parallel to the WCS plane; to account for ALL UCS planes, more transformations are required, but we'll start off easy: (defun c:test ( / _line pt1 pt2 pt1a pt1b ang ) (defun _line ( a b ) (entmakex (list (cons 0 "LINE") (cons 10 a) (cons 11 b)))) (if (and (setq pt1 (getpoint "\nPt1: ")) (setq pt2 (getpoint "\nPt2: " pt1)) ) (progn ;; 'getpoint' returns points in UCS ;; pt1 = UCS ;; pt2 = UCS ;; 'angle' returns the angle measured from ;; the X-Axis of the current construction plane. (setq ang (angle pt1 pt2)) ;; Now to calculate the points using the polar function: (setq pt1a (polar (polar pt1 (- ang (/ pi 2.)) 6.0) ang 10.0 ) ) (setq pt1b (polar (polar pt1 (+ ang (/ pi 2.)) 6.0) ang 10.0 ) ) ;; Lines are defined in WCS, so now we transform all points ;; from UCS to WCS: (setq pt1 (trans pt1 1 0) pt1a (trans pt1a 1 0) pt1b (trans pt1b 1 0) ) ;; Display the result: (_line pt1 pt1a) (_line pt1 pt1b) ) ) (princ) ) Quote Link to comment Share on other sites More sharing options...
Lee Mac Posted October 30, 2011 Share Posted October 30, 2011 Thank you Lee, I've learned a lot on this tutorial, If Autodesk made their explanation like your's that would be much simpler for us newbies. Thanks, I'm glad it was comprehensible. And by the way can I steal your niffty code. I always been using (entmakex) each time I'm creating a line. (defun _line ( a b ) (entmakex (list (cons 0 "LINE") (cons 10 a) (cons 11 b)))) You can use it if you wish. So I don't need (setq pt1 (trans (getpoint) 0 1))? No, since getpoint returns points in UCS, not WCS. If you needed the point in WCS, you would use: (trans (getpoint "\nPoint: ") 1 0) Quote Link to comment Share on other sites More sharing options...
ketongin Posted October 30, 2011 Author Share Posted October 30, 2011 That sets it all. Much thanks Lee... Quote Link to comment Share on other sites More sharing options...
pBe Posted October 31, 2011 Share Posted October 31, 2011 I only realize just now that geomcal is not pre-loaded on a drawing session, (defun c:test (/ p1 p2 p3 p1_ p2_) [color=blue][b](if (not (member "geomcal.arx" (arx))) (arxload "geomcal") ) [/b][/color] (setq p1 (getpoint "\nPick Point1") p2 (getpoint "\nPick Point2") p3 (getpoint "\nPick Point3") ) (setq p1_ (polar p1 (angle p1 p2) (/ (distance p1 p2) 2)) p2_ (car (vl-sort (list p1 p2) (function (lambda (y1 y2) (> (cadr y1) (cadr y2)) ) ) ) ) ) (if (<= (c:cal "ang(p1_,p2_,p3)") 180) (princ "\nUpper Side of P1 P2") (princ "\nLower Side of P1 P2") ) (princ) ) is it the same case for newer cad versions? Quote Link to comment Share on other sites More sharing options...
alanjt Posted October 31, 2011 Share Posted October 31, 2011 You can also use the area of a triangle... (defun AT:TriangleArea (a b c) ;; Returns area of three provided points ;; If returned value is negative, last point (c) exists on right side of a-b vector ;; Alan J. Thompson, 06.09.10 (/ (- (* (- (car b) (car a)) (- (cadr c) (cadr a))) (* (- (cadr b) (cadr a)) (- (car c) (car a))) ) 2. ) ) Quote Link to comment Share on other sites More sharing options...
ketongin Posted November 1, 2011 Author Share Posted November 1, 2011 Thanks pBe. I'll also include this on my artillery of sub routines. How can I live without you guys. Thank you very much! I only realize just now that geomcal is not pre-loaded on a drawing session, (defun c:test (/ p1 p2 p3 p1_ p2_) [color=blue][b](if (not (member "geomcal.arx" (arx))) (arxload "geomcal") ) [/b][/color] (setq p1 (getpoint "\nPick Point1") p2 (getpoint "\nPick Point2") p3 (getpoint "\nPick Point3") ) (setq p1_ (polar p1 (angle p1 p2) (/ (distance p1 p2) 2)) p2_ (car (vl-sort (list p1 p2) (function (lambda (y1 y2) (> (cadr y1) (cadr y2)) ) ) ) ) ) (if (<= (c:cal "ang(p1_,p2_,p3)") 180) (princ "\nUpper Side of P1 P2") (princ "\nLower Side of P1 P2") ) (princ) ) is it the same case for newer cad versions? Quote Link to comment Share on other sites More sharing options...
