Getstring Question

[harrison-matt]

Oh and man i was close, before i checked back here i was hot on the tail of

(vla-put-textalignmentpoint TEXT (vlax-3d-point begin))

.



Thanks,



matt

[harrison-matt]

Why is my angtos making a loop?

(angtos 0.603369 0 2)



Matt

[harrison-matt]

All,



If we can revisit this, i am having some trouble with creating a polyline:

  (while (= "" (setq content (getstring t "\nContents Within Box: ")))
   (princ "\nInvalid key: Enter the contents: "))
 (if (setq point (getpoint "\nCenter of cell: "))
   (progn (setq tObj (vla-AddText
  (vlax-get-property (vla-get-ActiveDocument (vlax-get-acad-object))
    (if (= 1 (getvar 'CVPORT)) 'PaperSpace 'ModelSpace))
  content
  (vlax-3D-point point)
  0.09375))
     (vla-put-Alignment tObj acAlignmentMiddleCenter)
     (vla-put-TextAlignmentPoint tObj (vlax-3D-point point))
     (setq BL (+ (* (strlen content) 0.1) 0.2))
     (setq P1 (polar (polar point pi (/ bl 2)) (/ pi 2) 0.125)
    p2 (polar p1 (/ (* 3 pi) 2) 0.25)
    p3 (polar (polar point 0 (/ bl 2)) (/ (* 3 pi) 2) 0.125)
    p4 (polar p3 (/ pi 2) 0.25))
     (entmakeX (list (cons 0 "LWPOLYLINE")
       (cons 100 "AcDbEntity")
       (cons 100 "AcDbPolyline")
       (cons 70 1)
       (cons 90 4)
       (cons 10 p1)
       (cons 11 p2)
       (cons 12 p3)
       (cons 13 p4)
       (cons 39 0.01)))))

[BlackBox]

All,



If we can revisit this, i am having some trouble with creating a polyline:


(while (= "" (setq content (getstring t "\nContents Within Box: ")))
   (princ "\nInvalid key: Enter the contents: "))
 (if (setq point (getpoint "\nCenter of cell: "))
   (progn (setq tObj (vla-AddText
  (vlax-get-property (vla-get-ActiveDocument (vlax-get-acad-object))
    (if (= 1 (getvar 'CVPORT)) 'PaperSpace 'ModelSpace))
  content
  (vlax-3D-point point)
  0.09375))
     (vla-put-Alignment tObj acAlignmentMiddleCenter)
     (vla-put-TextAlignmentPoint tObj (vlax-3D-point point))
     (setq BL (+ (* (strlen content) 0.1) 0.2))
     (setq P1 (polar (polar point pi (/ bl 2)) (/ pi 2) 0.125)
    p2 (polar p1 (/ (* 3 pi) 2) 0.25)
    p3 (polar (polar point 0 (/ bl 2)) (/ (* 3 pi) 2) 0.125)
    p4 (polar p3 (/ pi 2) 0.25))
     (entmakeX (list (cons 0 "LWPOLYLINE")
       (cons 100 "AcDbEntity")
       (cons 100 "AcDbPolyline")
       (cons 70 1)
       (cons 90 4)
       (cons 10 p1)
       (cons 1[color=red]1[/color] p2)
       (cons 1[color=red]2[/color] p3)
       (cons 1[color=red]3[/color] p4)
       (cons 39 0.01)))))





Okay... I wonder what kind of trouble?



Perhaps a closer analysis of your code shall *reveal* something worthy of note?



... But then again, the polyline would still not yet be closed.

[Lee Mac]

Matt,



Did you actually read the link in my post #19?

[harrison-matt]

I did briefly, I am confused on the lambda, function, append bit and willl revisit that later.

[BlackBox]

I did briefly, I am confused on the lambda, function, append bit and willl revisit that later.



Perhaps a closer analysis of your code shall *reveal* something worthy of note?



... But then again, the polyline would still not yet be closed.



