    Default Any way to convert 3D face into a 3D solid?

    Registered forum members do not see this ad.

    I have this chair in 3d but it consists of 3d faces and i can not convert all of them into sufraces or solids...only the faces that are on the same plane can be converted.Since the object is a little curved...i get the message"faces are not coplanar"...or something.
    Need your help asap.
    Thanks.

  2. #2
    Super Moderator Cad64's Avatar
    Computer Details
    Cad64's Computer Details
    Operating System:
    Windows 7 Profesional x64
    Computer:
    XI Computers
    Motherboard:
    Asus P8Z77-V Pro
    CPU:
    Intel Core I7 3770K 4.1 Ghz Quad Core 3rd Gen
    RAM:
    24GB DDR3 @ 1333MHz
    Graphics:
    Nvidia GeForce GTX 570 1280MB GDDR5
    Primary Storage:
    SATAII 500GB 7200 RPM
    Secondary Storage:
    Western Digital My Book Studio Edition II - 2TB capacity
    Monitor:
    HPf2105 21" LCD Widescreen & Cintiq 21ux
    Discipline
    Multi-disciplinary
    Cad64's Discipline Details
    Occupation
    Freelance Digital Artist
    Discipline
    Multi-disciplinary
    Details
    3D model building, texturing and rendering. Photoshop Color Graphics.
    Using
    AutoCAD 2014
    Join Date
    Feb 2006
    Location
    Southern California
    Posts
    10,143

    Default

    You could give this 'mesh-to-solid' routine a try: http://discussion.autodesk.com/threa...hreadID=469691
    CGSociety Portfolio: http://rdeweese.cgsociety.org/
    Facebook:
    https://www.facebook.com/rdeweese67/


    "Work Smart, Not Hard"

  3. #3
    Senior Member Lazarus's Avatar
    Computer Details
    Lazarus's Computer Details
    Operating System:
    Windows 7 x64
    Motherboard:
    ASUS P5Q-E
    CPU:
    Intel Core2 Quad Q9550
    RAM:
    8Gb DDR2 800Mhz
    Graphics:
    ATI HD4850
    Primary Storage:
    WD Caviar Black
    Monitor:
    Dell U2311H
    Using
    AutoCAD 2010
    Join Date
    Apr 2006
    Location
    Skopje,Macedonia
    Posts
    206

    Default

    Thanks for the reply Cad64,but it doesn't work.The M2S lisp is asking a polygon mesh to solidify,but since i'm selecting a 3D face i get the message "that is not a polygon mesh".
    But thak you for the reply anyway.

  4. #4
    Administrator CADTutor's Avatar
    Computer Details
    CADTutor's Computer Details
    Operating System:
    Windows 7 Home Premium 64bit
    Motherboard:
    Asus P7P55D-E PRO
    CPU:
    Intel Core i7-860
    RAM:
    4GB PC3-12800 C8 Corsair Dominator
    Graphics:
    NVIDIA Quadro FX 1800 768 MB
    Primary Storage:
    Intel X25-M SSD 160GB
    Secondary Storage:
    Samsung Spinpoint 320GB
    Monitor:
    BenQ FP241W 24" Wide
    Discipline
    Education
    CADTutor's Discipline Details
    Occupation
    Senior Lecturer (Digital Design), Landscape Architect & Web Designer
    Discipline
    Education
    Using
    AutoCAD 2015
    Join Date
    Aug 2002
    Location
    Hampshire, UK
    Posts
    3,731

    Default

    Have you tried CONVTOSOLID?
    Tip: Please do not PM or email me with CAD questions - use the forums, you'll get an answer sooner.
    AutoCAD Tutorials | How to add images to your posts | How to register successfully | Forum FAQ

  5. #5
    Senior Member Lazarus's Avatar
    Computer Details
    Lazarus's Computer Details
    Operating System:
    Windows 7 x64
    Motherboard:
    ASUS P5Q-E
    CPU:
    Intel Core2 Quad Q9550
    RAM:
    8Gb DDR2 800Mhz
    Graphics:
    ATI HD4850
    Primary Storage:
    WD Caviar Black
    Monitor:
    Dell U2311H
    Using
    AutoCAD 2010
    Join Date
    Apr 2006
    Location
    Skopje,Macedonia
    Posts
    206

    Default

    Quote Originally Posted by CADTutor View Post
    Have you tried CONVTOSOLID?
    It can't be done...the only way i could convert something from the object into a solid was a tiny fraction of the faces wich were on the same plane...with this procedure : CONVTOSURFACE,then THICKEN ...but nevermind i needed this to create a section from that chair for a school project, and it's too late now .

