jmerch Posted April 6, 2012 Share Posted April 6, 2012 I haven't used PDF Underlays very much as we're always given CAD backgrounds. In this case, I used them to quickly put in since we won't get CAD files. However, they are scanned PDF's so they are essentially raster images. They have jagged lines, etc. Is there a way to just lighten these when plotting so I can still use them as my background? or should I just bite the bullet and trace them to get actual ACAD lines to be able to control in plotting? Quote Link to comment Share on other sites More sharing options...
ReMark Posted April 9, 2012 Share Posted April 9, 2012 Do you put the underlay on its own layer? Quote Link to comment Share on other sites More sharing options...
jmerch Posted April 9, 2012 Author Share Posted April 9, 2012 yes, doesn't help. the scanned lines still show up as dark as they were plotted. I'm guessing there is no way around this since it's pretty much a raster image... Quote Link to comment Share on other sites More sharing options...
ReMark Posted April 9, 2012 Share Posted April 9, 2012 Have you tried changing the color of the layer? Have you tried adjusting the screening percentage? Quote Link to comment Share on other sites More sharing options...
jmerch Posted April 9, 2012 Author Share Posted April 9, 2012 Yes, yes. Doesn't affect the actual image lines. Quote Link to comment Share on other sites More sharing options...
ReMark Posted April 9, 2012 Share Posted April 9, 2012 I'm all out of ideas. Quote Link to comment Share on other sites More sharing options...
jmerch Posted April 9, 2012 Author Share Posted April 9, 2012 hopefully we can get a fresh batch in. Thanks for the suggestions though. Quote Link to comment Share on other sites More sharing options...
tzframpton Posted April 9, 2012 Share Posted April 9, 2012 I always convert to monochrome TIFF. The reasons: TIFF can inherit the color properties of the layer it's on, including colors that are set to screen in your CTB/STB plot style. The performance is much better than PDF, albeit still not perfect. Here's the online converter I use: http://pdf.my-addr.com/free-online-pdf-to-tiff-convert.php If you still want to use PDF, then try using the Transparency setting to see if that works. Quote Link to comment Share on other sites More sharing options...
jmerch Posted April 9, 2012 Author Share Posted April 9, 2012 ahh.....ADJUST. That's the command. Quote Link to comment Share on other sites More sharing options...