... If only you were able to look at your code through my eyes (or my post?), as if I'd left you hint of where to look. :wink:

[harrison-matt]

I actually have picked up on your hint and moved on, ps i the polyline closes now as well, just alittle re-arranging etc. Here it is:

(defun c:test ( / content point tobj BL p1 p2 p3 p4)
 (vl-load-com)

 (while (= "" (setq content (strcase (getstring t "\nContents Within Box: "))))
   (princ "\nInvalid key: Enter the contents: "))
 (if (setq point (getpoint "\nCenter of cell: "))
   (progn (setq tObj (vla-AddText
  (vlax-get-property (vla-get-ActiveDocument (vlax-get-acad-object))
    (if (= 1 (getvar 'CVPORT)) 'PaperSpace 'ModelSpace))
  content
  (vlax-3D-point point)
  0.09375))
     (vla-put-Alignment tObj acAlignmentMiddleCenter)
     (vla-put-TextAlignmentPoint tObj (vlax-3D-point point))
     (setq BL (+ (* (strlen content) 0.1) 0.2))
     (setq P1 (polar (polar point pi (/ bl 2)) (/ pi 2) 0.125)
    p2 (polar p1 (/ (* 3 pi) 2) 0.25)
    p3 (polar (polar point 0 (/ bl 2)) (/ (* 3 pi) 2) 0.125)
    p4 (polar p3 (/ pi 2) 0.25))
     (entmakeX (list (cons 0 "LWPOLYLINE")
       (cons 100 "AcDbEntity")
       (cons 100 "AcDbPolyline")
       (cons 90 4)
       (cons 10 p1)
       (cons 10 p2)
       (cons 10 p3)
       (cons 10 p4)
       (cons 10 p1)
       (cons 70 1)
       (cons 39 0.01))))))



Thank you for your help, now if i can only get the dang thing to fillet as well, more points i assume.



Thanks again for your help,

Matt



Any thoughts on fillets?

[BlackBox]

I actually have picked up on your hint and moved on, ps i the polyline closes now as well, just alittle re-arranging etc.

Thank you for your help





You're welcome.





Any thoughts on fillets?





"No Sir, I don't like [them]."



[harrison-matt]

Hello i have updated my code:



(defun c:test ( / content point tobj BL p1 p2 p3 p4)
 (vl-load-com)

 (while (= "" (setq content (strcase (getstring t "\nContents Within Box: "))))
   (princ "\nInvalid key: Enter the contents: "))
 (if (setq point (getpoint "\nCenter of cell: "))
   (progn (setq tObj (vla-AddText
  (vlax-get-property (vla-get-ActiveDocument (vlax-get-acad-object))
    (if (= 1 (getvar 'CVPORT)) 'PaperSpace 'ModelSpace))
  content
  (vlax-3D-point point)
  0.09375))
     (vla-put-Alignment tObj acAlignmentMiddleCenter)
     (vla-put-TextAlignmentPoint tObj (vlax-3D-point point))
     (setq BL (+ (* (strlen content) 0.1) 0.2))
     (setq P1 (polar (polar point pi (/ bl 2)) (/ pi 2) 0.125)
    p2 (polar p1 (/ (* 3 pi) 2) 0.25)
    p3 (polar (polar point 0 (/ bl 2)) (/ (* 3 pi) 2) 0.125)
    p4 (polar p3 (/ pi 2) 0.25))
     (setq robj (vlax-ename->vla-object
      (entmakeX (list (cons 0 "LWPOLYLINE")
        (cons 100 "AcDbEntity")
        (cons 100 "AcDbPolyline")
        (cons 90 4)
        (cons 10 p1)
        (cons 10 p2)
        (cons 10 p3)
        (cons 10 p4)
        (cons 70 1)
        (cons 43 0.01)
        (cons 39 0.01)))))
     (vla-put-closed robj :vlax-true))))



Any suggestions on filleting still?

[alanjt]

You don't need to set it to closed with VL; (70 . 1) does that for you.