    Edit: 100th post,woo!

  6. #6
    Junior Member
    Using
    ADT 2008
    Join Date
    Mar 2009
    Posts
    12

    Default

    I had the similar situation and I found a solution...at least it worked perfectly fine for me...I hope it will help you to get your problem solved...

    I had shape with quite complex geometry created in Architectural Desktop...I did this shape by drawing up 3D faces so eventually I could move the edges and stretch any of these faces as I wanted...then the next step for me was to get this new shape with many 3d faces in ADT as a 3d solid...it took me a while to find a way how to do this quickly without redoing the this new shape as a solid...here is a few very simple steps that I did...

    1. Saved this new file with many many 3d faces as a dwg file
    2. Imported this file into the 3dsmax (not by using file link manager...it will not work...this file must be imported as a dwg)
    3. When this file was imported I exported it as a dwg file instantly without doing anything else in 3ds max...
    4. Then I opened this new exported file in ADT and converted it as a Mass Element with Mass Element Tool
    5. Then I converted this new shape from a mass element to 3D solid with 3D solids Tool in ADT and that’s it...

    Now this new shape is 3D solid and it shouldn’t take more then a minute to do this if you have ADT and 3ds max already installed ...I hope this helps

  7. #7
    Luminous Being JD Mather's Avatar
    Using
    Inventor 2015
    Join Date
    Sep 2007
    Location
    Williamsport, PA
    Posts
    8,719

    Default

    Quote Originally Posted by Lazarus View Post
    I have this chair in 3d but it consists of 3d faces and i can not convert all of them into sufraces or solids...
    Can you zip and attach the file here?
    Attached Images
    Certified SolidWorks Professional
    Autodesk Inventor 2015 Certified Professional
    Autodesk AutoCAD 2013 Certified Professional

  8. #8
    Senior Member Lazarus's Avatar
    Computer Details
    Lazarus's Computer Details
    Operating System:
    Windows 7 x64
    Motherboard:
    ASUS P5Q-E
    CPU:
    Intel Core2 Quad Q9550
    RAM:
    8Gb DDR2 800Mhz
    Graphics:
    ATI HD4850
    Primary Storage:
    WD Caviar Black
    Monitor:
    Dell U2311H
    Using
    AutoCAD 2010
    Join Date
    Apr 2006
    Location
    Skopje,Macedonia
    Posts
    206

    Default

    well this is a blast form the past!
    But i still didn't resolve the issue....
    DidzisK Thanks for the suggestion but i don't use Autocad Architecture.
    JD Mather Here's the file.
    Thanks.
    Attached Files

  9. #9
    Forum Newbie trubin's Avatar
    Computer Details
    trubin's Computer Details
    Operating System:
    Windows Vista Home Premium (6.0, Build 6001) Service Pack 1 (6001.longhorn_rtm.080118-1840)
    Motherboard:
    NVIDIA nForce790i Ultra SLI
    CPU:
    Intel(R) Core(TM)2 Duo CPU E8500 @ 3.16GHz (2 CPUs), ~3.2GHz
    RAM:
    4GB Patriot Viper DDR3 1333MHz
    Graphics:
    512MB NVIDIA GeForce 9600 GT Superclocked
    Primary Storage:
    250GB SATA 3Gb/s 7,200RPM 16MB Cache
    Monitor:
    22" Samsung 2253BW 1680 x 1050 (2ms) Widescreen
    Using
    AutoCAD 2009
    Join Date
    Feb 2009
    Location
    Brooklyn NY
    Posts
    7

    Default

    I thought convtosolid command would work, but it doesn't.

  10. #10
    Junior Member
    Using
    ADT 2008
    Join Date
    Mar 2009
    Posts
    12

    Default

    Registered forum members do not see this ad.

    Lazarus many thanks for this model! I wanted to give it a try and test if convert to mass element and 3d solid tool in ADT can help solving this 3d face to 3d solid problem with this drawing and actually it did pretty well I think... I have managed to get this as a 3d solid but had to slice the solid to reduce the file size as it is about 650KB when zipped… I have given a ref. point on the drawing to merge the slices together…

    The only thing that I did notice using ADT was that converting to solid would not be possible is any of the 3d face objects has a gaps or isn't fully closed...or 3d faces are crossing each other...and when converting the 3d solid it is almost identical to original model from 3d faces...meshy !
    Attached Files
