JamFam Posted January 16, 2013 Share Posted January 16, 2013 Objective: to show in an electrical plan view a 2 and 5 gang light switch box. Problem; I have both a 2 and 5 gang light switch plates in separate locations. I need to show in an electrical plan that there are both a 2 and 5 gang switches in these particular location without crowding the wall with switch symbols. How do I do that? Quote Link to comment Share on other sites More sharing options...
ReMark Posted January 16, 2013 Share Posted January 16, 2013 You just can't put a number next to the symbol to denote what it is? Make it part of your legend too. Create this as a block and you are good to go. Quote Link to comment Share on other sites More sharing options...
JamFam Posted January 17, 2013 Author Share Posted January 17, 2013 Works for me. I just wasn't sure if there was a right way or a wrong way of doing this. Thanks ReMark. Quote Link to comment Share on other sites More sharing options...
