tarnoki Posted October 12, 2010 Share Posted October 12, 2010 We have some drawings where we've xref'd floor plans of adjacent buildings and annotated it with leaders (in model space) inside of a master file (eg Bldg1-1st flr, Bldg2-1st flr, Bldg3-1st flr all xref'd into Master1stflr.dwg). The individual floor plans contain a hatch layer color coding each room on the plans indicating departmental ownership. The leaders are all drawn on one layer called MC-TEXT in the master file. Our problem is the the leader annotations show up above the xref when drawn, but upon reloading the xref or re-opening the master file, the xref jumps to the front and covers up the leaders. I've tried to send the leaders to the front and the xref's to the back to no avail. Is there a command I can apply the in the master drawing that will hold the draw order upon xref reloading? Should I be pushing the xref's to the back or the leaders to the front? Is there a way to set draworder of layers? When invoking the draworder command, how do I call out a specific xref to push to back (without selecting the object with cursor...eg send Bldg1-1st flr xref to back)? Thanks for any advice in advance. Steve Quote Link to comment Share on other sites More sharing options...