(defun c:test (/ content point tobj BL p1 p2 p3 p4)
 (vl-load-com)

 (while (= "" (setq content (strcase (getstring t "\nContents Within Box: "))))
   (princ "\nInvalid key: Enter the contents: ")
 )
 (setvar 'filletrad
         (cond ((getdist (strcat "\nSpecify fillet radius <"
                                 (rtos (getvar 'filletrad))
                                 ">: "
                         )
                )
               )
               ((getvar 'filletrad))
         )
 )
 (if (setq point (getpoint "\nCenter of cell: "))
   (progn (setq tObj (vla-AddText
                       (vlax-get-property
                         (vla-get-ActiveDocument (vlax-get-acad-object))
                         (if (= 1 (getvar 'CVPORT))
                           'PaperSpace
                           'ModelSpace
                         )
                       )
                       content
                       (vlax-3D-point point)
                       0.09375
                     )
          )
          (vla-put-Alignment tObj acAlignmentMiddleCenter)
          (vla-put-TextAlignmentPoint tObj (vlax-3D-point point))
          (setq BL (+ (* (strlen content) 0.1) 0.2))
          (setq P1 (polar (polar point pi (/ bl 2)) (/ pi 2) 0.125)
                p2 (polar p1 (/ (* 3 pi) 2) 0.25)
                p3 (polar (polar point 0 (/ bl 2)) (/ (* 3 pi) 2) 0.125)
                p4 (polar p3 (/ pi 2) 0.25)
          )
          (if (setq robj (entmakeX (list (cons 0 "LWPOLYLINE")
                                         (cons 100 "AcDbEntity")
                                         (cons 100 "AcDbPolyline")
                                         (cons 90 4)
                                         (cons 10 p1)
                                         (cons 10 p2)
                                         (cons 10 p3)
                                         (cons 10 p4)
                                         (cons 70 1)
                                         (cons 43 0.01)
                                         (cons 39 0.01)
                                   )
                         )
              )
            (command "_.fillet" "_polyline" robj)
          )
   )
 )
 (princ)
)

[harrison-matt]

Here it is once more with the option of square or round:

Thanks alan, i was trying to get the dang thing to round for some reason it wouldn't accept Fillet as a known command!



(defun c:test ( / content point tobj BL sobj robj dobj p1 p1.a p2 p3 p3.a p4)
 (vl-load-com)

 (while (= "" (setq content (strcase (getstring t "\nContents Within Box: "))))
   (princ "\nInvalid key: Enter the contents: "))
 (if (setq point (getpoint "\nCenter of cell: "))
    (progn (setq tObj (vla-AddText
   (vlax-get-property (vla-get-ActiveDocument (vlax-get-acad-object))
     (if (= 1 (getvar 'CVPORT)) 'PaperSpace 'ModelSpace))
   content
   (vlax-3D-point point)
   0.09375))
      (vla-put-Alignment tObj acAlignmentMiddleCenter)
      (vla-put-TextAlignmentPoint tObj (vlax-3D-point point))))

 (initget 128 "Square Rounded")
 (setq settings (getkword "\nChoose border type [square/Rounded]: "))
 (cond
   ((= settings "Square")
    (progn
      (setq BL (+ (* (strlen content) 0.1) 0.2))
      (setq P1 (polar (polar point pi (/ bl 2)) (/ pi 2) 0.125)
     p2 (polar p1 (/ (* 3 pi) 2) 0.25)
     p3 (polar (polar point 0 (/ bl 2)) (/ (* 3 pi) 2) 0.125)
     p4 (polar p3 (/ pi 2) 0.25))
      (entmakeX (list (cons 0 "LWPOLYLINE")
        (cons 100 "AcDbEntity")
        (cons 100 "AcDbPolyline")
        (cons 90 4)
        (cons 10 p1)
        (cons 10 p2)
        (cons 10 p3)
        (cons 10 p4)
        (cons 70 1)
        (cons 43 0.01)))))

    ((= settings "Rounded")
      (progn
 (setq BL (+ (* (strlen content) 0.1) 0.2))
 (setq P1 (polar (polar point pi (/ bl 2)) (/ pi 2) 0.125)
       p2 (polar p1 (/ (* 3 pi) 2) 0.25)
       p3 (polar (polar point 0 (/ bl 2)) (/ (* 3 pi) 2) 0.125)
       p4 (polar p3 (/ pi 2) 0.25))
 (setq robj (entmakeX (list (cons 0 "LWPOLYLINE")
       (cons 100 "AcDbEntity")
       (cons 100 "AcDbPolyline")
       (cons 90 4)
       (cons 10 p1)
       (cons 10 p2)
       (cons 10 p3)
       (cons 10 p4)
       (cons 70 1)
       (cons 43 0.01))))
 (command "_.fillet" "_polyline" robj))))
 (princ))
