nnutting Posted July 17, 2012 Share Posted July 17, 2012 So I'm having an issue with draw order... I have a base with a solid screened hatch that is xrefed into a sheet file in model space. I have text, reference bubbles, dimensions, etc in paper space. When I print, the information in paper space that is above the hatch isn't showing up. Usually the information in paper space would show up when I print without having to deal with draw order...I have made sure that the hatch is in the back (the very back of everything)...and I'm still having the same problem. Any tips? Quote Link to comment Share on other sites More sharing options...
Dadgad Posted July 17, 2012 Share Posted July 17, 2012 If the hatch is part of the XREF I don't believe that the program will recognize it as hatch unless the xref is exploded. I could be wrong, but you could try and see if that resolves it. Quote Link to comment Share on other sites More sharing options...
nnutting Posted July 17, 2012 Author Share Posted July 17, 2012 I don't want to bind the xref to the sheet file in order to xplode the drawing. Quote Link to comment Share on other sites More sharing options...
rickh Posted July 18, 2012 Share Posted July 18, 2012 There is a check box in the plot dialog to "plot paperspace last". Is that checked? Quote Link to comment Share on other sites More sharing options...
